Page 1 Cat. No. I532-E1-1 USER’S MANUAL SYSDRIVE 3G3RV High-function General-purpose Inverters...
Page 2: General Precautions
Make sure that these protective covers are on the product before use. Consult your OMRON representative when using the product after a long period of storage. !WARNING Do not touch the inside of the Inverter. Doing so may result in electrical shock.
Page 3: Installation Precautions
Transportation Precautions !Caution Do not hold by front cover or panel, instead, hold by the radiation fin (heat sink) while transporting the product. Doing so may result in injury. !Caution Do not pull on the cables. Doing so may result in damage to the product or malfunc- tion.
Page 4 !Caution Be sure to wire correctly and securely. Not doing so may result in injury or damage to the product. !Caution Be sure to firmly tighten the screws on the terminal block. Not doing so may result in fire, injury, or damage to the product. !Caution Do not connect any power source to the U, V, or W output.
Page 5 Maintenance and Inspection Precautions !WARNING Do not touch the Inverter terminals while the power is being supplied. !WARNING Maintenance or inspection must be performed only after turning OFF the power sup- ply, confirming that the CHARGE indicator (or status indicators) is turned OFF, and after waiting for the time specified on the front cover.
Page 6 Warning Information and Position There is warning information on the Inverter in the position shown in the following illustration. Always heed the warnings. Warning information position Warning information position Illustration shows the 3G3RV-B2220 Illustration shows the 3G3RV-A2004 Warning Information For ASIA Model (No suffix) For Europe (-E suffix) Models WARNING WARNING...
Page 7 Registered Trademarks The following registered trademarks are used in this manual. DeviceNet is a registered trademark of the ODVA (Open DeviceNet Vendors Association, • Inc.). • MODBUS is a trademark of the AEG Schneider Automation, Inc.
Page 8: Table Of Contents
Contents Handling Inverters ..............1-1 SYSDRIVE RV Introduction................1-2 SYSDRIVE RV Applications ................... 1-2 RV-series Inverter Models ....................1-2 Differences by Model..................1-4 Differences in Hardware ....................1-4 Differences in Software (Function, Factory Setting, and Setting Range) ....... 1-4 Confirmations upon Delivery ................1-7 Checks..........................1-7 Nameplate Information ....................1-7 Component Names......................
Page 9 Terminal Arrangement for European Models..............2-7 Terminal Functions ......................2-8 Wiring Main Circuit Terminals..............2-14 Applicable Wire Sizes and Closed-loop Connectors ............ 2-14 Main Circuit Configurations ..................2-19 Standard Connection Diagrams ................... 2-20 Wiring the Main Circuits....................2-21 Wiring Control Circuit Terminals for Asian Models ........2-29 Wire Sizes and Closed-loop Connectors..............
Page 10 Trial Operation Procedures................4-4 Application Confirmation....................4-4 Setting the Power Supply Voltage Jumper (400-V Class Inverters of 75 kW or Higher) 4-4 Power ON ........................4-4 Checking the Display Status ................... 4-5 Initializing Parameters ....................4-5 Basic Settings ......................... 4-7 Settings for the Control Methods ..................4-9 Autotuning........................4-11 Application Settings ......................
Page 11 Stopping Methods ..................6-14 Selecting the Stopping Method..................6-14 Using the DC Injection Brake ..................6-17 Using a Deceleration Stop from an External Input ............6-18 Acceleration and Deceleration Characteristics .......... 6-19 Setting Acceleration and Deceleration Times............... 6-19 Accelerating and Decelerating Heavy Loads (Dwell Function) ........6-22 Preventing the Motor from Stalling During Acceleration (Stall Prevention During Acceleration Function)............
Page 12 Blocking Inverter Outputs (Baseblock Commands) ............6-63 Stopping Acceleration and Deceleration (Acceleration/Deceleration Ramp Hold) ..6-64 Raising and Lowering Frequency References Using Contact Signals (UP/DOWN)..6-65 Accelerating and Decelerating Constant Frequencies in the Analog References (+/- Speed)........................6-68 Hold Analog Frequency Using User-set Timing............6-69 Switching Operations between a Communications Option Card and Control Circuit Terminals ..................
Page 13 If the Motor Operates Higher Than the Reference ............7-18 If the Slip Compensation Function Has Low Speed Precision ........7-19 If There Is Low Speed Control Accuracy at High-speed Rotation in Open-loop Vector Control Mode ................7-19 If Motor Deceleration Is Slow ..................7-19 If the Motor Overheats....................
Page 14 Wiring Examples..................10-7 Using a Braking Resistor Unit..................10-7 Using a Braking Unit and Braking Resistor Unit ............10-7 Using Braking Units in Parallel ..................10-8 Using a Braking Unit and Three Braking Resistor Units in Parallel ......10-9 Using an Analog Operator ..................10-10 Using Transistors for Input Signals and a 0-V Common in Sinking Mode with an Internal Power Supply....................
Page 15: Handling Inverters
Chapter 1 Handling Inverters This chapter describes the checks required upon receiving or installing an Inverter. SYSDRIVE RV Introduction.........1-2 Differences by Model ........... 1-4 Confirmations upon Delivery........1-7 Exterior and Mounting Dimensions......1-12 Checking and Controlling the Installation Site ...1-15 Installation Orientation and Space ......1-16 Removing and Attaching the Terminal Cover ....
Page 16: Sysdrive Rv Introduction
SYSDRIVE RV Introduction K K K K SYSDRIVE RV Applications The SYSDRIVE RV is ideal for the following applications. Fan, blower, and pump applications • • Conveyors, pushers, metal tooling machines, etc. Settings must be adjusted to the application for optimum operation. Refer to Chapter 4 Trial Operation. K K K K RV-series Inverter Models RV-series Inverters have different models and specifications by the area (Asia and Europe) to support widely...
Page 17 SYSDRIVE RV Introduction Protective Maximum Applied Motor Model Model Structure Capacity (Asia) (Europe) 22 kW 3G3RV-B2220 3G3RV-B2220-E 30 kW 3G3RV-B2300 3G3RV-B2300-E 37 kW 3G3RV-B2370 3G3RV-B2370-E 45 kW 3G3RV-B2450 3G3RV-B2450-E Open Chassis type IP00 55 kW 3G3RV-B2550 3G3RV-B2550-E 75 kW 3G3RV-B2750 3G3RV-B2750-E 90 kW 3G3RV-B2900...
Page 18: Differences By Model
Differences by Model The RV-series products differ in specifications by model. This section explains the differences. K K K K Differences in Hardware For details, refer to Chapter 3 The Digital Operator and Chapter 2 Wiring. Table 1.3 Differences in Hardware Europe Asia (suffixed -E)
Page 19 Differences by Model Table 1.4 Differences in Software (Continued) Europe Name Parameter Number Asia * * * * suffixed -E C4-03/C4-04: Set the rated torque of the motor. C4-03 to C4-05: Set the time constant (ms) for Torque value setting Disabled C4-05 the rising start torque value.
Page 20 Table 1.4 Differences in Software (Continued) Europe Name Parameter Number Asia * * * * suffixed -E LCD brightness Setting Range: 0 to 5 o1-05 Cannot change. adjustment Adjusts the brightness in five steps. Operation selection Factory setting Factory setting when Digital Opera- o2-06 0 (Disabled)
Page 21: Confirmations Upon Delivery
Use a screwdriver or other tools to check for tightness. loose? If you find any irregularities in the above items, contact the dealer from which you purchased the Inverter or your OMRON representative immediately. K K K K Nameplate Information There is a nameplate attached to the side of each Inverter.
Page 22 nInverter Model Numbers The model number of the Inverter on the nameplate indicates the specifications, voltage class, and maximum motor capacity of the Inverter in alphanumeric codes. 3G3RV - A 2 037 -E Specifications None Asian model European model Maximum Applicable Motor Capacity 5.5 kW 22 kW 75 kW...
Page 23: Component Names
Confirmations upon Delivery K K K K Component Names n Inverter Appearance The external appearance and component names of the Inverter are shown in Figs. 1.3. and 1.4 Top protective cover Mounting hole Front cover Digital Operator Diecast case Terminal cover Nameplate Bottom protective cover Fig 1.3 18.5 kW or Less...
Page 24 nTerminal Arrangement for Asian Models Views with the terminal cover removed are shown in Figs. 1.5 and 1.6. E (G) RP R+ R- S+ S- MB MC M2 E (G) Control circuit terminals Main circuit terminals Charge indicator Ground terminal Fig 1.5 18.5 kW or Less Charge indicator Control circuit...
Page 25 Confirmations upon Delivery nTerminal Arrangement for European Models Views with the terminal cover removed are shown in Figs. 1.7 and 1.8. -V -V E(G) E(G) E(G) E(G) Control circuit terminals Main circuit terminals Charge indicator Ground terminal Fig 1.7 18.5 kW or Less Control circuit terminals Charge indicator Main circuit terminals...
Page 26: Exterior And Mounting Dimensions
Exterior and Mounting Dimensions K K K K Open Chassis Inverters (IP00) Exterior diagrams of the Open Chassis Inverters are shown below. A. 200-V class Inverters of 22 to 30 kW B. 200-V class Inverters of 37 to 110 kW 400-V class Inverters of 22 to 55 kW 400-V class Inverters of 75 to 160 kW Fig 1.9 Exterior Diagrams of Open Chassis Inverters...
Page 27 Exterior and Mounting Dimensions Table 1.6 Open Chassis Type (IP00) Dimensions (mm) Caloric Value (W) Mount- Max. Motor Approx. Total Voltage Model Cooling Output Figure Mass Inter- Heat Class (-E included) Holes Method External (kW) (kg) Gener- ated 0.75 Natural Not available.
Page 28 Table 1.7 NEMA 1 Type (IP20) Dimensions (mm) Caloric Value (W) Max. Moun Approx. Total Voltage Motor Model ting Cooling Figure Mass Exter- Inter- heat Class Output (-E included) Holes Method (kg) gener- (kW) ated 3G3RV-A2004 0.75 3G3RV-A2007 Natural 3G3RV-A2015 126 280 266 3G3RV-A2022 3G3RV-A2037...
Page 29: Checking And Controlling The Installation Site
Checking and Controlling the Installation Site Checking and Controlling the Installation Site Install the Inverter in an installation site as described below and maintain optimum conditions. K K K K Installation Site Install the Inverter under the following conditions and in a pollution degree 2 environment. Table 1.8 Installation Site Type Ambient Operating Temperature...
Page 30: Installation Orientation And Space
Installation Orientation and Space !WARNING Provide an appropriate stopping device on the machine side to secure safety. (A hold- ing brake is not a stopping device for securing safety.) Not doing so may result in injury. !WARNING Provide an external emergency stopping device that allows an instantaneous stop of operation and power interruption.
Page 31: Digital Operator Panel Cutout Dimensions
Installation Orientation and Space K K K K Digital Operator Panel Cutout Dimensions Mounting panel Two M3 holes 14.5 Cutout 15.8 Fig 1.12 Digital Operator Panel Cutout Dimensions 1. The same space is required horizontally and vertically for both Closed Wall-mounting (IP20, NEMA 1)and Open Chassis (IP00) Inverters.
Page 32: Removing And Attaching The Terminal Cover
Removing and Attaching the Terminal Cover Remove the terminal cover to wire cables to the control circuit and main circuit terminals. K K K K Removing the Terminal Cover n Inverters of 18.5 kW or Less Loosen the screws at the bottom of the terminal cover, press in on the sides of the terminal cover in the direc- tions of arrows 1, and then lift up on the terminal in the direction of arrow 2.
Page 33: Removing/Attaching The Digital Operator And
Removing/Attaching the Digital Operator and Front Cover Removing/Attaching the Digital Operator and Front Cover The methods for removing and attaching the Digital Operator and front cover are described in this section. K K K K Inverters of 18.5 kW or Less To attach optional cards or change the terminal card connector, remove the Digital Operator and front cover in addition to the terminal cover.
Page 34 nRemoving the Front Cover Press the left and right sides of the front cover in the directions of arrows 1 and lift the bottom of the cover in the direction of arrow 2 to remove the front cover as shown in the following illustration. Fig 1.16 Removing the Front Cover (3G3RV-A4055 Shown Above) nMounting the Front Cover After wiring the terminals, mount the front cover to the Inverter by performing in reverse order the steps to...
Page 35: Inverters Of 22 Kw Or More
Removing/Attaching the Digital Operator and Front Cover 1. Do not remove or attach the Digital Operator or mount or remove the front cover using methods other than those described above, otherwise the Inverter may break or malfunction due to imperfect contact. 2.
Page 37: Wiring
Chapter 2 Wiring This chapter describes wiring terminals, main circuit terminal connections, main circuit termi- nal wiring specifications, control circuit terminals, and control circuit wiring specifications. Wiring................2-2 Connections to Peripheral Devices......2-3 Connection Diagrams ..........2-4 Terminal Block Configuration ........2-6 Wiring Main Circuit Terminals ........2-14 Wiring Control Circuit Terminals for Asian Models..
