Introduction

Parameter group 3xx selects the analog and digital inputs and outputs to the desired function. Also scaling of
the inputs and outputs is performed in this group. Inputs: Max frequency on inputs terminal 16, 17, 18, 19,
27, 32, and 33 is 5 kHz. (24Vpp). Max frequency on inputs terminal 29 is 65 kHz (24Vpp).
Max frequency for the encoder inputs terminal 73 - 78 is 250 kHz (5Vpp). Outputs: Analog outputs terminal
42 and 45 are scaleable current outputs. Max frequency on digital outputs terminal 26 and 46 is 50kHz.
PNU Parameter
# description
300 Terminal 16, input
301 Terminal 17, input
302 Terminal 18 Start, input
303 Terminal 19, input
304 Terminal 27, input
305 Terminal 29, input
306 Terminal 32, input
307 Terminal 33, input
308 Terminal 53, analog input voltage
309 Terminal 53, min. scaling
310 Terminal 53, max. scaling
311 Terminal 54, analog input voltage
312 Terminal 54, min. scaling
313 Terminal 54, max. scaling
314 Terminal 60, analog input current
315 Terminal 60, min. scaling
316 Terminal 60, max. scaling
317 Time out
318 Function after time out
319 Terminal 42, output
321 Terminal 45, output
323 Relay 01, output
324 Relay 01, ON delay
325 Relay 01, OFF delay
326 Relay 04, output
327 Pulse reference, max. frequency
329 Encoder feedback pulse/rev.
341 Terminal 46, digital output
342 Terminal 46, output, pulse scaling
350 Encoder monitoring
351 Encoder direction
355 Terminal 26, digital output
356 Terminal 26, output, pulse scaling
357 Terminal 42, Output minimum scaling
358 Terminal 42, Output maximum scaling
359 Terminal 45, Output minimum scaling
360 Terminal 45, Output maximum scaling
361 Max Tracking Error
362 KTY Sensor Type
See also Operation and Display for further
information regarding Changes during operation,
4-Setup and Conversion index.
= factory setting. () = display text [] = value for use in communication via serial communication port
88
Factory setting Range
Reset
Freeze reference
Start
Reversing
Coasting stop, inverse
Jog
Choice of setup, msb/speed up
Choice of setup, lsb/speed down
Reference
0.0 V 0.0 - 10.0 V
10.0 V 0.0 - 10.0 V
No operation
0.0 V 0.0 - 10.0 V
10.0 V 0.0 - 10.0 V
Reference
0.0 mA 0.0 - 20.0 mA
20.0 mA 0.0 - 20.0 mA
10 sec. 0 - 99 sec.
Off
⇒ 0-20 mA
0 - n
MAX
⇒ 0-20 mA
0 - n
MAX
No operation
0.00 sec. 0.00 - 600.00 sec.
0.00 sec. 0.00 - 600.00 sec.
No operation
100 - 65000 Hz 5000 Hz
1024 pulses/rev. 500 - 10.000 pulses/rev.
No operation
5000 Hz 1 - 50000 Hz
OFF
Normal
No operation
5000 Hz 1 - 50000 Hz
0 % 000 - 100%
100% 000 - 500%
0 % 000 - 100%
100% 000 - 500%
OFF 000 - 999 rpm
KTY1 KTY 1-3
MG.55.A6.02 - VLT is a registered Danfoss trademark
®
VLT 5000 FLUX
Conver-
Changes 4-Setup sion
during operation index
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes -1
Yes Yes -1
Yes Yes 0
Yes Yes -1
Yes Yes -1
Yes Yes 0
Yes Yes -4
Yes Yes -4
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes -2
Yes Yes -2
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
No No 0
No Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
No Yes 0
Data
type
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
6
6
5
6
6
5
6
5
5
5
6
6
6
6
6
6
5
