Parameter survey

PNU Parameter
# description
001 Language
002 Local/remote control
003 Local reference
004 Active setup
005 Programming setup
006 Copying of setups
007 LCP copy
008 Display scaling speed
009 Display lini 2
010 Display line 1.1
011 Display line 1.2
012 Display line 1.3
013 Local operation mode
014 Local stop
015 Local jog
016 Local reversing
017 Local reset of trip
018 Lock for data change
019 Operating state at power-up, local
control
024 Userdefined Quick Menu
025 Quick Menu Setup
Changes during operation:
"Yes" means that the parameter can be changed,
while the frequency converter is in operation. "No"
means that the frequency converter must be stopped
before a change can be made.
4-Setup:
"Yes" means that the parameter can be programmed
individually in each of the four setups, i.e. the
same parameter can have four different data
values. "No" means that the data value will be
the same in all four setups.
Conversion index:
This number refers to a conversion figure to
be used when writing or reading by means
of a frequency converter.
MG.55.A6.02 - VLT is a registered Danfoss trademark
Factory setting Range
English
Remote control
000.000
Setup 1
Active setup
No copying
No copying
1 0.01 - 100.00
Speed [rpm]
Reference [%]
Motor current [A]
Power [kW]
LCP control
Enable
Not possible
Not possible
Possible
Not locked
Forced stop, use
saved ref.
Not active
000 0-999
Data type:
Data type shows the type and length of the telegram.
Data type
3
4
5
6
7
9
®
VLT 5000 FLUX
Changes 4-Setup
during operation
No No
Yes Yes
Yes Yes
Yes No
Yes No
No No
No No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes No
Yes No
Conversion index
74
2
1
0
-1
-2
-3
-4
Description
Integer 16
Integer 32
Unsigned 8
Unsigned 16
Unsigned 32
Text string
Conversion Data
index type
0 5
0 5
-3 4
0 5
0 5
0 5
0 5
-2 6
0 5
0 5
0 5
0 5
0 5
0 5
0 5
0 5
0 5
0 5
0 5
0 5
0 6
Conversion factor
0.1
100
10
1
0.1
0.01
0.001
0.0001
131