Page 38: Wiring
Wiring !WARNING Wiring must be performed only after confirming that the power supply has been turned OFF. Not doing so may result in electrical shock. !WARNING Wiring must be performed by authorized personnel. Not doing so may result in electri- cal shock or fire.
Page 39: Connections To Peripheral Devices
Connections to Peripheral Devices Connections to Peripheral Devices Examples of connections between the Inverter and typical peripheral devices are shown in Fig 2.1. Power supply Molded-case circuit breaker or ground fault interrupter Magnetic con- tactor (MC) AC reactor for power factor improvement Braking resistor Input noise filter...
Page 40: Connection Diagrams
Connection Diagrams The connection diagrams for the Inverter are shown in this section. K K K K Asian Models The connection diagram for Asian models is shown in Fig. 2.2. When using the Digital Operator, the motor can be operated by wiring only the main circuits. DC reactor to improve input power factor (optional) Braking Resistor Unit (optional) Short-circuit bar...
Page 41: European Models
Connection Diagrams K K K K European Models The connection diagram for the European models is shown in Fig. 2.3. DC reactor to improve input power factor (optional) Braking Resistor Unit (optional) Short-circuit bar MCCB U/T1 R/L1 3-phase power 200 to 240 V S/L2 V/T2 50/60 Hz...
Page 42: Terminal Block Configuration
Terminal Block Configuration K K K K Terminal Arrangement for Asian Models The terminal arrangement for Asian-model Inverters is shown in Fig 2.4 and Fig 2.5. E (G) RP R+ R- S+ S- MB MC M2 E (G) Control circuit terminals Main circuit terminals Charge indicator Ground terminal...
Page 43: Terminal Arrangement For European Models
Terminal Block Configuration K K K K Terminal Arrangement for European Models The terminal arrangement for European-model Inverters is shown in Fig 2.6 and Fig 2.7. Control circuit terminals Main circuit terminals Charge indicator Ground terminals Fig 2.6 18.5 kW or Less Control circuit terminals Charge indicator Main circuit terminals...
Page 44: Terminal Functions
K K K K Terminal Functions The functions of the main-circuit and control-circuit terminals are shown below. nAsian Models The terminal functions for the Asian-model Inverters are shown below. Main-circuit Terminals The functions for the main-circuit terminals by symbol are shown in Table 2.1. Be sure to wire correctly. Table 2.1 Main-circuit Terminal Functions Voltage Class 200-V Class...
Page 45 Terminal Block Configuration Control-circuit Terminals (Same for 200-V and 400-V Class) The functions for the control-circuit terminals by symbol are shown in Table 2.2. Table 2.2 Control-circuit Terminal Functions Signal Type Signal Name Terminal Function Signal Level Symbol Forward-stop command Forward when ON, stop when OFF Reverse-stop command Reverse when ON, stop when OFF...
Page 46 Communications-circuit Terminals (Same for 200-V and 400-V Class) The functions for the communications-circuit terminals by symbol are shown in Table 2.3. Table 2.3 Communications-circuit Terminal Functions Signal Type Signal Name Terminal Function Signal Level Symbol Differential input, RS-422A/485 receive data 422A/ For 2-wire RS-485, short R+ and photocoupler isolation...
Page 47 Terminal Block Configuration nEuropean Models The terminal functions for European model Inverters are described below. Main-circuit Terminals The functions of the main-circuit termina.s by symbol are shown in Table 2.4. Be sure to wire correctly. Table 2.4 Main-circuit Terminal Functions Voltage Class 200-V Class 400-V Class...
Page 48 Control-circuit Terminals (Same for 200-V and 400-V Class) The functions for the control-circuit terminals by symbol are shown in Table 2.5. Table 2.5 Control-circuit Terminal Functions Signal Type Signal Name Terminal Function Signal Level Symbol Forward-stop command Forward when ON, stop when OFF Reverse-stop command Reverse when ON, stop when OFF Factory setting: External fault...
Page 49 Terminal Block Configuration Table 2.5 Control-circuit Terminal Functions (Continued) Signal Type Signal Name Terminal Function Signal Level Symbol Factory setting: Frequency refer- Pulse Multi-function pulse input 0 to 32 kHz (3 kΩ) ence input (H6-01 = 0) Input/Out- Factory setting: Output frequency Multi-function pulse monitor 0 to 32 kHz (2.2 kΩ) (H6-06 = 2)
Page 50: Wiring Main Circuit Terminals
Wiring Main Circuit Terminals K K K K Applicable Wire Sizes and Closed-loop Connectors Select the appropriate wires and crimp terminals from Table 2.7 to Table 2.9 (same for all countries). Refer to USER’S MANUAL (I526-E1-o) for wire sizes for Braking Resistor Units and Braking Units. Table 2.7 200-V class Wire Sizes Recom- Ter-...
Page 51 Wiring Main Circuit Terminals Recom- Possible Inverter Termi- Tightening mended Wire Wire Sizes Model Terminal Symbol Torque Wire Size Type 3G3RV- Screws (N•m) (AWG) (AWG) 60 to 100 R/L1, S/L2, T/L3, 1 U/T1, 17.6 to 22.5 (2/0 to 4/0) (2/0) V/T2, W/T3, R1/L11, S1/L21, T1/L31 5.5 to 22 8.8 to 10.8...
Page 52 Table 2.8 400-V class Wire Sizes Recom- Possible mended Inverter Termi- Tightening Wire Sizes Wire Size Model Terminal Symbol Torque Wire Type 3G3RV Screws (N•m) (AWG) (AWG) R/L1, S/L2, T/L3, 2, B1, B2, 2 to 5.5 U/T1, V/T2, W/T3 A4004 1.2 to 1.5 (14 to 10) (14)
Page 53 Wiring Main Circuit Terminals Recom- Possible mended Inverter Termi- Tightening Wire Sizes Wire Size Model Terminal Symbol Torque Wire Type 3G3RV Screws (N•m) (AWG) (AWG) 38 to 60 R/L1, S/L2, T/L3, 1, U/T1, V/T2, 9.0 to 10.0 (2 to 1/0) W/T3, R1/L11, S1/L21, T1/L31 8 to 22 B4450...
Page 54 Table 2.9 Closed-loop Connector Sizes (JIS C2805) (200-V class and 400-V class) Terminal Screws Size Wire Thickness (mm M3.5 1.25 to 3.5 1.25 to 4 M3.5 1.25 to 3.5 0.75 1.25 to 4 M3.5 1.25 to 3.5 1.25 1.25 to 4 M3.5 2 to 3.5 2 to 4...
Page 55: Main Circuit Configurations
Wiring Main Circuit Terminals K K K K Main Circuit Configurations The main circuit configurations of the Inverter are shown in the table below. Table 2.10 Inverter Main Circuit Configurations 200-V Class 400-V Class 3G3RV-A2004 to A2185 3G3RV-A4004 to A4185 U/T1 U/T1 R/L1...
Page 56: Standard Connection Diagrams
K K K K Standard Connection Diagrams Standard Inverter connection diagrams are shown in Fig 2.8. The connections depend on the Inverter capacity. n3G3RV-A2004 to A2185, A4004 to A4185 n3G3RV-B2220, B2300, B4220 to B4550 Braking Resistor Unit (optional) Braking Resistor DC reactor Unit (optional) Braking Unit...
Page 57: Wiring The Main Circuits
Wiring Main Circuit Terminals K K K K Wiring the Main Circuits This section describes wiring connections for the main circuit inputs and outputs. nWiring Main Circuit Inputs Observe the following precautions for the main circuit power supply input. Installing a Molded-case Circuit Breaker Always connect the power input terminals (R, S, and T) and power supply via a molded-case circuit breaker (MCCB) suitable for the Inverter.
Page 58 Installing a Magnetic Contactor If the power supply for the main circuit is to be shut off during a sequence, a magnetic contactor can be used. When a magnetic contactor is installed on the primary side of the main circuit to forcibly stop the Inverter, however, the regenerative braking does not work and the Inverter will coast to a stop.
Page 59 Wiring Main Circuit Terminals Incorrect Noise Filter Installation • Power 3G3RV MCCB supply Inverter MCCB General- Other purpose controllers noise filter Example: SYSMAC Power MCCB 3G3RV supply General- purpose Inverter noise filter MCCB Other Do not use general-purpose noise filters. No general- controllers purpose noise filter can effectively suppress noise generated from the Inverter.
Page 60 When using an MC to switch to a commercial power supply, stop the Inverter and motor before operating the MC. Use the speed search function if the MC is operated during operation. If measures for momentary power interrupts are required, use a delayed release MC. Installing a Thermal Overload Relay This Inverter has an electronic thermal protection function to protect the motor from overheating.
Page 61 Wiring Main Circuit Terminals Countermeasures Against Radio Interference Radio noise is generated from the Inverter as well as from the input and output lines. To reduce radio noise, install noise filters on both input and output sides, and also install the Inverter in a totally enclosed steel box. The cable between the Inverter and the motor should be as short as possible.
Page 62 nConnecting the Braking Resistor (Mounting 3G3IV-PERF) A Braking Resistor that mounts to the Inverter can be used with 200-V and 400-V Class Inverters with outputs from 0.4 to 11 kW. Connect the braking resistor as shown in Fig 2.16. Table 2.12 L8-01 (Protect selection for internal DB resistor) 1 (Enables overheat protection) 0 (Disables stall prevention function)
Page 63 Wiring Main Circuit Terminals To prevent the Unit from overheating, design the sequence to turn OFF the power supply for the thermal over- load relay trip contacts of the Unit as shown in Fig 2.17. 200-V and 400-V Class Inverters with 0.4 to 18.5 kW Output 3G3IV-PLKBo Braking Resistor Unit Thermal overload...
Page 64 Braking resistor overheat- Braking resistor overheat- Braking resistor overheat- ing contacts (Thermal pro- ing contacts (Thermal pro- ing contacts (Thermal pro- tector contacts) tector contacts) tector contacts) Braking Braking Braking Resistor Resistor Resistor Unit Unit Unit Inverter Braking Unit #2 Braking Unit #3 Braking Unit #1 Cooling fin overheating con-...
Page 65: Wiring Control Circuit Terminals For Asian Models
Wiring Control Circuit Terminals for Asian Models Wiring Control Circuit Terminals for Asian Models K K K K Wire Sizes and Closed-loop Connectors For remote operation using analog signals, keep the control line length between the Digital Operator or opera- tion signals and the Inverter to 50 m or less, and separate the lines from high-power lines (main circuits or relay sequence circuits) to reduce induction from peripheral devices.
Page 66 n Straight Solderless Terminals for Signal Lines Models and sizes of straight solderless terminal are shown in the following table. Table 2.15 Straight Solderless Terminal Sizes Model Manufacturer Wire Size mm (AWG) 0.25 (24) AI 0.25 - 8YE 12.5 0.5 (20) AI 0.5 - 8WH 0.75 (18) AI 0.75 - 8GY...
Page 67: Control Circuit Terminal Connections
Wiring Control Circuit Terminals for Asian Models K K K K Control Circuit Terminal Connections Connections to Inverter control circuit terminals are shown in Fig 2.23. Forward Run/Stop Pulse train output Reverse Run/Stop 0 to 32 kHz (2.2 kΩ) Default: Output frequency External fault Fault reset Ammeter adjustment...
Page 68 1. Control circuit terminals are arranged as shown below. IMPORTANT 2. The output current capacity of the +V terminal is 20 mA. 3. Disable the stall prevention during deceleration (set parameter L3-04 to 0) when using a Braking Resistor Unit. If this parameter is not changed to disable stall prevention, the system may not stop during decelera- tion.
Page 69: Control Circuit Terminal Functions
Wiring Control Circuit Terminals for Asian Models K K K K Control Circuit Terminal Functions The functions of the control circuit terminals are shown in Table 2.16. Use the appropriate terminals for the correct purposes. Table 2.16 Control Circuit Terminals Type Signal Name Function...
Page 70 Table 2.16 Control Circuit Terminals (Continued) Type Signal Name Function Signal Level 0 to 32 kHz (3 kΩ) H6-01 (Frequency reference input) High level voltage 3.5 to Pulse input 13.2 V Pulse 0 to 32 kHz Pulse monitor H6-06 (Output frequency) +5 V output (Load: 1.5 kΩ) MEMOBUS communica-...
Page 71 Wiring Control Circuit Terminals for Asian Models The functions of DIP switch S1 are shown in the following table. Table 2.17 DIP Switch S1 Name Function Setting RS-485 and RS-422A terminating resis- OFF: No terminating resistance S1-1 ON: Terminating resistance of 110 Ω tance OFF: 0 to 10 V (internal resistance: 20 kΩ) S1-2...
