General technical data

Mains supply (L1, L2, L3):
Supply voltage 200-240 V units ........................................................................ 3 x 200/208/220/230/240 V ±10%
Supply voltage 380-500 V units ................................................................ 3 x 380/400/415/440/460/500 V ±10%
Supply frequency ......................................................................................................................... 48-62 Hz +/- 1%
Max imbalance of supply voltage:
VLT 5001-5011, 380-500 V and VLT 5001-5006, 200-240 V ................................... ±2.0% of rated supply voltage
VLT 5016-5062, 380-500 V and VLT 5008-5027, 200-240 V ................................... ±1.5% of rated supply voltage
VLT 5072-5500, 380-500 V and VLT 5032-5052, 200-240 V .................................. ±3.0% of rated supply voltage
True Power factor (λ) ...................................................................................................... 0.90 nominal at rated load
Displacement Power Factor (cos ϕ) ............................................................................................. near unity (>0.98)
No. of switchings on supply input L1, L2, L3 .......................................................................... approx. 1 time/min.
VLT output data (U, V, W):
Output voltage ................................................................................................................ 0-100% of supply voltage
Output frequency ................................................................................................................ 0 - 132 Hz, 0 - 300 Hz
Rated motor voltage, 200-240 V units .............................................................................. 200/208/220/230/240 V
Rated motor voltage, 380-500 V units ............................................................... 380/400/415/440/460/480/500 V
Rated motor frequency ............................................................................................................................ 50/60 Hz
Switching on output ................................................................................................................................. Unlimited
Ramp times .................................................................................................................................... 0.01-3600 sec.
Torque characteristics:
Starting torque, VLT 5001-5027, 200-240 V and VLT 5001-5302, 380-500 V ................................ 160% for 1 min.
Starting torque, VLT 5032-5052, 200-240 V and VLT 5350-5500, 380-500 V ................................ 150% for 1 min.
Starting torque ............................................................................................................................ 180% for 0.5 sec.
Acceleration torque ....................................................................................................................................... 100%
Overload torque, VLT 5001-5027, 200-240 V and VLT 5001-5302, 380-500 V ............................................. 160%
Overload torque, VLT 5032-5052, 200-240 V and VLT 5350-5500, 380-500 V ............................................. 150%
Arresting torque at 0 rpm (closed loop) ......................................................................................................... 100%
The torque characteristics given are for the frequency converter at the high overload torque level
(160%). At the normal overload torque (110%), the values are lower.
200-240 V
5001-5027
5032-5052
380-500 V
5001-5102
5122-5252
5302
5350-5500
Control card, digital inputs:
Number of programmable digital inputs ................................................................................................................ 8
Terminal nos. ............................................................................................................ 16, 17, 18, 19, 27, 29, 32, 33
Terminal number for none programmable digital input ........................................................................................ 37
Voltage level ........................................................................................................... 0-24 V DC (PNP positive logics)
Voltage level, logical '0' ............................................................................................................................ < 5 V DC
138
Braking at high overload torque level
Cycle time (s) Braking duty cycle at
120
300
120
600
600
300
VLT
100% torque
Continuous
10%
Continuous
Continuous
40%
10%
MG.55.A6.02 - VLT is a registered Danfoss trademark
®
5000 FLUX
Braking duty cycle at over
torque (150/160%)
40%
10%
40%
10%
10%
10%
