APRILIA CAPONORD 1200 Service Station Manual page 43

CAPONORD 1200
pos. Description
1 Oil drainage plug
2 Fastening oil sensor on clutch side
crankcase half
3 Fastening oil filter union on clutch
side crankcase half
4 Oil filter
5 Oil pressure regulator valve
6 Oil pump fixing screw
7 Rose pipe fixing screw
8 Oil pump driven gear fastener nut
9 By-Pass plate fastener screw
10 Oil cooling radiator nipple
O
IL PUMP
Type Quantity
M16x1.5 1
- 1
- 1
- 1
M18x1.5 1
M6 2 5-6 Nm (3.69-4.42 lbf ft) 3M SCOTCH GRIP
M6 2
M6 1
M5 2 5.50 Nm (4.06 lbf ft)
M16x1.5 2 42.5 Nm (31.35 lbf ft)
Characteristics
Torque
19 Nm (14.01 lbf ft)
13 Nm (9.59 lbf ft)
20 Nm (14.75 lbf ft)
14 Nm (10.33 lbf ft)
42 Nm (30.98 lbf ft)
12 Nm (8.85 lbf ft)
11 Nm (8.11 lbf ft)
Loctite 242
Notes
-
-
-
-
-
2353
-
-
-
CHAR - 43