Page 72: Control Circuit Wiring Precautions
K K K K Control Circuit Wiring Precautions Observe the following precautions when wiring control circuits. Separate control circuit wiring from main circuit wiring (terminals R/L1, S/L2, T/L3, B1, B2, U/T1, V/T2, • W/T3, 2, and 3) and other high-power lines. Separate wiring for control circuit terminals MA, MB, MC, M1, and M2 (contact outputs) from wiring to •...
Page 73: Wiring Control Circuit Terminals For European Models
Wiring Control Circuit Terminals for European Models Wiring Control Circuit Terminals for European Models K K K K Wire Sizes and Closed-loop Connectors For remote operation using analog signals, keep the control line length between the Digital Operator or opera- tion signals and the Inverter to 50 m or less, and separate the lines from high-power lines (main circuits or relay sequence circuits) to reduce induction from peripheral devices.
Page 74 n Straight Solderless Terminals for Signal Lines Models and sizes of straight solderless terminal are shown in the following table. Table 2.20 Straight Solderless Terminal Sizes Model Manufacturer Wire Size mm (AWG) 0.25 (24) AI 0.25 - 8YE 12.5 0.5 (20) AI 0.5 - 8WH 0.75 (18) AI 0.75 - 8GY...
Page 75: Control Circuit Terminal Connections
Wiring Control Circuit Terminals for European Models K K K K Control Circuit Terminal Connections Connections to Inverter control circuit terminals are shown in Fig 2.30. Forward Run/Stop Pulse train output Reverse Run/Stop 0 to 32 kHz (2.2 kW) Default: Output frequency External fault Fault reset CN15...
Page 76 1. Control circuit terminals are arranged as shown below. IMPORTANT E(G) E(G) 2. The output current capacity of the +V and -V terminal is 20 mA. 3. Disable the stall prevention during deceleration (set parameter L3-04 to 0) when using a Braking Resistor Unit.
Page 77: Control Circuit Terminal Functions
Wiring Control Circuit Terminals for European Models K K K K Control Circuit Terminal Functions The functions of the control circuit terminals are shown in Table 2.21. Use the appropriate terminals for the correct purposes. Table 2.21 Control Circuit Terminals Type Signal Name Function...
Page 78 Table 2.21 Control Circuit Terminals (Continued) Type Signal Name Function Signal Level Multi-function analog output 0 to +10 V/100% fre- Multi-function (frequency output) quency analog monitor 1 Analog 0 to +10 V max. ±5% Analog common (copy) output 2 mA max. signals Multi-function analog output 5 V/Inverter's rated cur-...
Page 79 Wiring Control Circuit Terminals for European Models nShunt Connector CN15 and DIP Switch S1 The shunt connector CN 15 and DIP switch S1 are described in this section. Terminating resistance Analog input A2 swich : Factory settings CN15 Analog output switch Voltage output (Factory setting) Current output CN15...
Page 80 n Sinking/Sourcing Mode The input terminal logic can be selected between sinking mode (0-V common) and sourcing mode (+24-V common) as shown in Table 2.23. An external power supply is also supported, providing more freedom in sig- nal input methods. Table 2.23 Sinking/Sourcing Mode and Input Signals Internal Power Supply External Power Supply...
Page 81: Control Circuit Wiring Precautions
Wiring Control Circuit Terminals for European Models K K K K Control Circuit Wiring Precautions Observe the following precautions when wiring control circuits. • Separate control circuit wiring from main circuit wiring (terminals R/L1, S/L2, T/L3, B1, B2, U/T1, V/T2, W/T3, 2, and 3) and other high-power lines.
Page 82: Wiring Check
Wiring Check K K K K Checks Check all wiring after wiring has been completed. Do not perform a buzzer check on control circuits. Perform the following checks on the wiring. • Is all wiring correct? Have any wire clippings, screws, or other foreign material been left? •...
Page 83: Installing And Wiring Option Cards
Installing and Wiring Option Cards Installing and Wiring Option Cards K K K K Option Card Models and Specifications Up to three Option Cards can be mounted in the Inverter. You can mount up one Card into each of the three places on the controller card (A, C, and D) shown in Fig 2.34.
Page 84: Pg Speed Control Card Terminals And Specifications
n Preventing C and D Option Card Connectors from Rising After installing an Option Card into slot C or D, insert an Option Clip to prevent the side with the connector from rising. The Option Clip can be easily removed by holding onto the protruding portion of the Clip and pulling it out.
Page 85 Installing and Wiring Option Cards n3G3FV-PPGB2 The terminal specifications for the 3G3FV-PPGB2 are given in the following table. Table 2.26 3G3FV-PPGB2 Terminal Specifications Terminal Contents Specifications 12 VDC (±5%), 200 mA max. Power supply for pulse generator 0 VDC (GND for power supply) H: +8 to 12 V L: +1 V max.
Page 86: Wiring
n3G3FV-PPGX2 The terminal specifications for the 3G3FV-PPGX2 are given in the following table. Table 2.28 3G3FV-PPGX2 Terminal Specifications Terminal Contents Specifications 12 VDC (±5%), 200 mA max.* Power supply for pulse generator 0 VDC (GND for power supply) 5 VDC (±5%), 200 mA max.* A-phase + input terminal A-phase - input terminal B-phase + input terminal...
Page 87 Installing and Wiring Option Cards Three-phase, Inverter 200 VAC (400 VAC) E6B2-CWZ6C R/L1 U/T1 V/T2 V/T2 W/T3 W/T3 3G3FV-PPGA2 +12 V power supply 0 V power supply Open collector output (A/B phase) Pulse 0 V Pulse monitor output TA2 (E) •...
Page 88 n Wiring the 3G3FV-PPGB2 Wiring examples are provided in the following illustrations for the 3G3FV-PPGB2. Inverter Three-phase E6B2-CWZ6C VAC (400 VAC) 3G3FV-PPGB2 Power supply +12 V Power supply 0 V Power supply +12 V A-phase pulse output (-) Power supply +12 V B-phase pulse output (-) A-phase pulse monitor output B-phase pulse monitor output...
Page 89 Installing and Wiring Option Cards nWiring the 3G3FV-PPGD2 Wiring examples are provided in the following illustrations for the 3G3FV-PPGD2. Inverter Three-phase 200 VAC (400 VAC) E6B2-CWZ1X 3G3FV-PPGD2 Power supply +12 V Power supply 0 V Power supply +5 V Pulse input + (A/B phase) Pulse input - (A/B phase) Pulse monitor output •...
Page 90: Wiring Terminal Blocks
K K K K Wiring Terminal Blocks Use no more than 30 meters of wiring for PG (encoder) signal lines for the 3G3FV-PPGA2/PPGB2 or 50 meters for the 3G3FV-PPGD2/PPGX2, and keep the wiring separate from power lines. Use shielded, twisted-pair wires for pulse inputs and pulse output monitor wires, and connect the shield to the shield connection terminal.
Page 91: Selecting The Number Of Pg (Encoder) Pulses
Installing and Wiring Option Cards K K K K Selecting the Number of PG (Encoder) Pulses The setting for the number of PG pulses depends on the model of PG Speed Control Card being used. Set the correct number for your model. n3G3FV-PPGA2/3G3FV-PPGB2 The maximum response frequency is 32,767 Hz.
Page 92 n3G3FV-PPGD2/3G3FV-PPGX2 There are 5 V and 12 V PG power supplies. Check the PG power supply specifications before connecting. The maximum response frequency is 300 kHz. Use the following equation to computer the output frequency of the PG (f Motor speed at maximum frequency output (r/min) ×...
Page 93: Digital Operator And Modes
Chapter 3 Digital Operator and Modes This chapter describes Digital Operator displays and functions, and provides an overview of operating modes and switching between modes. Digital Operator............3-2 Modes ................3-5...
Page 94: Digital Operator
Digital Operator This section describes the displays and functions of the Digital Operator. K K K K Digital Operator Display The key names and functions of the Digital Operator are described below. Digital Operator with LED Display (3G3IV-PJVOP161) Drive Mode Indicators FWD: Lit when there is a forward run command input.
Page 95: Digital Operator Keys
Digital Operator K K K K Digital Operator Keys The names and functions of the Digital Operator Keys are described in Table 3.1. Table 3.1 Key Functions Name Function Switches between operation via the Digital Operator (LOCAL) and L OC AL LOCAL/REMOTE Key control circuit terminal operation (REMOTE).
Page 96 There are indicators on the upper left of the RUN and STOP Keys on the Digital Operator. These indicators will light and flash to indicate operating status. The RUN Key indicator will flash and the STOP Key indicator will light during initial excitation of the dynamic brake.
Page 97: Modes
Modes Modes This section describes the Inverter's modes and switching between modes. K K K K Inverter Modes The Inverter's parameters and monitoring functions are organized in groups called modes that make it easier to read and set parameters.The Inverter is equipped with 5 modes. The 5 modes and their primary functions are shown in the Table 3.2.
Page 98: Switching Modes
K K K K Switching Modes The mode selection display will appear when the MENU Key is pressed from a monitor or setting display. Press the MENU Key from the mode selection display to switch between the modes. Press the DATA/ENTER Key from the mode selection key to monitor data and from a monitor display to access the setting display.
Page 99: Drive Mode
Modes K K K K Drive Mode Drive Mode is the mode in which the Inverter can be operated. The following monitor displays are possible in Drive Mode: The frequency reference, output frequency, output current, and output voltage, as well as fault information and the fault history.
Page 100: Quick Programming Mode
K K K K Quick Programming Mode In Quick Programming Mode, the parameters required for Inverter trial operation can be monitored and set. Parameters can be changed from the setting displays. Use the Increment, Decrement, and Digit Selection/ RESET Keys to change the frequency. The parameter will be written and the monitor display will be returned to when the ENTER Key is pressed after changing the setting.
Page 101: Advanced Programming Mode
Modes K K K K Advanced Programming Mode In Advanced Programming Mode, all Inverter parameters can be monitored and set. Parameters can be changed from the setting displays. Use the Increment, Decrement, and Digit Selection/ RESET Keys to change the frequency. The parameter will be written and the monitor display will be returned to when the ENTER Key is pressed after changing the setting.
Page 102 nSetting Parameters Here, the procedure is shown to change C1-01 (Acceleration Time 1) from 10 s to 20 s. Table 3.3 Setting Parameters in Advanced Programming Mode Step Digital Operator Display Description Power supply turned ON. MENU Key pressed to enter Drive Mode. MENU Key pressed to enter Quick Program- ming Mode.
Page 103: Verify Mode
Modes K K K K Verify Mode Verify Mode is used to display any parameters that have been changed from their default settings in a Pro- gramming Mode or by autotuning. “None” will be displayed if no settings have been changed. Of the Environment Mode settings, only A1-02 will be displayed if it has been changed.
Page 104: Autotuning Mode
K K K K Autotuning Mode Autotuning automatically tunes and sets the required motor constants when operating in the open-loop V/f, V/f with PG, or open-loop vector control modes. Always perform autotuning before starting operation when using open-loop vector control mode. When V/f control has been selected, stationary autotuning for only line-to-line resistance can be selected.
Page 105 Modes Autotuning Monitor Display Setting Display MENU Tuning mode: Tuning mode rotational tuning Autotuning DRIVE QUICK VERIFY AUTO TUNING DRIVE QUICK VERIFY AUTO TUNING Motor output power Motor output power DRIVE QUICK VERIFY AUTO TUNING Motor rated voltage Motor rated voltage DRIVE QUICK VERIFY AUTO...
Page 107: Trial Operation
Chapter 4 Trial Operation This chapter describes the procedures for trial operation of the Inverter and provides an example of trial operation. Cautions and Warnings..........4-2 Trial Operation Procedures.......... 4-4 Adjustment Suggestions ..........4-18...
Page 108: Cautions And Warnings
Cautions and Warnings !WARNING Turn ON the input power supply only after mounting the front cover, terminal covers, bottom cover, Digital Operator, and optional items. Not doing so may result in electri- cal shock. !WARNING Do not remove the front cover, terminal covers, bottom cover, Digital Operator, or optional items while the power is being supplied.
Page 109: Trial Operation Procedure
Trial Operation Procedure Trial Operation Procedure Perform trial operation according to the following flowchart. When setting the basic parameters, always set C6-01 (CT/VT Selection) according to the application. START Installation Wiring Set power supply voltage. Turn ON power. Confirm status. Initialize parameters Basic settings...
Page 110: Trial Operation Procedures
Trial Operation Procedures The procedure for trial operation is described in order in this section. K K K K Application Confirmation First, confirm the application before using the Inverter. Fan, blower, pump • Other equipment • For any Inverter application other than a fan, blower, or pump, set C6-01 (CT/VT Selection) to 0 (CT: low car- rier, fixed torque).
