Jumper Header Definitions; Figure 2-5. Header Locations (Top Side); Table 2-3. Jumper Settings - ADLINK Technology CoreModule 430 Reference Manual

Chapter 2
Key:
J2 - Fast Ethernet
J3 - COM1
J4 - Parallel
J5 - Utility
J6 - IDE
J7 - Power
J8 - GPIO
J9 - COM2
J10 - USB0
J11 - TTL and VGA Video
J13 - COM4
J14 - COM3
J17 - USB1
J19 - SPI 16 Mbit Data Storage
JP1 - See jumper table
JP2 - See jumper table
JP5 - See jumper table
JP6 - See jumper table
JP7 - See jumper table
JP8 - See jumper table
P1 - PC/104

Jumper Header Definitions

Table 2-3 describes the jumper headers shown in

Table 2-3. Jumper Settings

Jumper #
JP1 – Serial Port 2
Termination
JP2 – Serial Port 1
Termination
JP5 – Backlight
Voltage Select
JP6 – Flat Panel
Voltage Select
JP7 – Compact Flash
Voltage Select
JP8 – IDE Select
Note: All jumper headers use 0.079" (2mm) pitch.
CoreModule 430
J9 J14
JP5
JP6
J11
J17
J10
J7

Figure 2-5. Header Locations (Top Side)

Figure
Installed
Enable RS-485 Termination (Pins 1-2)
Enable RS-485 Termination (Pins 1-2)
+5 Volts (Pins 1-2)
+3.3 Volts (Pins 1-2) Default
+5 Volts (Pins 1-2)
Enable HDD master, CF slave (Pins 1-2)
Default
Reference Manual
J6
JP7
JP8
J13
J19
J20
P1
2-5.
Removed/Installed
Disable RS-485 Termination
(Removed) Default setting
Disable RS-485 Termination
(Removed) Default setting
+12 Volts (Pins 2-3) Default
+5 Volts (Pins 2-3)
+3.3 Volts (Pins 2-3) Default
Enable HDD slave, CF master
(Pins 2-3)
Product Overview
J5
JP2
JP1
J3
J8
J4
J2
11
