APRILIA CAPONORD 1200 Service Station Manual page 52

Characteristics
Specification
Crankcase class A
Crankcase class B
See also
Removing the flywheel cover
Crankcase class (internal marking on second
generation crankcases)
Two different crankcase classes (A or B) are avail-
able, selected in relation to the centre-to-centre
distance between the primary reduction gears.
The class is indicated on the clutch side crankcase
half, in the gearbox control mechanism area.
NOTE
IN THE EVENT OF CRANKCASE REPLACEMENT, THE PRI-
MARY REDUCTION GEAR IS SUPPLIED READY MESHED.
Specification
Crankcase class A
Crankcase class B
Class one
Two different pinion classes (A or B) are available,
selected in relation to the centre-to-centre dis-
tance between the primary reduction gears.
On class B pinions only, the class is indicated on
the pinion itself.
See also
Removing the flywheel cover
CHAR - 52
C 01
RANKCASE CLASSES
Centre-to-centre distance: 110.50 - 110.54 mm (4.3504 -
Centre-to-centre distance: 110.46 - 110.50 mm (4.3488 -
C 02
RANKCASE CLASSES
Centre-to-centre distance: 110.50 - 110.54 mm (4.3504 -
Centre-to-centre distance: 110.46 - 110.50 mm (4.3488 -
CAPONORD 1200
Desc./Quantity
4.3519 in)
4.3504 in)
Desc./Quantity
4.3519 in)
4.3504 in)