Page 111: Power On
Trial Operation Procedures K K K K Power ON Confirm all of the following items before turning ON the power supply. • Check that the power supply is of the correct voltage. 200-V class: 3-phase 200 to 240 V, 50 Hz/60 Hz 400-V class: 3-phase 380 to 480 V, 50 Hz/60 Hz •...
Page 112: Initializing Parameters
K K K K Initializing Parameters Initialize parameters by following the table below. Set A1-03 to 2220 when initializing a 2-wire sequence. Table 4.1 Initializing Parameters Step Operator Screen Displays Description Turn ON the power. Press to shift to Advanced Programming MENU Mode.
Page 113: Basic Settings
Trial Operation Procedures K K K K Basic Settings Switch to the quick programming mode (the QUICK indicator on the Digital Operation should be lit) and then set the following parameters. Refer to Chapter 3 Digital Operator and Modes for Digital Operator operating procedures and to Chapter 5 Parameters and Chapter 6 Parameter Settings by Function for details on the parameters.
Page 114 Table 4.2 Parameters that must be set (Continued) Parame- Factory ter Num- Name Description Setting Range Page Setting Set to enable or disable the motor overload protection function using the electronic ther- mal relay. Motor protection 5-56 L1-01 0: Disabled 0 to 3 selection 6-47...
Page 115: Settings For The Control Methods
Trial Operation Procedures K K K K Settings for the Control Methods Autotuning methods depend on the control method set for the Inverter. Make the settings required by the con- trol method. nOverview of Settings Make the required settings in quick programming mode and autotuning mode according to the following flow- chart.
Page 116 nSetting the Control Method Any of the following three control methods can be set. V/f control without PG (normal speed control) • V/f control with PG (simple speed feedback control) • • Open-loop vector control (high-performance control without PG) V/f Control without PG (A1-02 = 0) •...
Page 117: Autotuning
Trial Operation Procedures K K K K Autotuning Use the following procedure to perform autotuning to automatically set motor constants when using the open- loop vector control method, when the cable length is long, etc. n Setting the Autotuning Mode One of the following three autotuning modes can be set.
Page 118 n Precautions Before Using Autotuning Read the following precautions before using autotuning. Autotuning the Inverter is fundamentally different from autotuning the servo system. Inverter autotuning • automatically adjusts parameters according to detected motor constants, whereas servo system autotuning adjusts parameters according to the detected size of the load. When speed precision is required at high speeds (i.e., 90% of the rated speed or higher), use a motor with a •...
Page 119 Trial Operation Procedures n Parameter Settings for Autotuning The following parameters must be set before autotuning. Table 4.4 Parameter Settings before Autotuning Data Displays during Param- Autotuning eter Setting Factory Name Display Open Num- Range Setting with Loop Vector Set the location where the autotuned motor constants are to be stored.
Page 120 nDigital Operator Displays during Autotuning The following displays will appear on the Digital Operator during autotuning. Table 4.5 Digital Operator Displays during Autotuning Digital Operator Display Description Autotuning mode selection: T1-01 Using the same procedures as for the programming modes check and set the T1 parameters according to information on the previous page.
Page 121 Trial Operation Procedures nPrecautions After Using Autotuning When using a spindle motor, the maximum output speed is higher than the rated frequency (or Base Fre- quency, FA (E1-06)). For the region greater than FA, defined as the constant output range, output torque is reduced because the voltage does not increase for an increase in the frequency.
Page 122: Application Settings
K K K K Application Settings Parameters are set as required in advanced programming mode (i.e., with the ADV indicator lit on the Digital Operator). All the parameters that can be set in quick programming mode can also be displayed and set in advanced programming mode.
Page 123: Check And Recording Parameters
Trial Operation Procedures nOperation Using the Digital Operator Use the Digital Operator to start operation in LOCAL mode in the same way as in no-load operation. • • Make sure the STOP Key on the Digital Operator is easily accessible so that any unexpected movement can be stopped.
Page 124: Adjustment Suggestions
Adjustment Suggestions If hunting, vibration, or other problems originating in the control system occur during trial operation, adjust the parameters listed in the following table according to the control method. This table lists only the most commonly used parameters. Table 4.6 Adjusted Parameters Recom- Control Name (Parameter...
Page 125 Adjustment Suggestions Table 4.6 Adjusted Parameters (Continued) Recom- Control Name (Parameter Factory Performance mended Adjustment Method Method Number) Setting Setting • Reducing motor • Increase the setting if magnetic noise motor magnetic noise is Depends Carrier frequency • Controlling hunting 0 to high.
Page 127: Parameters
Chapter 5 Parameters This chapter describes all parameters that can be set in the Inverter. Parameter Descriptions ..........5-2 Digital Operator Display Functions and Levels....5-3 Parameter Tables............5-9...
Page 128: Parameter Descriptions
Parameter Descriptions This section describes the contents of the parameter tables. K K K K Description of Parameter Tables Parameter tables are structured as shown below. Here, b1-01 (Frequency Reference Selection) is used as an example. Name Control Methods Change Param- Open during...
Page 129: Digital Operator Display Functions And Levels
Digital Operator Display Functions and Levels Digital Operator Display Functions and Levels The following figure shows the Digital Operator display hierarchy for the Inverter. Function Display Page MENU Drive Mode Status Monitor Parameters Monitor 5-75 Fault Trace Fault Trace 5-79 Inverter can be operated and Fault History Fault History...
Page 130: Parameters Settable In Quick Programming Mode
K K K K Parameters Settable in Quick Programming Mode The minimum parameters required for Inverter operation can be monitored and set in quick programming mode. The parameters displayed in quick programming mode are listed in the following table. These, and all other parameters, are also displayed in advanced programming mode.
Page 131 Digital Operator Display Functions and Levels Name Control Methods Change Param- Regis- during Open Setting Factory Description eter Loop Range Setting Opera- with Number Vec- Display tion Accelera- Set the acceleration time in seconds tion time 1 C1-01 for the output frequency to climb from 200H Accel Time 0% to 100%.
Page 132 Name Control Methods Change Param- Regis- Open during Setting Factory Description eter Loop Range Setting Opera- with Number Vec- Display tion V/f pattern 0 to E: Select from 15 preset patterns. selection Custom user-set patterns E1-03 0 to F 302H (Applicable for setting E1-04 V/F Selec- to E1-10).
Page 133 Digital Operator Display Functions and Levels Name Control Methods Change Param- Regis- during Open Setting Factory Description eter Loop Range Setting Opera- with Number Vec- Display tion Set the voltage level gain for multi- Gain (termi- function analog output 1. nal FM) Set the number of multiples of 10 V to be output as the 100% output for the...
Page 134 Name Control Methods Change Param- Regis- Open during Setting Factory Description eter Loop Range Setting Opera- with Number Vec- Display tion 0: Disabled (Deceleration as set. If Stall pre- deceleration time is too short, a vention main circuit overvoltage may selection result.) during...
Page 135: Parameter Tables
Parameter Tables Parameter Tables K K K K A: Setup Settings The following settings are made with the environment parameters (A parameters): Language displayed on the Digital Operator, access level, control method, initialization of parameters. n Initialize Mode: A1 Parameters for the environment modes are shown in the following table. Name Control Methods Change...
Page 136 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Used to initialize the param- Initialize eters using the specified method. No initializing 1110: Initializes using the Parameters 0 to A1-03 103H 2220: Initializes using a...
Page 137: Application Parameters: B
Parameter Tables K K K K Application Parameters: b The following settings are made with the application parameters (B parameters): Operation method selection, DC injection braking, speed searching, timer functions, dwell functions, and energy saving functions. nOperation Mode Selections: b1 Parameters for operation mode selection are shown in the following table.
Page 138 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Operation Used to set the operation selection mode by switching to the after switch- Remote mode using the ing to Local/Remote Key.
Page 139 Parameter Tables Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion DC Injec- Sets the time in units of 1 tion brak- second to perform DC ing time at injection braking at stop.
Page 140 Name Control Methods Change Param- Regis- during Setting Factory Description Page eter Open Range Setting Opera- with Number Loop Display tion Speed Sets the output frequency search deceleration time during speed decelera- search in 1-second units. tion time 0.1 to b3-03 Set the time for deceleration 2.0 s...
Page 141 Parameter Tables nPID Control: b5 Parameters for PID control are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion 0: Disabled PID control 1: Enabled (Deviation is D- mode selec- controlled.)
Page 142 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion PID output 0.0 to gain b5-10 Sets output gain. 1AEH 6-118 25.0 Output Gain PID reverse 0: 0 limit when PID output output is negative.
Page 143 Parameter Tables Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Accel/decel time for PID Set the accel/decel time for 0.0 to reference b5-17 0.0 s 1B5H 6-118 PID reference in seconds.
Page 144 nEnergy Saving: b8 Parameters for energy-saving control functions are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Energy-sav- Select whether to enable or ing mode disable energy-saving con- selection...
Page 145: Tuning Parameters: C
Parameter Tables K K K K Tuning Parameters: C The following settings are made with the tuning parameters (C parameters): Acceleration/deceleration times, s-curve characteristics, slip compensation, torque compensation, speed control, and carrier frequency func- tions. nAcceleration/Deceleration: C1 Parameters for acceleration and deceleration times are shown in the following table. Name Control Methods Change...
Page 146 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Decelera- The deceleration time when tion Stop the multi-function input Time “Deceleration stop” is set to 0.0 to C1-09 10.0 s 208H 6-18...
Page 147 Parameter Tables nS-curve Acceleration/Deceleration: C2 Parameters for S-curve characteristics are shown in the following table. Name Control Methods Change Param- during eter Setting Factory Description Register Page Open Num- Range Setting Opera- with Loop Display tion S-curve character- istic time 0.00 at acceler- C2-01...
Page 148 nMotor Slip Compensation: C3 Parameters for slip compensation are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Slip com- Used to improve speed accu- pensation racy when operating with a gain...
Page 149 Parameter Tables nTorque Compensation: C4 Parameters for are torque compensation shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Sets torque compensation gain as a ratio. Torque Usually setting is not neces- compensa-...
Page 150 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Starting Sets the rise time constant torque time (ms) for the starting torque 0 to constant C4-05 value. 10 ms 219H 6-37 The filter is disabled if set...
Page 151 Parameter Tables nCarrier Frequency: C6 Parameters for the carrier frequency are shown in the following table. Name Control Methods Change Param- during eter Setting Factory Description Register Page Open Num- Range Setting Opera- with Loop Display tion CT/VT 0: CT (low carrier, constant selection torque, 150% for 1 munite max.)
Page 152 Name Control Methods Change Param- during eter Setting Factory Description Register Page Open Num- Range Setting Opera- with Loop Display tion Carrier frequency upper limit 2.0 to 15.0 C6-03 225H 15.0 *2 *3 Carrier- Freq Max Set the carrier frequency upper limit and lower limit in kHz units.
Page 153: Reference Parameters: D
Parameter Tables K K K K Reference Parameters: d The following settings are made with the reference parameters (d parameters): Frequency references. nPreset Reference: d1 Parameters for frequency references are shown in the following table. Name Control Methods Change Param- during Setting Factory...
Page 154 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Frequency The frequency reference reference 9 when multi-step speed com- 0.00 d1-09 288H mand 4 is ON for a multi- Reference 9 function input.
Page 155 Parameter Tables nReference Limits: d2 Parameters for frequency reference limits are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Frequency Set the output frequency reference upper limit as a percent, tak- 0.0 to...
Page 156 nReference Frequency Hold: d4 Parameters for the reference frequency hold function are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Sets whether or not frequen- cies on hold will be Frequency recorded.
Page 157: Motor Constant Parameters: E
Parameter Tables nField Weakening: d6 Parameters for the field weakening command are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Set the Inverter output volt- Field weak- age when the field weaken- ening level...
Page 158 Name Control Methods Change Param- during eter Setting Factory Description Register Page Open Num- Range Setting Opera- with Loop Display tion Max. 60.0 output 40.0 to frequency E1-04 (50.0 303H 400.0 6-129 Frequency Max. Output voltage (V) 200.0 0.0 to voltage E1-05 304H...
Page 159 Parameter Tables Name Control Methods Change Param- during eter Setting Factory Description Register Page Open Num- Range Setting Opera- with Loop Display tion Mid. output frequency 0.0 to 0.0 Hz E1-11 30AH 6-129 400.0 Frequency Mid. Set only to fine-adjust V/f for the output output range.
Page 160 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Motor line- Sets the motor phase-to- to-line resis- 0.000 9.842 phase resistance in Ω units. Ω tance E2-05 312H 6-127 This parameter is automati- 65.000...
Page 161 Parameter Tables n Motor 2 V/f Pattern: E3 Parameters for motor 2 V/f characteristics are shown in the following table. Name Control Methods Change Param- during eter Setting Factory Description Register Page Open Num- Range Setting Opera- with Loop Display tion Motor 2 control...
