Chapter 1

Purpose of this Manual

This manual is for designers of systems based on the CoreModule™ 430 PC/104 single board computer
(SBC) module. This manual contains information that permits designers to create an embedded system
based on specific design requirements.
Information provided in this reference manual includes:
CoreModule 430 SBC Specifications
Environmental requirements
Major chips and features implemented
CoreModule 430 SBC connector/pin numbers and definitions
BIOS Setup information
Information not provided in this reference manual includes:
Detailed chip specifications
Internal component operation
Standard interface pin-out tables
Internal registers or signal operations
Bus or signal timing for industry standard busses and signals

References

The following list of references may be helpful for you to complete your custom design successfully. Some
of these references are also available on the Ampro By ADLINK web page. The web page was created for
embedded system developers to share ADLINK's knowledge, insight, and expertise.
Specifications
PC/104 Specifications Revision 2.5, November 2003
For latest revision of the PC/104 specifications, contact the PC/104 Consortium, at:
Web site:
Major Integrated Circuit (Chip) Specifications
The following chip specifications are used in the CoreModule 430 processor module:
DMP Electronics Inc. and the Vortex 86SX/DX CPU
Web site:
Winbond Electronics and the W25Q16BV SPI Flash memory
Web site:
http://www.winbond.com/hq/enu/ProductAndSales/ProductSearch/?partno=w25q16bv
Samsung Electronics and DDR2 on-board System Memory
Web site:
Hynix Semiconductor, Inc. and DDR2 on-board Video Memory
Web site:
NOTE
If you are unable to locate the datasheets using the links provided, search the
internet to find the manufacturer's web site and locate the documents you need.
CoreModule 430
About This Manual
http://www.pc104.org
http://www.vortex86sx.com/
http://www.samsung.com/global/business/semiconductor/
http://www.hynix.com/gl/products/consumer/consumer_info.jsp
Reference Manual
1
