web page, select the same channel number for each
output as was used for the corresponding input. Se-
lect "To source" for the Type and configure for "Fast
Stream" audio mode.
5. Open the Element Sources & Profiles Configuration
web page. Choose Source Profiles, then Create New
Source Profile. In your new source profile, choose the
Primary Source that you entered in the audio node's
setup page. Give it an Element source name and se-
lect "Phone" for source type. Set the default input
mode to Left.
Operation
Load the hybrid source(s) onto the fader channels.
Use the control surfaces directly connected to the phone
system to select lines and place callers on the hybrids.
Faders will not be controlled by the hybrids via GPIO
and will need to be manually turned
needed.
Note: Dialing or generation of DTMF from the
Element keypad is not supported for these lega-
cy Telos phone systems.
and
as
ON
OFF
©2016 Axia Audio- Rev 1.8.1
