Tightening-up torques and screw sizes

The table shows the torque required when fitting
terminals to the frequency converter. For VLT
5001-5027 200-240 V and VLT 5001-5102 380-500
V, the cables must be fastened with screws. For VLT
5032-5052 200-240 V and VLT 5122-5500 380-500
V, the cables must be fastened with bolts.
These figures apply to the following terminals:
VLT type
200-240 V
5001-5006
5008
5008-5011
5011-5022
3)
5016-5022
5027
1)
5032-5052
380-500 V
5001-5011
5016-5022
5016-5027
5027-5042
3)
5032-5042
5052-5062
5072-5102
4)
5122-5302
5)
5350-5500
1) Brake terminals: 3,0 Nm, Nut: M6
2) Brake and loadsharing: 14 Nm, M6 Allen screw
3) IP54 with RFI - Line terminals 6Nm, Screw: M6 - 5 mm Allen wrench
4) Loadshare and brake terminals: 9,5 Nm; Bolt M8
5) Brake terminals: 11,3 Nm; Bolt M8
MG.55.A6.02 - VLT is a registered Danfoss trademark
Torque [Nm]
0,6
IP20 1,8
IP54 1,8
IP20 3
IP54 3
6
11,3
0,6
IP20 1,8
IP54 1,8
IP20 3
IP54 3
6
IP20 15
2)
IP54 24
19
42
®
VLT 5000 FLUX
Mains terminals
Motor terminals
Earth terminal
Brake resistor terminals
Loadsharing
Screw/
Boltsize
M3
M4
M4
M5
M5
M6
M8 (bolt and stud)
M3
M4
M4
M5
M5
M6
M6
M8
M10 bolt
M12 bolt
Nos 91, 92, 93
L1, L2, L3
Nos 96, 97, 98
U, V, W
No 94, 95, 99
81, 82
88, 89
Tool
Slotted screw
Slotted screw
Slotted screw
4 mm Allen wrench
4 mm Allen wrench
4 mm Allen wrench
Slotted screw
Slotted screw
Slotted screw
4 mm Allen wrench
4 mm Allen wrench
5 mm Allen wrench
6 mm Allen wrench
8 mm Allen wrench
21