Page 162 Name Control Methods Change Param- during eter Setting Factory Description Register Page Open Num- Range Setting Opera- with Loop Display tion Output voltage (V) Motor 2 min. out- put fre- quency voltage (VMIN) 0.0 to Frequency (Hz) 9.0 V E3-08 320H 255.0 To set V/f characteristics in a...
Page 163 Parameter Tables nMotor 2 Setup: E4 Parameters for motor 2 are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Motor 2 Sets the motor rated current rated cur- in 1 A units.
Page 164: Option Parameters: F
K K K K Option Parameters: F The following settings are made with the option parameters (F parameters): Settings for Option Cards nPG Option Setup: F1 Parameters for the PG Speed Control Card are shown in the following table. Name Control Methods Change Param-...
Page 165 Parameter Tables Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Display Loop tion Sets the stopping method Operation when a speed deviation selection at (DEV) fault occurs. deviation 0: Ramp to stop (Deceleration stop using Deceleration Time 1, C1- 02.)
Page 166 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Overspeed detection Sets the overspeed detection 0 to level F1-08 115% 387H 6-144 method. Frequencies above that set PG Over- for F1-08 (set as a percent- spd Level age of the maximum output...
Page 167 Parameter Tables nAnalog Monitor Cards: F4 Parameters for the Analog Monitor Card are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Channel 1 monitor selection F4-01...
Page 168 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Channel 2 output mon- Sets the channel 2 item bias -10.0 to itor bias F4-06 to 100%/10 V when the Ana- 396H 6-73 10.0...
Page 169 Parameter Tables nNot Used: F5 Parameters for the Digital Output Card are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Not used F5-01 399H DO Ch1...
Page 170 nCommunications Option Cards: F6 Parameters for a Communications Option Card (DeviceNet) are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion DeviceNet 0: Decelerates to a stop fault opera- using C1-02 deceleration tion selec-...
Page 171: Terminal Function Parameters: H
Parameter Tables K K K K Terminal Function Parameters: H The following settings are made with the terminal function parameters (H parameters): Settings for external terminal functions. nMulti-function Digital Inputs: H1 Parameters for multi-function digital inputs are shown in the following tables. Name Control Methods Change...
Page 172 Control Methods Set- Open ting Function Page Loop with Value Vec- Multi-step speed reference 3 6-10 Jog frequency command (higher priority than multi-step speed reference) 6-10 Accel/decel time 1 6-20 External baseblock NO (NO contact: Baseblock at ON) 6-63 External baseblock NC (NC contact: Baseblock at OFF) 6-63 Acceleration/deceleration ramp hold (ON: Acceleration/deceleration stopped, fre- 6-64...
Page 173 Parameter Tables Control Methods Set- Open ting Function Page Loop with Value Vec- PID soft starter PID input characteristics switch DC injection braking command (ON: Performs DC injection braking) 6-17 External search command 1 (ON: Speed search from maximum output frequency) 6-54 External search command 2 (ON: Speed search from set frequency) 6-54...
Page 174 Name Control Methods Change during Parameter Num- Setting Factory Description Register Page Open Range Setting Opera- with Loop Display tion Terminal P2 function 3G3RV select (con- (Asia) tact) Term P2 Sel Multi-function Terminal H2-03 0 to 37 40DH output 2 M5-M6 function 3G3RV...
Page 175 Parameter Tables Control Methods Set- Open ting Function Page loop with Value Vec- Desired frequency agree 2 (ON: Output frequency = L4-03, L4-04 used, and dur- ing frequency agree) Frequency detection 3 (ON: Output frequency ≤L4-03, L4-04 used) Frequency detection 4 (ON: Output frequency ≥L4-03, L4-04 used) Overtorque/undertorque detection 1 NC (NC Contact: Torque detection at OFF) 6-44 Overtorque/undertorque detection 2 NO (NO Contact: Torque detection at ON)
Page 176 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Multi-func- 0: Limit negative frequency tion analog settings for gain and bias input termi- settings to 0. nal A2 sig- 1: Do not limit negative nal level frequency settings for...
Page 177 Parameter Tables H3-09 Settings Control Methods Set- Open ting Function Contents (100%) Loop with Value Vec- Add to terminal A1 Maximum output frequency 6-28 Frequency reference (voltage) command Frequency gain 6-28 value Auxiliary frequency reference (2nd Maximum output frequency 6-28 step analog) Voltage bias Motor rated voltage (E1-05)
Page 178 nMulti-function Analog Outputs: H4 Parameters for multi-function analog outputs are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Page eter Register Open Range Setting Opera- with Number Loop Display tion Monitor Sets the number of the moni- selection tor item to be output (U1- (terminal...
Page 179 Parameter Tables Name Control Methods Change Param- during Setting Factory Description Page eter Register Open Range Setting Opera- with Number Loop Display tion Analog out- Sets the signal output level put 2 signal for multi-function output 2 0 or 1 level selec- (terminal AM) (0 to 2)
Page 180 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Send wait Set the time from the time Inverter receiving data to H5-06 5 to 65 5 ms 42AH 6-76 when the Inverter starts to Transmit...
Page 181 Parameter Tables Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Pulse train Set the number of pulses out- monitor put when speed is 100% in scaling hertz. Set H6-06 to 2, and H6-07 to 0 to 1440...
Page 182: Protection Function Parameters: L
K K K K Protection Function Parameters: L The following settings are made with the protection function parameters (L parameters): Motor selection func- tion, power loss ridethrough function, stall prevention function, frequency detection, torque limits, and hard- ware protection. nMotor Overload: L1 Parameters for motor overloads are shown in the following table.
Page 183 Parameter Tables Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Alarm oper- Set H3-09 to E and select the ation selec- operation when the input tion during motor temperature (ther- motor over- mistor) input exceeds the...
Page 184 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Momentary power loss Ridethrough time, when ridethru Momentary Power Loss 0.1 s L2-02 0 to 2.0 486H 6-52 time Selection (L2-01) is set to 1, in units of seconds.
Page 185 Parameter Tables Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Frequency Sets as a percent the about to reduction reduce the output frequency gain at KEB at the beginning of decelera- start tion at momentary power 0 to...
Page 186 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion 0: Disabled (Deceleration as Stall pre- set. If deceleration time is vention too short, a main circuit selection overvoltage may result.) during decel 1: Enabled (Deceleration is stopped when the main...
Page 187 Parameter Tables nReference Detection: L4 Parameters for the reference detection function are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Speed Effective when “Desired fre- agreement quency (ref/setting) agree detection...
Page 188 nFault Restart: L5 Parameters for restarting faults are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Number of Sets the number of auto auto restart restart attempts.
Page 189 Parameter Tables nTorque Detection: L6 Parameters for the torque detection function are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion 0: Overtorque/undertorque detection disabled.
Page 190 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Torque detection selection 2 L6-04 0 to 8 4A4H 6-44 Torq Det 2 Torque Output of torque detection 1 detection is enabled by setting 17 for 0 to...
Page 191 Parameter Tables nTorque Limits: L7 Parameters for torque limits are shown in the following table. Name Control Methods Change Param- during eter Setting Factory Description Register Page Open Num- Range Setting Opera- with Loop Display tion Forward drive torque 0 to limit L7-01 200%...
Page 192 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Operation Sets the operation for when selection the Inverter overheat pre- after over- alarm goes ON. heat pre- 0: Decelerate to stop in alarm deceleration time C1-02.
Page 193: N: Special Adjustments
Parameter Tables Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion OL2 charac- teristics 0: OL2 characteristics at selection at low speeds disabled. L8-15 0 or 1 4BBH low speeds 1: OL2 characteristics at low speeds enabled.
Page 194 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Set the hunting-prevention Hunting- gain multiplication factor. prevention Normally, there is no need to gain make this setting. Make the adjustments as fol- lows: •...
Page 195: Digital Operator Parameters: O
Parameter Tables nHigh-slip Braking: N3 Parameters for high-slip braking are shown in the following table. Control Name Change Methods Param- during Setting Factory Description Register Page eter Range Setting Opera- Number with tion Display High-slip braking Sets the frequency width for decelera- deceleration during high-slip tion fre-...
Page 196 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Monitor Sets the monitor item to be selection displayed when the power is after power turned on. 1: Frequency reference o1-02 1 to 4 501H...
Page 197 Parameter Tables nMulti-function Selections: o2 Parameters for Digital Operator key functions are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion LOCAL/ Sets the Digital Operator REMOTE Local/Remote Key key enable/...
Page 198 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Operation Sets the operation when the selection Digital Operator is discon- when digi- nected. tal operator 0: Disabled (Operation is discon- continues even if the nected...
Page 199: T: Motor Autotuning
Parameter Tables n Copy Function: o3 Parameters for the copy function are shown in the following table. Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Copy func- 0: Normal operation tion selec- 1: READ (Inverter to...
Page 200 Name Control Methods Change Param- during Setting Factory Description Register Page eter Open Range Setting Opera- with Number Loop Display tion Motor rated current 0.32 to Set the rated current of the 1.90 A T1-04 704H 4-13 motor in amps. 6.40 Rated Cur- rent...
Page 201: U: Monitor Parameters
Parameter Tables K K K K U: Monitor Parameters The following settings are made with the monitor parameters (U parameters): Setting parameters for monitor- ing in drive mode. n Status Monitor Parameters: U1 The parameters used for monitoring status are listed in the following table. Name Control Methods Output Signal Level Dur-...
Page 202 Name Control Methods Output Signal Level Dur- Param- Min. Open Description ing Multi-Function Analog Register eter Loop Unit with Number Output Vec- Display Torque ref- Monitor in internal torque erence 10 V: Motor rated torque U1-09 reference value for vector 0.1% (0 to ±...
Page 203 Parameter Tables Name Control Methods Output Signal Level Dur- Param- Min. Open Description ing Multi-Function Analog Register eter Loop Unit with Number Output Vec- Display Software No. (flash U1-14 (Manufacturer’s ID number) (Cannot be output.) memory) FLASH ID Terminal Monitors the input voltage of A1 input the voltage frequency refer- 10 V: 100% (10 V)
Page 204 Name Control Methods Output Signal Level Dur- Param- Min. Open Description ing Multi-Function Analog Register eter Loop Unit with Number Output Vec- Display Output volt- Monitors the Inverter inter- age refer- nal voltage reference for 10 V: 200 VAC (400 VAC) ence (Vd) U1-27 motor excitation current con-...
Page 205 Parameter Tables n Fault Trace: U2 Parameters for error tracing are shown in the following table. Name Control Methods Output Signal Level Param- Min. Open Description During Multi-Function Register eter Loop Unit with Number Analog Output Vec- Display Current fault The contents of the current U2-01 fault.
Page 206 Name Control Methods Output Signal Level Param- Min. Open Description During Multi-Function Register eter Loop Unit with Number Analog Output Vec- Display Torque ref- The reference torque when the erence at previous fault occurred. The fault U2-10 0.1% motor rated torque corresponds Torque Ref- to 100%.
Page 207 Parameter Tables Name Control Methods Output Signal Level Dur- Param- Min. Open Description ing Multi-Function Analog Register eter Loop Unit with Number Output Vec- Display Fourth/old- est fault The error contents of 4th U3-04 previous fault. (803H) Fault Mes- sage 4 Cumulative operation The total operating time...
Page 208 Name Control Methods Output Signal Level Dur- Param- Min. Open Description ing Multi-Function Analog Register eter Loop Unit with Number Output Vec- Display 10th previ- ous fault U3-14 10th previous fault 809H Fault Mes- sage 10 Accumula- tive operat- ing time at Accumulative operating 5th previ- U3-15...
Page 209: Factory Settings That Change With The Control Method (A1-02)
Parameter Tables K K K K Factory Settings that Change with the Control Method (A1-02) The factory settings of the following parameters will change if the control method (A1-02) is changed. Factory Setting Open Param- V/f Con- V/F with Name Setting Range Unit Loop...
Page 210 n200-V and 400-V Class Inverters of 0.4 to 1.5 kW Para meter Open Factory Setting Unit Num- Loop Vector Control E1-03 E1-04 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0 60.0 E1-05 200.0 200.0 200.0...
Page 211: Factory Settings That Change With The Inverter Capacity (O2-04)
Parameter Tables K K K K Factory Settings that Change with the Inverter Capacity (o2-04) The factory settings of the following parameters will change if the Inverter capacity (o2-04) is changed. n200-V Class Inverters Parame- Name Unit Factory Setting ter Num- Inverter Capacity 0.75 o2-04...
Page 212 Parame- Name Unit Factory Setting ter Num- Inverter Capacity 18.5 o2-04 kVA selection Energy-saving filter time b8-03 0.50 (Open loop vector control) 2.00 (Open loop vector control) constant Energy-saving coeffi- b8-04 57.87 51.79 46.27 38.16 35.78 31.35 23.10 23.10 23.10 cient Carrier frequency selec- C6-02...
