Serial communication

Introduction
The purpose of the serial communication parameters is to select and adjust parameters in conjunction with
RS 485 field bus. See wiring diagram 'Bus connection' in the installation section.
PNU Parameter
# description
500 Address
501 Baudrate
502 Coasting
503 Quick-stop
504 DC-brake
505 Start
506 Reversing
507 Selection of setup
508 Selection of speed
509 Bus jog 1
510 Bus jog 2
512 Telegram profile
513 Bus time interval
514 Bus time interval function
515 Data read-out: Reference %
516 Data read-out: Reference unit
518 Data read-out: Frequency
520 Data read-out: Current
521 Data read-out: Torque
522 Data read-out: Power, kW
523 Data read-out: Power, HP
524 Data read-out: Motor voltage
525 Data read-out: DC link voltage
526 Data read-out: Motor temp.
527 Data read-out: VLT temp.
528 Data read-out: Digital input
529 Data read-out: Terminal 53,
analog input
530 Data read-out: Terminal 54,
analog input
531 Data read-out: Terminal 60,
analog input
532 Data read-out: Pulse reference
533 Data read-out: External reference %
534 Data read-out: Status word, binary
535 Data read-out: Brake power/2 min.
536 Data read-out: Brake power/sec.
537 Data read-out: Heat sink temperature
538 Data read-out: Alarm word, binary
539 Data read-out: VLT control word, binary
540 Data read-out: Warning word, 1
541 Data read-out: Extended status word
557 Data read-out: Motor RPM
558 Data read-out: Motor RPM x scaling
