Axia element v.2.0 Installation & User Manual page 87

bus when the channel is
the Program-1 bus when the channel is
with mix-minus if needed.
backfeeds audio from the Phone bus,
*
Phone
with mix-minus if needed.
*
Program 1 - Program 4
from the selected Program bus, with mix-
minus if needed.
*
Aux Send 1 - Aux Send 4
from the selected Auxiliary bus, with mix-
minus if needed.
About the PHONE and PROGRAM 4 buses:
Element's Program 4 mix bus is a special multi-
purpose bus that does several things at once to
make life easier for the operator.
Any source assigned to Program 4 also be fed
to the PHONE bus and sent to callers when the
channel is OFF and AUTO is selected as the
Feed To Source Mode. PHONE is an internal bus
which does not feed a separate output; instead,
it picks up the Program 4 audio pre-fader and
pre-On/Off and backfeeds them to an PHONE
sources.
Sources assigned to Program 4 are also sent to
the RECORD bus, a special fixed-level output
that can be used to feed recording devices. This
RECORD bus is post fader and pre on/off.
» Rotating the
Dim
adjust, in dB, the amount by which the studio
monitors are dimmed when this fader channel's
key is pressed.
Talkback
» Pressing
Feed to Source
time exits this menu.
» The knob, when rotated will control the
DIM/OFF
amount of program dimming that occurs during
Talkback. Pushing this control will select OFF which
completely mutes the backfeed program during
talkback.
Delay Section
These keys can be used to
provide from-the-board control of an external profanity
delay unit using one of Element's GPIO ports. Please
refer to Chapter 4: "Configuring GPIO" for instructions
, and audio from
Off
On
backfeeds audio
backfeeds audio
knob allows the operator to
or a second
Options
©2016 Axia Audio- Rev 1.8.1
on GPIO setup.
,
The keys provide for remote activation of
and
Exit, Pause Engage
Some enterprising individuals have found other used
for these keys. If they are not being used to control an ex-
ternal delay unit, our PathfinderPC software can monitor
these keys and perform various actions upon detecting
these button presses. Some of these uses have included
custom IFB, one-button show profile load, VMIX con-
trol . . the possibilities are virtually infinite!
Monitor Section
This controls in this section provide direct operator
access to monitor selection and volume controls.
•
Monitor 1 Knob + Source Keys
This knob, at the bottom left of the Monitor section,
controls the selection and volume of the source heard
in the speakers (typically the Control Room
Monitor 1
monitors).
» Rotate the knob to vary the gain of the
speakers.
1
» Use the Direct Selection Keys in the column
directly above the
output of
Program 1 - Program 4, Aux Send
A - Aux Send D,
sources to the Monitor 1 speakers. These keys
light to denote the selected source.
» You can listen to any frequently-used audio
stream in your facility instantly (such as a net-
work feed, off-the-air monitor or another studio's
Program output) by assigning it to one of the two
selector keys - like preset buttons on a
External
car radio.
Programming the External Monitor Selec-
tor keys: If you press and hold either of these
keys for five seconds, a list of available audio
streams will pop up onscreen. You can then
scroll through this list and select the source you
want to hear in the monitors when that key is
pressed. Each External key is independently
programmable.
Dump,
functions, respectively.
Monitor
knob to send the
Monitor 1
or the two monitor
External
