Kyocera TASKalfa 3050ci Service Manual page 136

Item No.
U140 Setting: [Mag Duty]
1. Select the item to be set.
2. Change the setting value using the +/- keys or numeric keys.
Display
Normal
B/W
3. Press the start key. The value is set.
Method: [AC Calib]
1. Select the item.
Calibration
Magnification
Type
Method: [Calibration]
1. Turns the items to implement to on.
If the machine is installed at high altitude, select [High Altitude].
C
M
Y
K
High Altitude
2. Select [Execute].
3. Press the start key. AC calibration is executed.
4. Turn the main power switch off and on. Allow more than 5 seconds between Off and On.
* : When an error occurs, an error code is displayed.
Description
Developer magnet roller duty
Developer magnet roller duty in black/
white mode
Display
Executing the AC calibration
AC calibration target bias value setting
Mode setting for AC calibration bias control
Display
Developer unit C or drum unit C
Developer unit M or drum unit M
Developer unit Y or drum unit Y
Developer unit K or drum unit K
Overall setting for installation at high altitude
Description
0 to 99
0 to 99
Description
Description
1-3-94
2LK/2LN/2LM/2LC
Initial
setting
Setting
range
30 ppm/
35 ppm
63
43
45 ppm/
55 ppm
43
43
