CAPONORD 1200
Electrical system
2. FRONT LEFT TURN INDICATOR
3. FRONT HEADLAMP
4. FRONT RIGHT TURN INDICATOR
5. HIGH BEAM LIGHTS RELAY
6. LIGHT RELAY
7. LEFT LIGHT SWITCH
8. HORN
9. BLUEDASH PRE-INSTALLATION
10. INSTRUMENT PANEL
11. HEATED HANDGRIPS (WHERE PROVIDED)
12. POWER SUPPLY FOR GPS
13. RIGHT LIGHT SWITCH
14. QUICK SHIFT
15. FRONT STOP SWITCH
16. REAR STOP SWITCH
17. CLUTCH SWITCH
18. IGNITION SWITCH
19. IMMOBILIZER AERIAL
20. SAFETY RELAY
21. TAIL LIGHT
22. LICENSE PLATE LIGHT
23. REAR RIGHT TURN INDICATOR
24. REAR LEFT TURN INDICATOR
25. EVC CONTROL UNIT
31. EXHAUST VALVE MOTOR
32. ALTERNATOR
33. VOLTAGE REGULATOR
34. REAR ABS SENSOR
35. FRONT ABS SENSOR
36. ABS CONTROL UNIT
37. MAIN FUSES 2
38. STARTER MOTOR
39. START-UP RELAY
40. MAIN FUSE 1
41. BATTERY
42. ELECTRIC FANS
43. ELECTRIC FANS RELAY
44. USB PORT
ELE SYS - 81
