CAPONORD 1200
•
Rear throttle position (pot. 1) (°)
•
Front throttle position correction (°)
•
Rear throttle position correction (°)
•
Front lambda probe tension (mV)
•
Rear lambda probe tension (mV)
•
Correction front cylinder value (%)
•
Correction rear cylinder value (%)
•
Front cylinder fuel adaptive correction (%)
•
Rear cylinder fuel adaptive correction (%)
•
Grip opening percentage (%)
•
Advance front cylinder ignition (central spark plug) (°)
•
Advance front cylinder ignition (side spark plug) (°)
•
Advance rear cylinder ignition (central spark plug) (°)
•
Advance rear cylinder ignition (side spark plug) (°)
•
Motor temperature (°C)
•
Intake air temperature (°C)
•
Front Cylinder Intake Pressure (mbar)
•
Reference Front Cylinder Intake Pressure (mbar)
•
Rear Cylinder Intake Pressure (mbar)
•
Reference Rear Cylinder Intake Pressure (mbar)
•
Battery voltage (V)
•
Exhaust butterfly valve target position (%)
•
Blue connector throttle grip position sensor - track A (mV)
•
Blue connector throttle grip position sensor - track B (mV)
•
White connector throttle grip position sensor - track C (mV)
•
White connector throttle grip position sensor - track D (mV)
•
Tension Front throttle Potentiometer 1 (mV)
•
Tension Front throttle Potentiometer 2 (mV)
•
Tension Rear throttle Potentiometer 1 (mV)
•
Tension Rear throttle Potentiometer 2 (mV)
•
Front throttle Limp Home position (mV)
•
Front throttle lower position (mV)
•
Rear throttle Limp Home position (mV)
•
Rear throttle lower position (mV)
•
Front throttle position (potentiometer 2) (°)
•
Rear throttle position (potentiometer 2) (°)
•
Motor temperature at start (°C)
•
Front cylinder injection time (ms)
Electrical system
ELE SYS - 101
