APRILIA CAPONORD 1200 Service Station Manual page 47

CAPONORD 1200
pos. Description
2 Fastener screw for Pump Cover /
Clutch side cover
3 Screw fastening Pump Cover /
Clutch Cover / clutch side crankcase
half
4 Nut fastening water pump drive gear
sprocket
5 Water pump rotor
6 Screw fastening chain tensioner slid-
er to water pump
7 Water pump support fixing screw
8 Water pump support plug
pos. Description
1 Spark plug
2 Freewheel Ring fastener screw
3 Screw fixing rotor - Crankshaft - (12
mm - 0.47 in)
3 Screw fixing rotor - Crankshaft - (14
mm - 0.55 in)
4 Screw fastening Stator / Flywheel
Cover
5 Screw fastening pick-up / Flywheel
cover
6 Flywheel cover fastener screw
7 Screw fastening starter motor brack-
et to motor and crankcase
8 Crankshaft access cap
9 Retainer plate fastener screw
Type Quantity
M6 3
M6 2
M6 1
- 1
M6 1 8-10 Nm (5.90-7.38 lbf
M6 3
M6x10 1
I
GNITION
Type Quantity
- 4
M6 6
M12x1.25 1
M12x1.25 1
M6 3
M5 2
M6 10
M6 4
- 1
M6 1
Characteristics
Torque
13 Nm (9.59 lbf ft)
13 Nm (9.59 lbf ft)
12 Nm (8.85 lbf ft)
4.50 Nm (3.32 lbf ft)
ft)
12 Nm (8.85 lbf ft)
6.5 Nm (4.79 lbf ft) 3M SCOTCH GRIP
Torque
11 Nm (8.11 lb ft)
14 Nm (10.33 lb ft) 3M SCOTCH GRIP
130 Nm (95.88 lb ft)
190-200 Nm
(140.14-147.51 lb ft)
9 Nm (6.64 lb ft)
3.50 Nm (2.58 lb ft) Loctite 270
13 Nm (9.59 lb ft)
6.86-7.84 Nm Loct. 242
(5.06-5.78 lb ft)
4 Nm (2.95 lb ft)
8 Nm (5.90 lb ft) 3M SCOTCH GRIP
Notes
-
-
-
-
-
-
2353
Notes
-
2353
-
-
-
-
-
2353
CHAR - 47
