SBC84820 Pentium

M All-In-One Capa Board User's Manual

4.8

Integrated Peripherals

This section allows you to configure your SuperIO Device, IDE

Function and Onboard Device.

OnChip IDE Device

Scroll to this item and press <Enter> to view the sub menu OnChip

IDE Device.

IDE HDD Block Mode

Block mode is also called block transfer, multiple commands,

or multiple sector read/write. If your IDE hard drive supports

block mode (most new drives do), select Enabled for

automatic detection of the optimal number of block

read/writes per sector the drive can support.

Award BIOS Utility
