1-1-2 Parts names

(1) Machine

17
18
19
20
1. Original size indicator plate
2. Slit glass
3. Toner container K
4. Toner container M
5. Toner container C
6. Toner container Y
7. Platen (Contact glass)
8. Clip holder
9. Operation panel
10. Indicators
1
2
3
4
5
6
11
Figure 1-1-1
11. Handles
12. Release button
13. Waste toner box
14. Waste toner tray
15. Front cover
16. Toner container release lever
17. Network interface connector
18. USB port
19. USB interface connector
20. Option interface
1-1-6
2LK/2LN/2LM/2LC
12 13 14 15
7
8
9
10
16
