Chapter 3

Power Interface

The CoreModule 430 requires one +5 volt DC power source. If the +5VDC power drops below ~4.65V, a
low voltage reset is triggered, resetting the system.
The power input header (J7) supplies the following voltages and ground directly to the module:
5.0VDC +/- 5% @ 1.35 Amps
Table 3-16
describes the pin signals of the Power interface, which uses a 10-pin, right-angle header with 2
rows, odd/even sequence (1, 2), and 0.100" (2.54mm) pitch.
Table 3-16. Power Interface Pin/Signals (J7)
Pin
Signal
1
GND
2
+5V
3
Key/GND
4
+12V
5
GND
6
NC
7
GND
8
+5V
9
GND
10
+5V
Note: The shaded table cells denote power or ground.
CoreModule 430
Descriptions
Ground
+5 Volts
Key Pin on connector/Grounded on board
+12 volts routed to PC/104
Ground
Not connected
Ground
+5 Volts
Ground
+5 Volts
Reference Manual
Hardware
31
