APRILIA CAPONORD 1200 Service Station Manual page 13

CAPONORD 1200
Specification
Dry weight (without fuel) (Caponord 1200)
Dry weight (without fuel) (Caponord 1200 Travel Pack)
Engine
Specification
No. of cylinders
Total engine capacity
Bore / stroke
Compression ratio
Electric
Engine idle speed
Clutch
Lubrication
Air filter
Cooling
Specification
Transmission
Specification
Gear ratio
1st gear ratio
2nd gear ratio
3rd gear ratio
4th gear ratio
5th gear ratio
6th gear ratio
Final drive gear ratio
Capacities
Specification
Fuel tank (reserve included)
Fuel reserve
Engine oil
Coolant
Maximum weight limit
Model
Type
G
Type
G
EAR RATIOS
C
Seats
Desc./Quantity
233 kg (513.68 lb)
247 kg (544.54 lb)
E
NGINE
Desc./Quantity
90° longitudinal V-twin, 4-stroke, 4 valves per cylinder, 2 over-
head camshafts.
1197 cm³ (73.05 cu in)
106 x 67.8 mm (4.17 x 2.67 in)
12.0 +/- 0.5: 1
1450 ± 100 rpm
Multiple-disk, oil-bathed clutch with control on the left side of
the handlebar
Wet crankcase. Pressure system regulated by a trochoidal
pump with oil radiator.
EARBOX
Desc./Quantity
Mechanical, 6 speeds with foot lever on the left hand side of
Desc./Quantity
Gear primary drive 40/69
14/36 (secondary)
17/32 (secondary)
20/30 (secondary)
22/28 (secondary)
23/26 (secondary)
24/25 (secondary)
APACITY
Desc./Quantity
24 l (5.28 UK gal; 6.34 US gal)
4 l (0.88 UK gal; 1.06 US gal)
3.1 l (without oil filter change) (0.68 UK gal; 0.82 US gal)
3.35 l (with oil filter change) (0.74 UK gal; 0.88 US gal)
2.5 l (0.55 UK gal; 0.66 US gal)
460 kg (1014.12 lb)
Characteristics
M558M
2
Starter
Sponge.
Fluid
the engine
17/42
2
CHAR - 13
