B
APPENDIX
SPARCstation 5 Input/Output
Connectors
This appendix contains pinouts and illustrations of the SPARCstation 5 system
input/output (I/O) connectors. The following connectors are described.
4 "SCSI Connector (External)" on page 137
4 "Parallel Port Micro-D Connector" on page 139
4 "Attachment Unit Interface (AUI) Micro-D Connector" on page 140
4 "Twisted-Pair Ethernet Connector" on page 141
4 "Serial Connector Ports A and B" on page 141
4 "Keyboard/Mouse Connector" on page 142
4 "Audio Ports" on page 143
4 "13W3 Video Connector" on page 145

SCSI Connector (External)

Figure B–1 External SCSI Connector
137
