Chapter 3
Table 3-7. Serial Ports 3 & 4 Interface Pin/Signal Descriptions (J13, J14) (Continued)
4
RTS*
5
TXD
6
CTS*
7
DTR*
8
RI*
9
GND
10
Key/NC
Note: The shaded table cell denotes ground. The * symbol indicates the signal is Active Low.

USB Interface

The CoreModule 430 contains one root USB (Universal Serial Bus) hub and two functional USB ports. The
Vortex CPU provides the USB function including the following features:
Provides one root hub with two USB ports
Supports USB EHCI v.2.0 and USB OHCI v.1.1
Provides over-current detection status
Provides a fuse (F1, 1.5A) on board for over current protection
Table 3-8
describes the pin signals of the USB0 interface, which uses a single-row, 5-pin, right-angle header
with 0.100" (2.54mm) pitch.
Table 3-8. USB0 Interface Pin/Signal Designations (J10)
Pin #
Signal
1
USB0PWR
2
USB0N
3
USB0P
4
GND
5
SHIELD
Note: The shaded table cells denote power or ground.
Table 3-9
describes the pin signals of the USB1 interface, which uses a single-row, 5-pin header with 0.079"
(2mm) pitch.
Table 3-9. USB1 Interface Pin/Signal Designations (J17)
Pin #
Signal
1
USB1PWR
2
USB1N
3
USB1P
CoreModule 430
7
Request To Send – Indicates serial port is ready to transmit data. Used as
hardware handshake with CTS for low level flow control.
3
Transmit Data – Serial port transmit data output is typically held to a
logic 1 when no data is being sent. Typically, a logic 0 (On) must be
present on RTS, CTS, DSR, and DTR before data can be transmitted on
this line.
8
Clear To Send – Indicates external serial device is ready to receive data.
Used as hardware handshake with RTS for low level flow control.
4
Data Terminal Ready – Indicates serial port is powered, initialized, and
ready. Used as hardware handshake with DSR for overall readiness.
9
Ring Indicator – Indicates external serial device is detecting a ring
condition. Used by software to initiate operations to answer and open the
communications channel.
5
Ground
NC
Key Pin – Not connected
Description
USB Power – VCC (+5V +/-5%) power goes to the port through an on board
fuse. Port is disabled if this input is low.
USB0 Port Data Negative
USB0 Port Data Positive
USB0 Port ground
USB0 Port shield
Description
USB Power – VCC (+5V +/-5%) power goes to the port through an on board
fuse. Port is disabled if this input is low.
USB1 Port Data Negative
USB1 Port Data Positive
Reference Manual
Hardware
23
