between Active and Bypass states.
sets the amount of sibilance re-
»
De-Ess Ratio
duction, in dB, that will be applied (adjustable
between 1:1 and 8:1).
»
Post Processing Gain
applied after processing. This can compensate
for gain that may be lost during compression.
» Pressing the
Dynamics & EQ
turn you to the
Channel Options
•
Pan & Mode Key
This function allows the operator to adjust the pan or
balance of the channel source and correct signal phase
errors.
Figure 5-11: Pan / Mode menu screen.
It's a Lock: If a "padlock" icon appears in any
sets the amount of gain
key again will re-
screen.
©2016 Axia Audio- Rev 1.8.1
options screen, that function is "locked out" in
the Source Profile and adjustments cannot be
made. In Figure 5-11, the padlock appears just
below the soundfield representation, above the
Mode indicator. The onscreen Mode SoftKnob
is also "grayed out" to show that this function
is unavailable.
Operators cannot "unlock" locked functions;
if you wish to make locked functions available,
simply modify the source profile to allow them
and when the source is reloaded to the console,
the padlock will have disappeared.
(2-Fader Monitor module only)
» Function/Exit:
This control changes the other control operates -
Pan, Mode or Phase. Pressing this knob will exit
the Pan/Mode Menu screen.
Rotating this SoftKnob adjusts
»
Pan/Balance:
the Pan setting for mono sources and the Balance
setting for stereo sources.
: If the selected source is in stereo and
»
Mode
the Source Profile for the selected source per-
mits it (see Chapter 3 for information on Source
Profiles), rotating this control lets the board op
switch source audio between
left/right), (left source channel fed to L/R
Left
input), (right source channel fed to L/R
Right
input) and (left and right source channels
Sum
summed to mono and fed to L/R input). Push to
the new setting.
Take
: If the selected source is stereo, rotating
»
Phase
this control lets the board op compensate for
out-of-phase audio sources.
in-phase sources;
Inv Left
the left input channel only,
the phase of the right input channel only, and
reverses phase of both stereo channels.
vert Both
If the selected source is in mono, the choices are
and
Normal Invert
setting.
» Pressing
Pan & Mode
nel Options screen.
»
Aux Sends Key
Element has four stereo Aux buses that can be used
as utility buses for mixing, for constructing custom IFB
mixes, or as effects buses for production. Pressing this
(discrete
Stereo
is used for
Normal
inverts the phase of
inverts
Inv Right
In-
only. Press to the new
Take
again returns to the Chan-
