Important: Your Gateway Subnet Mask should
be set within the same subnet as the PowerSta-
tion, even if you have no gateway installed.
»
Engine IP Address:
tion - do not change the factory default value.
»
1st NTP Server IP Address:
NTP (Network Time Protocol) timekeeping to
synchronize time-of-day clocks across your fa-
cility. If you have an NTP server, enter its IP Ad-
dress here.
»
2nd NTP Server IP Address:
software supports redundant NTP servers. Enter
the IP Address of your backup server here.
»
Web Page User Password:
protect your Element's web server connection by
entering a numeric password here.
Note: If you set a password for HTTP access,
you will not see your password displayed in this
field upon re-entering the IP Address book. This
is a security feature intended to prevent "over-
the-shoulder" password theft.
If you want to reverse changes you've made and
haven't saved, press the
them.
Press
to save changes you've made.
Save
immediately reboots the PowerStation.
Reboot
Note: After making changes to any Element IP
address settings, you must reboot the console.
Use the "REBOOT" soft key to begin an immedi-
ate reboot sequence.
Setting IP using the Monitor+ 2-Fader Module
When the PowerStation has completed its start cycle
(meter screen appears), find the numeric keypad at the
top right of the Monitor Module. Press and hold the *
,
&
keys simultaneously for five seconds
(star)
"7"
"4"
to enter the IP Address Book (Figure 2-15).
To set the IP address, rotate the left-most SoftKnob
to highlight the line titled "Element IP Address" and
push the knob to select that line. Now use the numeric
pad to enter the IP address. Press the leftmost SoftKey
again to "take" the new IP value. Repeat this process to
set the subnet mask value.
Not required for PowerSta-
Element supports
Element v2.x
You can password-
knob to erase
Undo
©2016 Axia Audio- Rev 1.8.1
Figure 2-15: IP Address Book
Continue down the screen and, in the same way, enter
the other fields' values as appropriate.
• Rotate the
Select/Set
the list of available options. To select an option to
modify, push this knob. While modifying an options,
rotate the knob to change an option's value, and push
the knob to move to the next field. Available options
include:
»
Element IP Address:
gear must have its own unique IP Address. Set the
IP Address for each Element in this field.
Enter your network's subnet
»
Subnet Mask:
mask value here, usually 255.255.255.0
»
Gateway IP Address:
tion and remote administration of your Livewire
network, you'll need a network gateway. Usually
this will be the IP address of your router.
SoftKnob to scroll through
Every piece of Livewire
To enable IP configura-
