Axia element v.2.0 Installation & User Manual page 73

1 2
7 8
for each of Element's four
1.
Program Meters
stereo Program buses feature true VU meter bal-
listics with an expanded scale. Solid bar graphs
indicate average level; the red line at -20dBFS cor-
responds to the 0dB mark on a traditional analog
meter. Other international standards are available.
indicates absolute peaks to show
2.
Peak Indicator
talent where the loudest portions of program mate-
rial are landing on the VU scale. (This indicator
may be switched off if desired.)
3.
Peak Indicator Warning
peaks reach or exceed 0dBFS.
4.
Day/Date and Digital Clock
formed of what day it is (in case they forget, which
is entirely normal). Clock can be set for 12- or 24-
hour operation, and can be slaved to a networked
NTP server if desired.
presents a traditional clock face
5.
Analog Clock
with second hand for fast orientation.
normally shows the volume of
6.
Utility Meter
sources assigned to the
multifunction bus, but can optionally be slaved to
meter whatever source is auditioned in the Control
Room Monitors.
Element Stereo Main Screen Overview
3
9
illuminates when
keep operators in-
PGM-4/Phone/Record
©2016 Axia Audio- Rev 1.8.1
4
10
informs operators when Mic
7.
Annunciator Panel
channels are open, when audio is being auditioned
in the Preview (cue) channel, when Talkback is ac-
tive in either direction, and when external profan-
ity delay units (if any) are active.
8.
Countdown Ring
Countdown Timer is active, and decreases during
the last :60 seconds as a visual prompt.
9.
Count Up and Countdown Timers
automatic event timer with manual elapsed-time
function, and a countdown timer to assist in back
timing live program material.
10.
Monitor Selection Indicators
source is being presented in the Control Room
and Studio Monitor channels, the CR Headphone
channel and the Preview channel, and shows the
position of each volume control when adjusted.
11.
External Monitor Indicators
es are assigned to each of the two programmable
External Monitor channels.
12.
Show Profile Indicator
Profile is currently loaded, and whether the con-
sole has been changed from Profile settings.
5
12
11
appears when Element's
provide an
show talent what
show what sourc-
tells talent what Show
6
