Axia element v.2.0 Installation & User Manual page 16

»
2nd NTP Server IP Address:
software supports redundant NTP servers. Enter
the IP Address of your backup server here.
»
Web Page User Password:
protect your Element's web server connection by
entering a short numeric password here.
Note: If you set a password for HTTP access,
you will not see your password displayed in this
field upon re-entering the IP Address book. This
is a security feature intended to prevent "over-
the-shoulder" password theft.
• If you want to reverse changes you've made and
haven't saved, press the
• Press to save changes you've made.
Save
• Press to immediately reboot the Ele-
Reboot
ment.
• You can press
Exit
at any time without saving your changes.
Note: After making changes to any Element IP
address settings, you must reboot the console.
Use the "REBOOT" soft key to begin an immediate
reboot sequence.
Remember, you can even reboot Element while
on-the-air, since the audio mixing is not done in
the console but in the Studio Engine; your audio
will continue to play without interruption.
Setting IP using the 2-Fader Monitor Module
When Element has completed its start cycle (meter
screen appears), find the numeric keypad at the top right
of the Monitor Module. Press and hold the *
& keys simultaneously for five seconds to enter the
"4"
IP Address Book (Figure 1-12).
To set the IP address, rotate the left-most SoftKnob
to highlight the line titled "Element IP Address" and
push the knob to select that line. Now use the numeric
pad to enter the IP address. Press the left-most SoftKnob
again to "take" the new IP value. Repeat this process to
set the subnet mask value.
Continue down the screen and, in the same way, enter
the other fields' values as appropriate.
• Rotate the
Select/Set
Element v2.x
You can password-
knob to erase them.
Undo
to leave the IP Address Book
,
(star)
SoftKnob to scroll through
©2016 Axia Audio- Rev 1.8.1
the list of available options. To select an option to
modify, push this knob. While modifying an options,
rotate the knob to change an option's value, and push
the knob to move to the next field. Available options
include:
»
Element IP Address:
gear must have its own unique IP Address. Set
the IP Address for each Element in this field.
»
Subnet Mask:
mask value here, usually 255.255.255.0
»
Gateway IP Address:
istration of your Livewire network, you'll need a
network gateway. If you have one installed, enter
its IP Address value here.
»
Engine IP Address:
controls a unique Studio Engine. Enter the IP of
the controlled Engine here.
»
1st NTP Server IP Address:
NTP (Network Time Protocol) timekeeping to
synchronize time-of-day clocks across your fa-
cility. If you have an NTP server, enter its IP Ad-
dress here.
"7"
Figure 1-12: IP Address Book,
Every piece of Livewire
Enter your network's subnet
To enable remote admin-
Each Axia control surface
Element supports
Monitor Module
