PNU Parameter
# description
100 Configuration
101 Torque characteristics
102 Motor power
103 Motor voltage
104 Motor frequency
105 Motor current
106 Rated motor speed
107 Automatic motor adaptation, AMA Adaptation off
115 Slip Compensating
116 Slip compensation time constant
119 High starting torque
120 Start delay
121 Start function
122 Function at stop
123 Min. speed for activating function
at stop
124 DC holding current
125 DC braking current
126 DC braking time
127 DC brake cut-in speed
128 Motor thermal protection
129 External motor fan
130 Start speed
131 Initial current
150 Stator resistance
151 Rotor resistance
152 Stator leakage reactance
153 Rotor leakage reactance
154 Main reactance
156 Pole number
158 Ironloss resistance
161 Minimum Inertia
162 Maximum Inertia
163 Functional stop delay
164 Mech. brake release delay
165 Mech. brake initial torque
166 Mech. brake initial direction
167 Proportional gain boost, during
brake release
See also Operation and Display for further
information regarding Changes during operation,
4-Setup and Conversion index.
132
Factory setting Range
Speed control, closed loop
High - constant torque
Depends on the unit 0.18-500 kW
Depends on the unit 200 - 500 V
50 Hz
Depends on the unit 0.01-I
Depends on the unit 100-60000 rpm
100% -400% - +400%
0.50 sec. 0.05-5.00 sec.
0.0 sec. 0.0 - 0.5 sec.
0.0 sec. 0.0 - 10.0 sec.
Coasting in start delay time
Coasting
0 rpm 0 - 600 rpm
50 % 0 - 100 %
50 % 0 - 160 %
10.0 sec. 0.0 - 60.0 sec.
Off 0.0-par. 202
No protection
No
0.0 rpm 0.0 - 600 rpm
0.0 Amp 0.0-par. 105
Depends on unit Ohm
Depends on unit Ohm
Depends on unit Ohm
Depends on unit Ohm
Depends on unit Ohm
4-pole motor 2-100
10000 1 - 10000
Depends on unit Kgm
Depends on unit Kgm
0 0 – 5 sec
0.5 sec 0.01 - 2.00 sec
20% +/- P221
[0] Clockwise [0] Clockwise
[1] Ref. dir.
100% 0-400%
®
VLT 5000 FLUX
Changes 4-Setup
during operation
No Yes
No Yes
No Yes
No Yes
No Yes
No Yes
VLT,MAX
No Yes
No No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
No Yes
No Yes
No Yes
No Yes
No Yes
No Yes
No Yes
2
No Yes
2
No Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
MG.55.A6.02 - VLT is a registered Danfoss trademark
Conversion Data
index type
0 5
0 5
1 6
0 6
0 6
-2 7
0 6
0 5
0 3
-2 6
-1 5
-1 5
0 5
0 5
-1 5
0 6
0 6
-1 6
-1 6
0 5
0 5
-1 5
-1 6
-4 7
-4 7
-3 7
-3 7
-3 7
0 5
0 6
-4 7
-4 7
-1 7
-2 U16
-1 S16
0 U8
0 S16
