Source-Specific Channel Controls

Some fader functions change their behavior to suit
the type of source assigned to the fader. A Guest Mic in-
put has unique functions different from those of a Codec
input, and so forth. In this section we'll explain the chan-
nel functions unique to each type of source input.
Control Room Operator Mic Channel Operation
The Control Room Operator microphone is the board
operator's mic. It's always located in the Control Room,
so activating a channel designated as the CR Operator
mic affects CR monitor speaker (Monitor 1) and Pre-
view speaker muting.
When the board operator pushes a
output bus assignments for the Control Room Operator
microphone are temporarily muted, while his mic's au-
dio is routed to the requested
leasing the button returns the channel outputs to normal.
(Pushing your own
Talkback
Pressing the channel
Mic while the channel is already on will mute the chan-
nel until the button is released, acting as a "cough" func-
tion for the board operator. On-air status and speaker
mutes are unaffected by this action. The CR Operator
microphone channel will mute the CR Monitors (Moni-
tor 1) and the Preview speakers whenever the channel is
or if or
On, Preview Record Mode Engage
selected.
Producer Microphone Channel Operation
The Producer's microphone is meant to be used at
*+C
Press and hold the
* (star)
* (star)
key, all
Talkback
destination. Re-
Talkback
key does nothing.)
key for the CR Operator
ON
keys are
