CAPONORD 1200
it controls the Ride by wire system, the injection/ignition, the system safety checks and the self-diagnosis
function
Level in electrical circuit diagram:
Each level in which the main component involves the control unit
Location:
•
on the vehicle: above the filter box
•
connector: on the 52 PIN connector ENGINE control unit, 28 PIN connector VEHICLE
Pin out:See the CONNECTORS section
DIAGNOSTICS INSTRUMENT: PARAMETERS ISO Screen page
(screen/example value with key set to ON)
•
ISO Code / -
•
Type-approval Code / -
•
Mapping / -
•
Marelli spare part code / IAW7SMHW430
•
Frame number (VIN) or diagnostics instrument serial number / -
•
Drawing number / -
•
Person in charge for last programming / - Indicates the series number of the DIAGNOSTICS
INSTRUMENT that has carried out the last control unit remapping
•
BOOT version / -
•
Control unit serial number (NIP) / -
•
Vehicle model / -
•
Internal code (IDVAG1) / -
•
Internal code (IDEEKE) / -
•
HW code / -
Electrical system
ELE SYS - 99
