Axia element v.2.0 Installation & User Manual page 72

Element with 2-Fader Phone Module and 2-Fader + Monitor Module
1 2
7 8
can accommodate any input source. Each
1.
Faders
channel's button (at the top of the fader
Options
strip) lets operators change sources and call up ex-
panded channel features.
2.
Assignment Buttons
put buses – Program-1, Program-2, Program-3
and Program-4/Record – are located atop each
fader strip.
contain a 10-character text
3.
Channel Displays
readout and a window for fader position numbers
and Status Symbol icons. Text is fixed for static
sources like microphones and CD players, but can
be set to show song/artist information, etc., when
computer-based audio sources are connected.
lets operators dial phone sys-
4.
Numeric Keypad
tems or codecs directly. Also provides numeric
input during surface setup.
are context sensitive; when any
5.
Three SoftKnobs
Direct Access key is pressed, the on-screen dis-
play shows the function affected by rotating and/
or pushing each knob.
6.
Record Mode and Load Profile Keys
tors recall customized Show Profiles and activate
3
9
for the four stereo main out-
let opera-
©2016 Axia Audio- Rev 1.8.1
4
10
Record Mode to quickly capture off-air bits to an
external recording device.
7.
Talkback & Preview Keys
(cue) selected sources off-air, or quickly talk to any
source(s) with associated backfeed(s).
8.
2-Fader Phone Module
of all hybrid and line control functions for Telos
Nx12, TWOx12 or Series 2101 Broadcast Talk-
show Systems.
help keep track of on-screen
9.
Timer Controls
elapsed and remaining time displays.
10.
Monitor 1 Section
tion controls for monitors, headphones, Aux Send
buses and Preview.
11.
Monitor 2 Talkback & Volume Controls
erators easily talk to hosts and guests in a second
studio, and control their monitor volume.
12.
Headphone and Preview Volume Controls
operators adjust Host headphone volume and con-
trol Preview (cue) volume and options.
5
12
11
let operators preview
provides direct control
contains volume and selec-
let op-
let
6
