Table of Inputs and Outputs

Main Outputs
Program 1
Program 2
Program 3
Program 4
Program 4 Record
Program 4 Phone
Aux Inputs and Outputs
Aux Send A Output
Aux Send B Output
Aux Send C Output
Aux Send D Output
Aux Return A Input
Aux Return B Input
Monitor-related Outputs
Monitor 1
C/R Monitor Direct
Main Headphone
Monitor 2
Studio Headphone Talent
Studio Headphone Guest
Preview
Talk to External
Talk to CR Audio
Monitor-related Inputs
External Preview Input
External Monitor Input 1
External Monitor Input 2
Source Inputs
Microphone Input n
Analog Line Input n
Digital Line Input n
Source-related Outputs
Feed-to-Source A n
Feed-to-Source B n
Individual Hphone Feed n
Type Comments
Stereo Main stereo bus (Usually referred to as Program)
Stereo Second stereo bus (Sometimes referred to as Audition)
Stereo Third stereo bus (Sometimes referred to as Utility)
Stereo Fourth stereo bus (Sometimes referred to as Auxiliary)
Stereo Fourth stereo bus variation (post fader, pre on/off)
Mono Fourth stereo bus variation (pre fader, pre on/off)
Type Comments
Stereo Aux send bus can be used for processing or independent mixes
Stereo Aux send bus can be used for processing or independent mixes
Stereo Aux send bus can be used for processing or independent mixes
Stereo Aux send bus can be used for processing or independent mixes
Stereo Allows processing to be folded back into a mix
Stereo Allows processing to be folded back into a mix
Type Comments
Stereo Control room monitor speakers, source and level controlled by Element Monitor
1 control
Stereo Control room monitor output, source same as Monitor 1, fixed level output
Stereo Control room (board op) headphone, source and level controlled by Element
headphone control
Stereo Studio monitor speakers, source and level controlled by Element Monitor 2 con-
trol
Stereo Studio (talent) headphones, source same as main, fixed level output, with
talkback
Stereo Studio (guest) headphones, source same as main, fixed level output, no talkback
Stereo Allows the connection and level control of external powered speakers.
Mono Allows board operator mic to talk to other devices, a logic command is associated
Mono Allows the Talk to CR audio mix to drive an external destination
Type Comments
Stereo Allows an external path into the preview speakers, a logic command is associated
Stereo Allows an external source to be monitored by c/r or studio selectors
Stereo Allows an external source to be monitored by c/r or studio selectors
Type Comments
Mono Typical installations have 4 or 8 microphone sources per studio
Stereo Typical installations have 16 analog line sources per studio
Stereo Typical installations have 16 digital line sources per studio
Type Comments
Mono Mono mix-minus output feeds the left side of a stereo connection. "Talk to..."
function enabled.
Mono Mono mix-minus output feeds the right side of a stereo connection. "Talk to..."
function disabled.
Stereo Individual headphone feed (for talent and guest mics) with *Talk to x* function
enabled.
