Digital and relay outputs

Digital outputs (Terminal 26 and 46, relay 01 and 04). Digital outputs are 0/24 V outputs Load : > 600 .
Common terminal (terminal 39) is the same for analog common and digital common. Relay 01 is placed on
the power board in the frequency converter. Relay 04 is placed on the control board.
Outputs
Value:
No function
Control ready
Ready signal
Ready - remote control
Enable, no warning
Running
Running, no warning
Running within range, no warning
Running at reference value, no warning
Fault
Fault or warning
Torque limit
Out of current range
Over I low
Under I high
Out of speed range
Over n low
Under n high
Thermal warning
Ready - no thermal warning
Ready - remote control - no therm.
warn.
Ready - mains voltage within range
Reversing
Bus ok
Torque limit and stop
Brake, no brake warning
Brake ready, no fault
Brake fault
Relay 123
Mechanical brake control
Control word bit 11/12
⇒ 0-50000 p
Ref - Ref
MIN MAX
⇒ 0-50000 p
0 - I
MAX
⇒ 0-50000 p
0 - T
LIM
⇒ 0-50000 p
0 - T
NOM
⇒ 0-50000 p
0 - P
NOM
0 - MAX SPEED ⇒ 0-50000 p
+/-160% TORQ ⇒ 0-50000 p
1) When mechanical brake control is selected, output 46 and 26 are inverted.
Function:
Description of choice:
Control ready, the frequency converter is ready for
use; the control board receives supply voltage.
Ready signal, the frequency converter control board
is receiving a supply signal and the frequency
converter is ready for operation.
Ready, remote control, the frequency converter control
board is receiving a supply signal and parameter
002 has been set to remote control.
= factory setting. () = display text [] = value for use in communication via serial communication port
96
terminal no.
parameter
(NO OPERATION)
(CONTROL READY)
(UNIT READY)
(UNIT READY/REM CTRL)
(ENABLE/NO WARNING)
(VLT RUNNING)
(RUNNING/NO WARNING)
(RUN IN RANGE/NO WARN)
(RUN ON REF/NO WARN)
(ALARM)
(ALARM OR WARNING)
(TORQUE LIMIT)
(OUT OF CURRENT RANGE)
(ABOVE CURRENT,LOW)
(BELOW CURRENT,HIGH)
(OUT OF SPEED RANGE)
(ABOVE SPEED LOW)
(BELOW SPEED HIGH)
(THERMAL WARNING)
(READY & NOTHERM WARN)
(REM RDY & NO THERMWAR)
(RDY NO OVER/UNDERVOL)
(REVERSE)
(BUS OK)
(TORQUE LIMIT AND STOP)
(BRAKE NO BRAKE WARNING)
(BRAKE RDY (NO FAULT))
(BRAKE FAULT (IGBT))
(RELAY 123)
(MECH. BRAKE CONTROL)
(CTRL WORD BIT 11/12)
(REF MIN-MAX = 0-50000P)
(0-IMAX = 0-50000P)
(0-TLIM = 0-50000P)
(0-TNOM = 0-50000P)
(0-PNOM = 0-50000P)
(0-MAX SPD. = 0-50000P)
(+/-160% TORQ= 0-50000P)
Enable, no warning, the frequency converter is
ready for use; no start or stop command has been
given (start/disable). No warning.
Running, a start command has been given.
Running, no warning, the output speed is higher
than the speed set in parameter 123. A start
command has been given. No warning.
Runs in range, no warning, runs within the programmed
current/speed ranges set in parameters 223-226.
®
VLT 5000 FLUX
01(relay) 04 (relay)
323 326
[0] [0]
[1] [1]
[2] [2]
[3] [3]
[4] [4]
[5] [5]
[6] [6]
[7] [7]
[8] [8]
[9] [9]
[10] [10]
[11] [11]
[12] [12]
[13] [13]
[14] [14]
[15] [15]
[16] [16]
[17] [17]
[21] [21]
[22] [22]
[23] [23]
[24] [24]
[25] [25]
[26] [26]
[27] [27]
[28] [28]
[29] [29]
[30] [30]
[31] [31]
[32] [32]
[33] [33]
MG.55.A6.02 - VLT is a registered Danfoss trademark
46 26
341 355
[0] [0]
[1] [1]
[2] [2]
[3] [3]
[4] [4]
[5] [5]
[6] [6]
[7] [7]
[8] [8]
[9] [9]
[10] [10]
[11] [11]
[12] [12]
[13] [13]
[14] [14]
[15] [15]
[16] [16]
[17] [17]
[21] [21]
[22] [22]
[23] [23]
[24] [24]
[25] [25]
[26] [26]
[27] [27]
[28] [28]
[29] [29]
[30] [30]
[31] [31]
1) 1)
[32] [32]
[33] [33]
[34] [34]
[36] [36]
[37] [37]
[38] [38]
[39] [39]
[40] [40]
[41] [41]