Page 213 Parameter Tables n400-V Class Inverters Parame- Name Unit Factory Setting ter Num- Inverter Capacity 0.75 o2-04 kVA selection Energy-saving filter time b8-03 0.50 (Open loop vector control) constant Energy-saving coeffi- b8-04 576.40 447.40 338.80 313.60 245.80 236.44 189.50 145.38 140.88 126.26 cient Carrier frequency selec-...
Page 214 Parame- Name Unit Factory Setting ter Num- Inverter Capacity 18.5 o2-04 kVA selection Energy-saving filter time b8-03 0.50 (Open loop vector control) 2.00 (Open loop vector control) constant Energy-saving coeffi- b8-04 115.74 103.58 92.54 76.32 71.56 67.20 46.20 41.22 36.23 33.18 cient Carrier frequency selec-...
Page 215 Parameter Tables Parame- Name Unit Factory Setting ter Num- Inverter Capacity o2-04 kVA selection Energy-saving filter time 2.00 (Open loop vector con- b8-03 constant trol) Energy-saving coeffi- b8-04 30.13 30.57 27.13 21.76 cient Carrier frequency selec- C6-02 tion Carrier frequency selec- tion upper limit E2-01 Motor rated current...
Page 217: Parameter Settings By Function
Chapter 6 Parameter Settings by Function Application and Overload Selections ......6-2 Frequency Reference ..........6-6 Run Command............6-12 Stopping Methods ............6-14 Acceleration and Deceleration Characteristics ..6-19 Adjusting Frequency References....... 6-27 Speed Limit (Frequency Reference Limit Function) ..6-32 Improved Operating Efficiency........6-34 Machine Protection ............
Page 218: Application And Overload Selections
Application and Overload Selections K K K K Select the Overload to Suit the Application Set C6-01 (CT: Low carrier constant torque, VT: High carrier variable torque) depending on the application for which the Inverter is used. The setting ranges for the Inverter carrier frequency, overload tolerance, and maximum output frequency depend on the setting in C6-01.
Page 219 Application and Overload Selections nDifference between CT and VT The characteristics of CT (low carrier, constant torque) and VT (high carrier, variable torque) are shown below. CT: Low Carrier, Constant Torque VT: High Carrier, Variable Torque Variable Torque Constant Torque Torque Torque Motor speed...
Page 220 Carrier Frequency When selecting the carrier frequency, observe the following precautions items. When using a device with C6-01 set to 1 (VT), adjust the carrier frequency according to the cases shown • below. If the wiring distance between Inverter and motor is long: Set the carrier frequency low. (Use the following values as guidelines.
Page 221 Application and Overload Selections nCarrier Frequency and Inverter Overload Current Level When C6-01 is set to 1, the Inverter overload level will be reduced. Even when the overload current falls to below 120%, OL2 (Inverter overload) will be detected. The Inverter overload current reduction level is shown below.
Page 222: Frequency Reference
Frequency Reference This section explains how to input the frequency reference. K K K K Selecting the Frequency Reference Source Set parameter b1-01 to select the frequency reference source. nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop...
Page 223 Frequency Reference nInputting the Frequency Reference Using Voltage (Analog Setting) When b1-01 is set to 1, you can input the frequency reference from control circuit terminal A1 (voltage input), or control circuit terminal A2 (voltage or current input). Inputting Master Speed Frequency Reference Only (Asian Model) If inputting the master speed frequency reference only, input the voltage reference to control circuit terminal Inverter 2 kΩ...
Page 224 Inputting Master Speed Frequency Reference Only (European Model) If inputting the master speed frequency reference only, input the voltage reference to control circuit terminal A1. The voltage range canbe selected by setting H3-01. When H3-01 = 0 When H3-01 = 1 Inverter Inverter 2 kΩ...
Page 225 Frequency Reference nInputting Frequency Reference Using Current When b1-01 is set to 1, you can input the frequency reference from control circuit terminal A2. Input the cur- rent (4 to 20 mA) in control circuit terminal A2. When H3-09 (Multi-Function Analog Input Terminal A2 Signal Level Selection) is set to 0 (factory setting) the input on A2 is added to A1.
Page 226: Using Multi-Step Speed Operation
K K K K Using Multi-Step Speed Operation With SYSDRIVE RV series Inverters, you can change the speed to a maximum of 17 steps, using 16 fre- quency references, and one jog frequency reference. The following example of a multi-function input terminal function shows a 9-step operation using multi-step references 1 to 3 and jog frequency selection functions.
Page 227 Frequency Reference Setting Precautions When setting analog inputs to speed 1 and speed 2, observe the following precautions. • When setting terminal A1's analog input to speed 1, set b1-01 to 1, and when setting d1-01 (Frequency Reference 1) to speed 1, set b1-01 to 0. When setting terminal A2's analog input to speed 2, set H3-09 to 2 (auxiliary frequency reference).
Page 228: Run Command
Run Command This section explains input methods for the run command. K K K K Selecting the Run Command Source Set parameter b1-02 to select the source for the run command. nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during...
Page 229 Run Command Performing Operations Using a 3-wire Sequence By selecting 0 for any parameter from H1-01 to H1-05 (related to terminals S3 to S7), the selected terminal functions as a forward/reverse run command, and terminals S1 and S3 change functions to 3-wire sequence commands.
Page 230: Stopping Methods
Stopping Methods This section explains methods of stopping the Inverter. K K K K Selecting the Stopping Method There are four methods of stopping the Inverter when a stop command is set: Deceleration to stop • Coast to stop • DC braking stop •...
Page 231 Stopping Methods nDeceleration to Stop If the stop command is input (i.e., the run command is turned OFF) when b1-03 is set to 0, the motor deceler- ates to a stop according to the deceleration time that has been set. (Factory setting: C1-02 (Deceleration Time If the output frequency when decelerating to a stop falls below b2-01, the DC injection brake will be applied using the DC current set in b2-02 only for the time set in b2-04.
Page 232 nDC Braking Stop If the stop command is input (i.e., the run command is turned OFF) when b1-03 is set to 2, a wait is made for the time set in L2-03 (Minimum Baseblock (BB) Time) and then the DC injection brake current set in b2-02 is sent to the motor to apply a DC injection brake to stop the motor.
Page 233: Using The Dc Injection Brake
Stopping Methods K K K K Using the DC Injection Brake Set parameter b2-03 to apply the DC injection brake voltage to the motor while it is coasting to a stop, to stop the motor and then restart it. Set b2-03 to 0 to disable the DC injection brake at start. Set the DC injection brake current using b2-02.
Page 234: Using A Deceleration Stop From An External Input
nChanging the DC Injection Brake Current Using an Analog Input When H3-09 (Multi-function Analog Input Terminal A2 Function Selection) is set to 6 (DC injection brake current), the DC injection brake current level is specified by the analog input. At 10 V input (voltage) or 20 mA input (current), 100% of the Inverter rated current will be applied. DC injection brake voltage level Inverter rated current If you set this parameter to 7 and use overtorque detection...
Page 235: Acceleration And Deceleration Characteristics
Acceleration and Deceleration Characteristics Acceleration and Deceleration Characteristics This section explains the acceleration and deceleration characteristics of the Inverter. K K K K Setting Acceleration and Deceleration Times Acceleration time indicates the time taken for the output frequency to climb from 0% to 100%. Deceleration time indicates the time taken for the output frequency to reduce to 0%.
Page 236 Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion S-curve characteristic time at acceleration start 0.00 to C2-01 0.20 s 2.50 Set the S-curve characteristic time for each part in SCrv Acc@ Start seconds.
Page 237: Acceleration And Deceleration Characteristics
Acceleration and Deceleration Characteristics Output frequency Acceleration/ deceleration time switching frequency (C1-11) C1-07 rate C1-01 rate C1-02 rate C1-08 rate When output frequency ≥ C1-11, acceleration and deceleration are performed using Acceleration/deceleration Time 1 (C1-01, C1-02). When output frequency < C1-11, acceleration and deceleration are performed using Acceleration/deceleration Time 4 (C1-07, C1-08).
Page 238: Accelerating And Decelerating Heavy Loads (Dwell Function)
nEntering S-curve Characteristics in the Acceleration and Deceleration Time By performing acceleration and deceleration using an S-curve pattern, you can reduce shock when starting and stopping the machine. Using the Inverter, you can set an S-curve characteristic time for each of the following: Acceleration start time, deceleration start time, acceleration end time, and deceleration end time.
Page 239: Preventing The Motor From Stalling During Acceleration (Stall Prevention During Acceleration Function)
Acceleration and Deceleration Characteristics K K K K Preventing the Motor from Stalling During Acceleration (Stall Prevention During Acceleration Function) The Stall Prevention During Acceleration function prevents the motor from stalling if a heavy load is placed on the motor, or sudden rapid acceleration is performed. If you set L3-01 to 1 (enabled) and the Inverter output current exceeds the -15% level of the set value in L3- 02, the acceleration rate will begin to slow down.
Page 240 nTime Chart The following figure shows the frequency characteristics when L3-01 is set to 1. Output current Stall level during acceleration Time Output frequency Output frequency is controlled to prevent the motor stalling. Time Fig 6.24 Time Chart for Stall Prevention During Acceleration nSetting Precautions If the motor capacity is small compared to the Inverter capacity, or if the motor is operated using the fac- •...
Page 241: Preventing Overvoltage During Deceleration (Stall Prevention During Deceleration Function)
Acceleration and Deceleration Characteristics K K K K Preventing Overvoltage During Deceleration (Stall Prevention During Deceleration Function) The Stall Prevention During Deceleration function makes the rate of deceleration more gentle to suppress increases in DC bus voltage when the DC bus voltage exceeds the set value during motor deceleration. This function automatically lengthens the deceleration time with respect to the bus voltage, even if the decel- eration time has been set to a considerably small value.
Page 242 nSetting Example An example of stall prevention during deceleration when L3-04 is set to 1 as shown below. Output frequency Deceleration time controlled to prevent overvoltage Time Deceleration time (set value) Fig 6.26 Stall Prevention During Deceleration Operation nSetting Precautions •...
Page 243: Adjusting Frequency References
Adjusting Frequency References Adjusting Frequency References This section explains methods of adjusting frequency references. K K K K Adjusting Analog Frequency References Gain and bias are among the parameters used to adjust analog inputs. nRelated Parameters Name Control Methods Param- Change Open eter...
Page 244 Frequency reference Frequency reference Terminal A2 input Terminal voltage (current) input voltage Terminal A2 input Terminal A1 input Fig 6.27 Terminals A1 and A2 Inputs nAdjusting Frequency Gain Using an Analog Input When H3-09 is set to 1 (frequency gain), you can adjust the frequency gain using an analog input. Frequency gain Multi-function analog input terminal A2 input level...
Page 245: Operation Avoiding Resonance (Jump Frequency Function)
Adjusting Frequency References Frequency bias Multi-function analog input terminal A2 input level Fig 6.29 Frequency Bias Adjustment (Terminal A2 Input) For example, if H3-02 is 100%, H3-03 is 0%, and terminal A2 is set to 1 V, the frequency reference from terminal A1 when 0 V is input to A1 will be 10%.
Page 246: Adjusting Frequency Reference Using Pulse Train Inputs
The relationship between the output frequency and the jump frequency reference is as follows: Output frequency Frequency reference descending Jump frequency width d3-04 Frequency reference ascending Jump frequency Jump width d3-04 frequency width d3-04 Jump frequency reference Jump Jump Jump frequency frequency frequency...
Page 247 Adjusting Frequency References nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion Pulse train input function 0: Frequency reference selection H6-01 1: PID feedback value 0 to 2 2: PID target value Pulse Input Sel Pulse train input scaling...
Page 248: Speed Limit (Frequency Reference Limit Function)
Speed Limit (Frequency Reference Limit Func- tion) This section explains how to limit the motor speed. K K K K Limiting Maximum Output Frequency If you do not want the motor to rotate above a given frequency, use parameter d2-01. Set the upper limit value of the Inverter output frequency as a percent, taking E1-04 (Maximum Output Fre- quency) to be 100%.
Page 249 Speed Limit (Frequency Reference Limit Function) nAdjusting Frequency Lower Limit Using an Analog Input If you set parameter H3-09 (Multi-function Analog Input Terminal A2 Function Selection) to 9 (output fre- quency lower level), you can adjust the frequency lower level using the terminal A2 input level. Output frequency lower level Max.
Page 250: Improved Operating Efficiency
Improved Operating Efficiency This section explains functions for improving motor operating efficiency. K K K K Reducing Motor Speed Fluctuation (Slip Compensation Function) When the load is large, the amount of motor slip also grows large and the motor speed decreases. The slip compensation function controls the motor at a constant speed, regardless of changes in load.
