Display mode - selection of read-outstate

• Read-out state I:
This read-out state is default after starting
up or after initialisation.
FREQUENCY
1500 rpm
MOTOR IS RUNNING
Line 2 shows the data value of an operating variable
with related unit. Line 1 provides a text which explains
line 2. In the example,the speed has been selected as
variable via parameter 009. In normal operation mode
variables can be read out by using the [+/-] keys.
• Read-out state II:
Switching between read-out states I and II is effected by
pressing the [DISPLAY / STATUS] key in less than 1 sec.
24.3% 30.2%
1500 rpm
MOTOR IS RUNNING
Data values for four operating values are shown at the
same time, giving the related unit, cf. table. In the
example, Reference, Torque, Current and Speed are
selected as variables in the first and second line.
• Read-out state III:
Read-out state III can be shown as long as the
[DISPLAY/STATUS] key is pressed. When the
key is released, the system switches back to
Read-out state II, unless the key is pressed for
less that approx. 1 sec., in which case the system
always reverts to Read-out state I.
This is where parameter names and units for operating
variables in the first and second line are given -
operating variable 2 remains unchanged.
Operating values 1.1 and 1.2 and 1.3 in the first line,
and operating value 2 in the second line are selected
via parameter 009, 010, 011 and 012.
MG.55.A6.02 - VLT is a registered Danfoss trademark
SETUP
1
13.8A
SETUP
1 2
®
VLT
• Display state IV:
This display state can be produced during operation
if another setup is to be changed without stopping
the frequency converter. This function is activated
in parameter 005, Programming Setup.
24.3% 30.2%
1500 rpm
MOTOR IS RUNNING
The selected programming setup number will flash
to the right of the active setup.
The fourth line is showing status messages .
Structure for the Quick menu mode versus
the Menu mode
Each named parameter is linked up with a number
which is the same regardless of the programming
mode. In Menu mode, the parameters are divided
into groups, with the left digit of the parameter
number indicating the parameter.
• The Quick menu takes the user through a number
of parameters that may be enough to get the
motor to run nearly optimally, if the factory setting
for the other parameters takes the desired control
functions into account, as well as the configuration
of signal inputs/outputs (control terminals).
• Menu mode makes it possible to select and change
all parameters at the user's option. However, some
parameters will be "missing", depending on the
choice of configuration (parameter 100).
5000 FLUX
13.8A
SETUP
1 2
