Axia element v.2.0 Installation & User Manual page 90

Figure 5-15: Monitor Options menu screen.
» Pushing the
TALK LEV
tween adjusting the levels of the
and levels and the
To Dim
The active function is highlighted in yellow on
the screen. Turn the knob to adjust the values of
these settings.
» Rotate the knob to choose whether
HP LINK
the headphone source will follow the Monitor
1 source selection. Push the knob to
selection.
means that Headphone and Monitor
*
Linked
1 selections will mirror each other; making a
selection from one bank of keys on the Moni-
tor Module will automatically choose the
same source on the other bank.
allows Monitor 1 and Headphone
*
Unlinked
sources to be selected independently of each
SoftKnob selects be-
Monitor 1 Talk
level.
Monitor 2 Dim
your
Take
©2016 Axia Audio- Rev 1.8.1
other.
The strongest link: You've noticed that there
are no Direct Selection Keys for the headphone
source on the Monitor + 2-Fader Module. By de-
fault, CR Headphones and Monitor 1 sources are
linked - the phones will play whatever source is
assigned to the monitor speakers. So how can
the operator select a headphone source if s/he
chooses to Unlink the headphones?
When Unlinked is chosen in the Headphones
Follow Monitors box, the Preview knob doubles
as the headphone source selector. When the
operator pushes the Preview knob, the Head-
phone Source menu is displayed. Voila!
» The knob allows the board op to turn
H/P PROC
Headphone Processing on and off, define how it
operates if active, and change Headphone Pro-
cessing settings. These controls are adjusted in a
manner similar to Channel Options EQ settings.
» Pushing the
HP Proc
onscreen and takes the operator to the
tings
screen shown in Figure 5-16. In this
Process
screen, the operator is presented with a graphi-
cal representation of the EQ curve applied to the
headphone channel. Talent can then apply three-
band parametric equalization to his or her head-
phone channel, and select headphone dynamics
processing. The screen indicates the amount of
cut/boost applied, and the center frequency of
each band.
»
Lo Gain/Bypass/Active:
Knob adjusts the amount of gain or cut applied
to the low EQ band. Pressing this knob toggles
EQ between and
Active
EQ mode for this band automatically changes
to Peak mode when boost is applied, and Shelf
mode when cut is applied.
* Rotating the
Lo Freq
frequency of the low EQ band (20 - 320 Hz).
* Rotating the
Mid Gain
Knobs adjust gain and center frequencies of
the midrange EQ band (125 Hz - 2 kHz).
* The knob adjusts the boost/cut of the
Hi Gain
high frequency band (1.25 kHz - 20 kHz).
*
Hi Freq/Shelf/Peak:
knob selects
Change Set-
H/P
Rotating this Soft-
Note that the
Bypass.
knob adjusts the center
and Soft-
Mid Freq
Rotating this Soft-
