References and limits

Introduction
The purpose of the parameter group 2xx is selecting and adjusting references, ramping times and setting
limits for warnings.
Actual reference
External reference
Preset reference
PNU Parameter
# description
200 Output speed range/direction
202 Output speed high limit
203 Reference Range
204 Minimum reference
205 Maximum reference
206 Ramp type
207 Ramp-up time 1
208 Ramp-down time 1
209 Ramp-up time 2
210 Ramp-down time 2
211 Jog ramp time
212 Quick stop ramp-down time
213 Jog speed
214 Reference function
215 Preset reference 1
216 Preset reference 2
217 Preset reference 3
218 Preset reference 4
219 Catch up/slow down value
221 Torque limit for motor mode
222 Torque limit for generating
operation
223 Warning: Low current
224 Warning: High current
225 Warning: Low speed
226 Warning: High speed
234 Motor phase monitor
235 Phase loss monitor
236 Low Speed Current
237 Model Shift Speed
240 Acceleration Jerk 1
241 Acceleration Jerk 2
242 Deceleration Jerk 1
243 Deceleration Jerk 2
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.55.A6.02 - VLT is a registered Danfoss trademark
Resulting reference for speed/torque
Reference on Terminals 53, 54 or 60, and puls and bus references
Reference value from the internal four presets.
Factory setting
Only clockwise, 0-4500
rpm
3000 rpm
Min - max
0.000
1500.000
Linear
Depends on unit
Depends on unit
Depends on unit
Depends on unit
Depends on unit
Depends on unit
200 rpm
Sum
0.00 %
0.00 %
0.00 %
0.00 %
0.00 %
160 %
160 %
0.0 A
I
VLT,MAX
0 rpm
100.000 rpm
Enable
Enable
100%
20% of n
nom
33%
33%
33%
33%
®
VLT
Range Changes
during operation
No
n - par. 200 No
MIN
Yes
-100,000.000-Ref Yes
MAX
Ref -100,000.000 Yes
MIN
Yes
0.01 - 3600 Yes
0.01 - 3600 Yes
0.01 - 3600 Yes
0.01 - 3600 Yes
0.01 - 3600 Yes
0.01 - 3600 Yes
0.0 - par. 202 Yes
Yes
- 100.00 - 100.00 % Yes
- 100.00 - 100.00 % Yes
- 100.00 - 100.00 % Yes
- 100.00 - 100.00 % Yes
0.00 - 100 % Yes
0.0 % - xxx % Yes
0.0 % - xxx % Yes
0.0 - par. 224 Yes
Par. 223 - I Yes
VLT,MAX
0 - par. 226 Yes
Par. 225 - par. 202 Yes
Yes
No
0 – Motor size depended Yes
10 Hz Yes
0-100% No
0-100% No
0-100% No
0-100% No
5000 FLUX
4-Setup Conversion Data
index type
Yes 0 5
Yes -1 6
Yes 0 5
Yes -3 4
Yes -3 4
Yes 0 5
Yes -2 7
Yes -2 7
Yes -2 7
Yes -2 7
Yes -2 7
Yes -2 7
Yes -1 6
Yes 0 5
Yes -2 3
Yes -2 3
Yes -2 3
Yes -2 3
Yes -2 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes 0 5
No 0 5
Yes 0 6
No 0 6
No 0 U16
No 0 U16
No 0 U16
No 0 U16
79