Page 251 Improved Operating Efficiency nAdjusting Slip Compensation Gain The C3-01 parameter is initialized as shown below for the control method. V/f control without PG: 0.0 • Open loop vector control: 1.0 • Set C3-01 to 1.0 to compensate the rated slip set using the rated torque output status. Adjust the slip compensation gain using the following procedure.
Page 252: Compensating For Insufficient Torque At Startup And Low-Speed Operation (Torque Compensation)
nSelecting Slip Compensation Function During Regeneration Set whether to enable or disable the slip compensation function during regeneration. For the slip compensation function operates during regeneration, the braking option (braking resistor, Braking Resistor Unit, and Braking Unit) may be useful to momentarily increase the regenerative amount. nSelecting Output Voltage Limit Operation If output voltage saturation occurs while the output voltage limit operation is disabled, the output current will not change, but torque control accuracy will be lost.
Page 253 Improved Operating Efficiency nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion Set the torque compensation gain using the multi- plication factor. Normally, there is no need to Torque compensation gain change this parameter.
Page 254: Hunting-Prevention Function
nAdjusting the Torque Compensation Primary Delay Time Constant Set the torque compensation function primary delay in ms. The factory setting is related to the control method as follows: • V/f control without PG: 200 ms • V/f control with PG: 200 ms open loop vector control: 20 ms •...
Page 255: Stabilizing Speed (Speed Feedback Detection Function)
Improved Operating Efficiency K K K K Stabilizing Speed (Speed Feedback Detection Function) The speed feedback detection control (AFR) stabilizes the speed when a load changes swiftly. The speed is compensated by the amount of fluctuation from the current feedback torque. nRelated Parameters Name Control Methods...
Page 256: Machine Protection
Machine Protection This section explains functions for protecting the machine. K K K K Limiting Motor Torque (Torque Limit Function) The motor torque limit function is enabled only in open-loop vector control. The output torque to the motor is calculated internally in open loop vector control. The Torque Limit Function limits this internal torque value to output within a user set value.
Page 257 Machine Protection Output torque Positive Positive/negative torque limits Forward torque limit Regenerative torque limit No. of motor rotations Forward operation Reverse operation Regenerative torque limit Negative torque limit Positive/negative torque limits Negative Fig 6.35 Torque Limit by Analog Input nSetting Torque Limits Using Parameters and an Analog Input The following block diagram shows the relationship between torque limit using parameters and torque limit using an analog input.
Page 258: Preventing Motor Stalling During Operation
nSetting Precautions When the torque limit function is operating, control and compensation of the motor speed is disabled • because torque control is given priority. When using the torque limit to raise and lower loads, do not carelessly lower the torque limit value, as this •...
Page 259: Changing Stall Prevention Level During Operation Using An Analog Input
Machine Protection K K K K Changing Stall Prevention Level during Operation Using an Analog Input If you set H3-09 (Multi-function Analog Input Terminal A2 Function Selection) to 8 (stall prevention during operation level), you can change the stall level during operation by setting H3-10 (Gain (Terminal A2)) and H3-11 (Bias (Terminal A2)).
Page 260 nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion 0: Overtorque/undertorque detection disabled. 1: Overtorque detection only with speed agree- ment; operation continues after overtorque (warning). 2: Overtorque detected continuously during oper- Torque detection selection ation;...
Page 261 Machine Protection nL6-01 and L6-04 Set Values and LED Indicators The relationship between alarms displayed by the Digital Operator when overtorque or undertorque is detected, and the set values in L6-01 and L6-04, is shown in the following table. LED Indicator Overtorque/ Overtorque/ Function...
Page 262: Changing Overtorque And Undertorque Detection Levels Using An Analog Input
• Undertorque Detection Motor current (output torque) L6-02 or L6-05 L6-03 L6-03 Undertorque detection 1 NO or Undertorque detection 2 NO L6-06 L6-06 The undertorque detection disabled margin is approximately 10% of the Inverter rated output current (or motor rated torque) K K K K Changing Overtorque and Undertorque Detection Levels Using an Ana- log Input...
Page 263: Motor Overload Protection
Machine Protection K K K K Motor Overload Protection You can protect the motor from overload using the Inverter's built-in electronic thermal overload relay. nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display...
Page 264 nSetting Motor Rated Current Set the rated current value on the motor nameplate in parameters E2-01 (for motor 1) and E4-01 (for motor 2). This set value is the electronic thermal base current. nSetting Motor Overload Protection Characteristics Set the overload protection function in L1-01 according to the applicable motor. The induction motor's cooling abilities differ according to the speed control range.
Page 265 Machine Protection nSetting Motor Protection Operation Time Set the motor protection operation time in L1-02. If, after operating the motor continuously at the rated current, a 150% overload is experienced, set the (hot start) electronic thermal protection operation time. The factory setting is resistance to 150% for 60 seconds. The following diagram shows an example of the characteristics of the electronic thermal protection operation time (L1-02 = 1.0 min., operation at 60 Hz, general-purpose motor characteristics, when L1-01 is set to 1) Operating time (min.)
Page 266: Motor Overheating Protection Using Ptc Thermistor Inputs
K K K K Motor Overheating Protection Using PTC Thermistor Inputs Perform motor overheating protection using the thermistor temperature resistance characteristics of the PTC (Positive Temperature Coefficient) built into the windings of each motor phase. nRelated Parameters Name Control Methods Param- Change Open...
Page 267: Limiting Motor Rotation Direction
Machine Protection nOperation during Motor Overheating Set the operation if the motor overheats in parameters L1-03 and L1-04. Set the motor temperature input filter time parameter in L1-05. If the motor overheats, the OH3 and OH4 error codes will be displayed on the Digi- tal Operator.
Page 268: Continuing Operation
Continuing Operation This section explains functions for continuing or automatically restarting Inverter operation even if an error occurs. K K K K Restarting Automatically After Power Is Restored Even if a temporary power loss occurs, you can restart the Inverter automatically after power is restored to continue motor operation.
Page 269: Speed Search
Continuing Operation If the momentary power loss operation selection is set to 0 (Disabled), when the momentary power loss • exceeds 15 ms during operation, alarm UV1 (main circuit undervoltage) will be detected. K K K K Speed Search The speed search function finds the actual speed of the motor that is rotating using inertia, and then starts smoothly from that speed.
Page 270 Multi-function Digital Inputs (H1-01 to H1-05) Control Methods Open Function Loop Value with Vec- External search command 1 OFF: Speed search disabled (Start from lowest output frequency) ON: Speed estimation (Estimate the motor speed, and start search from estimated speed) Current detection (Start speed search from maximum output frequency) External search command 2 OFF: Speed search disabled (Start from lowest output frequency)
Page 271 Continuing Operation nSpeed Search Selection Set whether to enable or disable speed search at startup, and set the type of speed search (estimated speed or current detection) using setting b3-01. To perform speed search when inputting the run command, set b3-01 to 1 or 3.
Page 272 Speed Search after Short Baseblock (during Power Loss Recovery, etc.) • Loss Time Shorter Than the Minimum Baseblock Time (L2-03) AC power supply Set frequency Start using reference speed detected Output frequency Output current 10 ms *1 Baseblock time may be reduced by the output frequency immediately before the baseblock.
Page 273 Continuing Operation Deceleration time set in b3-03 Run command Maximum output Set frequency frequency or reference set frequency Output frequency b3-02 Output current * Lower limit is set using Speed Search Time (b3-05). Minimum baseblock time (L2-03) Fig 6.45 Speed Search at Startup (Using Current Detection) Speed Search after Short Baseblock (during Power Loss Recovery, etc.) Loss Time Shorter Than Minimum Baseblock Time •...
Page 274: Continuing Operation At Constant Speed When Frequency Reference Is Lost
K K K K Continuing Operation at Constant Speed When Frequency Reference Is Lost The frequency reference loss detection function continues operation using 80% speed of the frequency refer- ence before loss when the frequency reference using an analog input is reduced 90% or more in 400 ms. When the error signal during frequency reference loss is output externally, set H2-01 to H2-03 (multi-function contact output terminal M1-M2, P1-PC/M3-M4, and P2-PC/M5-M6 function selection) to C (frequency refer- ence lost).
Page 275 Continuing Operation nAuto Restart External Outputs To output auto restart signals externally, set H2-01 to H2-03 (multi-function output terminals M1-M2, M3- M4, M5-M6, P1-PC, and P2-PC function selection) to 1E (auto restart). nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory...
Page 276: Inverter Protection
Inverter Protection This section explains the functions for protecting the Inverter and the braking resistor. K K K K Performing Overheating Protection on Mounted Braking Resistors Perform overheating protection on Inverter-mounted braking resistors (3G3IV-PERFo). When overheating in a mounted braking resistor is detected, an alarm RH (Mounted braking resistor overheat- ing) is displayed on the Digital Operator, and the motor coasts to a stop.
Page 277: Reducing Inverter Overheating Pre-Alarm Warning Levels
Inverter Protection K K K K Reducing Inverter Overheating Pre-Alarm Warning Levels The Inverter detects the temperature of the cooling fins using the thermistor, and protects the Inverter from ° overheating. You can receive Inverter overheating pre-alarms in units of 10 The following overheating pre-alarm warnings are available: Stopping the Inverter as error protection, and continuing operation, with the alarm OH (Radiation fins overheating) on the Digital Operator flashing.
Page 278: Input Terminal Functions
Input Terminal Functions This section explains input terminal functions, which set operating methods by switching functions for the multi-function contact input terminals (S3 to S7). K K K K Temporarily Switching Operation between Digital Operator and Control Circuit Terminals You can switch the Inverter run command inputs and frequency reference inputs between local (i.e., Digital Operator) and remote (input method using b1-01 and b1-02).
Page 279: Blocking Inverter Outputs (Baseblock Commands)
Input Terminal Functions K K K K Blocking Inverter Outputs (Baseblock Commands) Set 8 or 9 (Baseblock command NO/NC) in one of the parameters H1-01 to H1-05 (multi-function input ter- minal S3 to S7 function selection) to perform baseblock commands using the terminal's ON/OFF operation, and prohibit Inverter voltage output using the baseblock commands.
Page 280: Stopping Acceleration And Deceleration (Acceleration/Deceleration Ramp Hold)
K K K K Stopping Acceleration and Deceleration (Acceleration/Deceleration Ramp Hold) The acceleration/deceleration ramp hold function stops acceleration and deceleration, stores the output fre- quency at that point in time, and then continues operation. Set one of the parameters H1-01 to H1-05 (multi-function input terminal S3 to S7 function selection) to A (acceleration/deceleration ramp hold) to stop acceleration and deceleration when the terminal is turned ON and to store the output frequency at that point in time.
Page 281: Raising And Lowering Frequency References Using Contact Signals (Up/Down)
Input Terminal Functions nApplication Precautions When d4-01 is set to 1, the output frequency on hold is stored even after the power supply is turned OFF. If • performing operations using this frequency after the Inverter has also been turned OFF, input the run com- mand with the Acceleration/Deceleration Ramp Hold turned ON.
Page 282 Application Precautions • Frequency outputs using UP/DOWN commands are limited by the frequency reference upper and lower limits set in parameters d2-01 to d2-03. Here, frequency references from analog frequency reference termi- nal A1 becomes the frequency reference lower limit. If using a combination of the frequency reference from terminal A1 and the frequency reference lower limit set in either parameter d2-02 or d2-03, the larger lower limit will become the frequency reference lower limit.
Page 283 Input Terminal Functions Output frequency Upper limit Accelerates to lower limit Same frequency Lower limit Forward operation/stop UP command Reference frequency reset DOWN command Frequency matching signal* Power supply * The frequency matching signal turns ON when the motor is not accelerating/ decelerating while the run command is ON.
Page 284: Accelerating And Decelerating Constant Frequencies In The Analog References (+/- Speed)
K K K K Accelerating and Decelerating Constant Frequencies in the Analog Refer- ences (+/- Speed) The +/- speed function increments or decrements the frequency set in analog frequency reference d4-02 (+/- Speed Limit) using two contact signal inputs. To use this function, set one of the parameters H1-01 to H1-05 (multi-function terminal inputs S3 to S7 func- tion selection) to 1C (Trim Control Increase command) and 1D (Trim Control Decrease command).
Page 285: Hold Analog Frequency Using User-Set Timing
Input Terminal Functions K K K K Hold Analog Frequency Using User-set Timing When one of H1-01 to H1-05 (multi-function input terminal S3 to S7 function selection) is set to 1E (sample/ hold analog frequency command), the analog frequency reference will be held from 100 ms after the terminal is turned ON, and operation will continue thereafter at that frequency.
Page 286: Switching Operations Between A Communications Option Card And Control Circuit Terminals
K K K K Switching Operations between a Communications Option Card and Con- trol Circuit Terminals You can switch reference input between the Communications Option Card and the control circuit terminals. Set one of the parameters H1-01 to H1-05 (multi-function input terminal S3 to S7 function selection) to 2 (Option/Inverter selection) to enable switching reference input using the terminal ON/OFF status when the Inverter is stopped.
