Appendix A:
Main Outputs
Program-1
Program-2
Program-3
Program-4/Record
Aux Inputs and Outputs
Aux Send-1 Output
Aux Send-2 Output
Aux Return-1 Input
Aux Return-2 Input
Monitor-related Outputs
C/R Monitor Main
C/R Monitor Direct
Main Headphone
Studio Monitor Main
Studio Headphone Talent
Studio Headphone Guest
Preview
Talk to External
Talk to CR Audio
Monitor-related Inputs
External Preview Input
External Monitor Input 1
External Monitor Input 2
External Monitor Input 3
External Monitor Input 4
Source Inputs
Microphone Input n
Analog Line Input n
Digital Line Input n
Source-related Outputs
Feed-to-Source A n
Feed-to-Source B n
Individual Hdphone Feed n
Table of Inputs and Outputs
Type Comments
Stereo Main stereo bus (Usually refered to as Program)
Stereo Second stereo bus (Sometimes refered to as Audition)
Stereo Third stereo bus (Sometimes refered to as Utility), signal post fader, before
on/off.
Stereo Fourth stereo bus (Sometimes referred to as Auxiliary), signal pre-fader, before
on/off.
Type Comments
Stereo Aux send bus can be used for processing or independent mixes
Stereo Aux send bus can be used for processing or independent mixes
Stereo Allows processing to be folded back into a mix
Stereo Allows processing to be folded back into a mix
Type Comments
Stereo Control room monitor speakers, source and level controlled by SS c/r monitor
control
Stereo Control room monitor output, source same as main, fixed level output
Stereo Control room (board op) headphone, source and level controlled by SS head-
phone control
Stereo Studio monitor speakers, source and level controlled by SS studio monitor con-
trol
Stereo Studio (talent) headpones, source same as main, fixed level output, with
talkback
Stereo Studio (guest) headphones, source same as main, fixed level output, no talkback
Stereo Allows the connection of external powered speakers.
Mono Allows board operator mic to talk to other devices, a logic command is associated
Mono Allows the Talk to CR audio mix to drive an external destination
Type Comments
Stereo Allows an external path into the preview speakers, a logic command is associated
Stereo Allows an external source to be monitored by c/r or studio selectors
Stereo Allows an external source to be monitored by c/r or studio selectors
Stereo Allows an external source to be monitored by c/r or studio selectors
Stereo Allows an external source to be monitored by c/r or studio selectors
Type Comments
Mono Typical installations have 4 or 8 microphone sources per studio
Stereo Typical installations have 16 analog line sources per studio
Stereo Typical installations have 16 digital line sources per studio
Type Comments
Mono Mono mix-minus output feeds the left side of a stereo connection. "Talk to..."
function enabled.
Mono Mono mix-minus output feeds the right side of a stereo connection. "Talk to..."
function disabled.
Stereo Individual headphone feed (for talent and guest mics) with *Talk to x* function
enabled.
