CAPONORD 1200
disconnected, check that there is not voltage at the circuit ends: if there is voltage, restore the cable
harness.
Error code B0006 (INSIDE ERROR)
There is a fault in the instrument panel.
Troubleshooting
Replace the instrument panel.
Error code B0007 (INSUFFICIENT NUMBER OF MEMORISED KEYS)
The number of stored keys is less than two.
Dashboard
In case of doubts in operation of the engine revs indication, it is possible to connect the vehicle to the
diagnostics instrument and activate the engine revs indication choosing the function "Rpm indicator"
from the "Devices Activation" screen page (injector icon)
SELECTING kph - mph UNIT OF MEASUREMENT
•
Connect the diagnostics instrument to the Marelli (7SM) engine control unit and start a di-
agnostics session.
•
Go to the "adjustments" page and configure the vehicle.
•
Close the current diagnosis session.
•
Enter the instrument panel diagnosis and do a KEY OFF / KEY ON
•
Enter the instrument panel diagnosis and make sure the error is present.
•
To solve the error, go to the "adjustments" page and carry out a "Vehicle configuration reset".
•
Follow the instructions on the screen.
•
Delete the errors stored by the instrument panel.
Diagnosis
The instrument errors are detected by means of the diagnosis instrument. It is therefore necessary to
connect it to the vehicle.
Following are listed the errors generated by the instrument panel.
CONFIGURATION
Error code B0000 (CONFIGURATION ERROR)
Error cause
The configuration memorised in the instrument panel does not correspond to the one detected in the
vehicle where it is installed (e.g. configuration unit of measurement miles/kilometres).
Identification
Warning light on.
Troubleshooting
Electrical system