Page 287: Stopping The Inverter By Notifying Programming Device Errors To The Inverter (External Error Function)
Input Terminal Functions nApplication Precautions Jog frequencies using FJOG and RJOG commands are given priority over other frequency references. • • When both FJOG command and RJOG commands are ON for 500 ms or longer at the same time, the Inverter stops according to the setting in b1-03 (stopping method selection).
Page 288: Monitor Parameters
Monitor Parameters This section explains the analog monitor and pulse monitor parameters. K K K K Using the Analog Monitor Parameters This section explains the analog monitor parameters. nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num-...
Page 289 Monitor Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion Channel 1 monitor selec- tion F4-01 1 to 40 Effective when the Analog Monitor Card is used. AO Ch1 Select Monitor selection: Set the number of the monitor item to be output.
Page 290: Using Pulse Train Monitor Parameters
10 V/100% monitor output × output gain + output bias Output voltage Gain x 10 V Bias x 10/100 V Monitor item Fig 6.53 Monitor Output Adjustment nSwitching Analog Monitor Signal Levels Monitor items corresponding to 0 to ±10 V output 0 to 10 V signals when the monitor value is positive (+), and 0 to -10 V signals when the monitor value is negative (-).
Page 291 Monitor Parameters nAdjusting the Pulse Monitor Items Adjust the pulse frequency output from pulse monitor terminal MP-SC. Set the pulse frequency output when 100% frequency is output to H6-07. Set H6-06 to 2, and H6-07 to 0, to output the frequency synchronous with the Inverter's U-phase output. nApplication Precautions When using a pulse monitor parameter, connect a peripheral device according to the following load condi- tions.
Page 292: Communications Functions
Communications Functions This section explains the individual communications functions. K K K K Using RS-422A/485 Communications You can perform serial communications with SYSMAC CS-series Programmable Controllers (PLCs) or simi- lar devices using the RS-422A/485 protocol. nRelated Parameters Name Control Methods Param- Change Open...
Page 293 Communications Functions Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion Bit 0: CRC error Bit 1: Data length error RS-422A/485 communica- Bit 2: Not used. tions error Bit 3: Parity error Bit 4: Overrun error U1-39...
Page 294 nCommunications Specifications The RS-422A/485 communications specifications are shown in the following table. Item Specifications Interface RS-422, RS-485 Communications Cycle Asynchronous (Start-stop synchronization) Baud rate: Select from 1,200, 2,400, 4,800, 9,600, and 19,200 bps. Data length: 8 bits fixed Communications Parameters Parity: Select from even, odd, or none.
Page 295 Communications Functions nConnection Example to a PLC This section provides a connector pin arrangements and standard wiring diagram for the Serial Communica- tions Boards/Units. Connector Pin Arrangement for Serial Communications Board/Unit The connector pin arrangement for the CS1W-SCB41, CS1W-SCU41, and C200HW-COM06-V1 Serial Com- munications Boards/Units is shown below.
Page 296 • RS-422A (4-wire) Communications Board SYSDRIVE RV B500-AL001 Link Adapter Pin No. Code Shielded cable Code Shielded cable Code Pin No. Pin No. Code Control cir- cuit terminal block (com- RS-422A RS-422A/485 munictions terminals) interface interface Hood RS-422A RS-422A 9-pin D-sub connector Code SDA SDB RDA RDB SG (Connector on cable: Male)
Page 297 Communications Functions Slave Address Set the Inverter address from 0 to 32. If you set 0, commands from the master will be broadcast (i.e., the Inverter will not return responses). Function Code The function code specifies commands. There are three function codes, as shown below. Command Message Response Message Function Code...
Page 298 nDSR Message An example of command/response messages is given below. Reading Storage Register Contents (Function Code: 03 Hex) Read the contents of the storage register only for specified quantities whose addresses are consecutive, starting from a specified address. The contents of the storage register are separated into higher place 8 bits and lower place 8 bits, and comprise the data within response messages in address order.
Page 299 Communications Functions Loopback Test (Function Code: 08 Hex) The loopback test returns command messages directly as response messages without changing the contents to check the communications between the master and slave. You can set user-defined test code and data values. The following table shows a message example when performing a loopback test with the slave 1 Inverter.
Page 300 Set the number of data specified using command messages as quantity of specified messages x 2. Handle response messages in the same way. INFO nData Tables The data tables are shown below. The types of data are as follows: Reference data, monitor data, and broadcast data.
Page 301 Communications Functions Register No. Contents Reference selection settings Bit 0 Not used Bit 1 PID target value (register 0006H) 1: Enabled 0: Disabled Bits 3 to B Not used 000FH Broadcast data S5 1: Enabled 0: Disabled Broadcast data S6 1: Enabled 0: Disabled Broadcast data S7 1: Enabled 0: Disabled Not used Note Write 0 to all unused bits.
Page 302 Register No. Contents Data link status Bit 0 Writing data Bit 1 Not used 0022H Bit 2 Not used Bit 3 Upper and lower limit errors Bit 4 Data integrity error Bits 5 to F Not used Frequency ref- 0023H Monitors U1-01 erence Output fre-...
Page 303 Communications Functions Register No. Contents Inverter status Bit 0 Operation 1: Operating Bit 1 Zero speed 1: Zero speed Bit 2 Frequency matching 1: Matched Bit 3 User-defined speed matching 1: Matched 1: Output frequency ≤ L4-01 Bit 4 Frequency detection 1 Output frequency ≥...
Page 304 Register No. Contents 003EH kVA setting 003FH Control method Note Communications error details are stored until an error reset is input (you can also reset while the Unit is operating). Communications error details can also be read by using the register numbers given in the Register column in the U: Monitor parameter table. Broadcast Data The following table shows the broadcast data.
Page 305 Communications Functions nError Codes The following table shows RS-422A/485 communications error codes. Error Code Contents Function code error A function code other than 03H, 08H, or 10H has been set by the PLC. Invalid register number error • The register address you are attempting to access is not recorded anywhere. •...
Page 306 nSelf-Diagnosis The Inverter has a built-in function for self-diagnosing the operations of serial communications interface cir- cuits. This function is called the self-diagnosis function. The self-diagnosis function connects the communica- tions parts of the send and receive terminals, receives the data sent by the Inverter, and checks if communications are being performed normally.
Page 307 Communications Functions nConverting Register Data Register data (such as monitor values or parameter set value data) is placed in the communications data block of the message data (i.e., request message or response data). The data in each register is sent as 2-byte data. It is processed under the following rules and sent in hexadecimal.
Page 308: Communications With A Programmable Controller
MSB will be 1. 400.0 (Hz)/0.01 (Hz) = 40000 = 9C40 Hex Set All Unused Bits to 0 Bits 11 through 15 of the RUN command (register 0001H) are not used. When writing the data, be sure to set all of these bits to 0. These bits when read are set to 0. No Data Settings in Unused Registers Registers described “not used”...
Page 309 Communications Functions n Applicable Serial Communications Boards and Unit The following Serial Communications Boards and Unit can be used with the RS-422A/485 port. The RS-232C port can be used if an RS-422/485 Conversion Adapter is installed. For ease of wiring, however, it is recommended that the RS-422/485 port be used.
Page 310 Table 6.4 Peripheral Devices Name Model Specification The following peripheral devices support the protocol macro function of the SYSMAC C200HX/HG/HE series. Personal computer environment Personal com- IBM PC/AT or compatible computer puter Minimum requirement: Pentium 90 MHz Recommended: Pentium 166 MHz or faster Protocol Sup- WS01-PSTF1-E Microsoft Windows 95 or Windows 98...
Page 311 Communications Functions m = D30000 + 100 x Unit No. (Wd) DM Area Board Unit Setting Value Port 1 Port 2 Port 1 Port 2 Port setting -- 0: Default, 1*: Desired setting 14 to 12 Reserved Serial communications mode 11 to 08 (6 Hex*: Protocol macro) 07 to 05...
Page 312 Communications Board Setting Value Port 1 Port 2 Port A Port B Communications speed 00 Hex: 1,200 bps (default) 01 Hex: 2,400 bps 00 to 07 02 Hex: 4,800 bps 03 Hex*: 9,600 bps 04 Hex: 19,200 bps Frame format Stop Start Parity...
Page 313 Each component of a message is in the memory of the Communications Board. Therefore, the CPU Unit can just execute the PMCR instruction to send or receive the data, with no need to write ladder programs for the communications protocol. Serial Communications Board CPU Unit SYSDRIVE 3G3RV DSR message Send PMCR Instruction Reception Response Fig 6.62 Creating a Message...
Page 314 A method to write reception data to the I/O memory of the Programmable Controller. Response notify method Select “notify by scan” for communictions with the 3G3RV. Serial Communications Board CPU Unit SYSDRIVE 3G3RV Step 00 DSR message (Write the RUN command PMCR instruction and frequency response.)
Page 315 Communications Functions Step In a single step, a DSR message is sent and a response for the DSR message is received. A step may not include a response if it is a broadcast message. In the case of repetitive actions to issue the RUN command and frequency reference to the Inverter and read the status of the Inverter, for example, the actions to give the RUN command and frequency reference consti- tute one step.
Page 316 nData Created by Protocol Support Tool and CX-Protocol # RTQLGEV HKNG KU WUGF D[ VJG 2TQVQEQN 5WRRQTV 6QQN VQ ETGCVG CPF EQPVTQN FCVC # RTQLGEV HKNG EQPUKUVU QH VJG HQNNQYKPI FCVC Protocol list Protocol name Single project file Protocol name A maximum of 20 protocols (A maximum of 1,000 sequences per project) Protocol name...
Page 317 Communications Functions nCreating a Project File The following descripton provides information about how to create a project file to send the RUN command and frequency references to three Inverters and read the Inverter status. (“PST” indicates the WS01-PSTF1-J Protocol Support Tool.) First, select from I/O items, monitor items, and parameters the data to be exchanged according to the applica- tion.
Page 318 Communications SYSDRIVE Board 3G3RV C: Control data (See note.) 12 11 Communications Sequence No. PMCR port 000 to 999 BCD 1: Port A 2: Port B Word Data No. of data items sent in accordance with PMCR instruction 000B No. of Slaves 0003 First Slave address 0001 RUN command to Slave 1 Frequency reference to Slave 1...
Page 319 Communications Functions Communication Timer Timer Timer Link word Control Response sequence Inverter I/O Send & Set (Setting required) Scan Recv Sequence number. The sequence number is automatically set. Communication Sequence The label (name) of the sequence. Input an appropriate, easy-to-distinguish name. Link Word Set the area for sharing the data between the Programmable Controller and Communications Board.
Page 320 nCreating a Step 1. Double-click on New Protocol with the left button of the mouse. 2. Click on New Sequence with the left button of the mouse and click on a blank space with the right button of the mouse. 3.
Page 321 Communications Functions Response Determine whether or not to write the reception data in the response. Always set this parameter to Yes for communications with the 3G3RV. Next Determine which step is to be processed next or finish the operation after the step finishes normally. In this example, step 00 is set to Next and step 01 is set to END because the sequence completes be executing steps 00 and 01.
Page 322 Length <l> Set the length of the data. All communications with the 3G3RV are performed in byte units. Select 1 Byte and BIN. Select No for read- ing data because there is no data to be read. Address <a> Set the addresses of the Slaves. In this example, the Slave addresses are set in S + 2, S + 5, and S + 8.
Page 323 Communications Functions DSR Message to Read the Inverter Status • The DSR message to read the Inverter status from register 002C Hex consists of the following items. 0 3 0 0 2 C 0 0 0 1 CRC-16 check (Set with <c>) Number of read data registers: 1 Read start register number (Inverter status: 002C) Function code (Read 03)
Page 324 Length <l> Set the length of the data. All communications with the 3G3RV are performed in byte units. Select 1 Byte and BIN. Select No for read- ing data because there is no data to be read. Address <a> Set the addresses of the Slaves. In this example, the Slave addresses are set in S + 2, S + 5, and S + 8.
Page 325 Communications Functions Response to the Inverter Status Read • The response to the DSR message to request the Inverter status in register 002C Hex consists of the fol- lowing items. CRC-16 check (Set with <c>) Inverter status data (Set with variable) Number of bytes of attached data (Set with <l>) Function code (Write 10) Slave address (Set with <a>)
Page 326 Inverter Control Inputs (Register 0001 RUN Command) The Inverter control inputs for the register 0001 RUN command are listed in the following table. Word Slave 1 function Word Slave 2 function Word Slave 3 function 00100 RUN command 00200 RUN command 00300 RUN command 00101 Forward/Reverse 00201 Forward/Reverse...
Page 327 Communications Functions Inverter Control Outputs (Register 002C Inverter Status) The Inverter control outputs for register 002C Inverter status are listed in the following table. Word Slave 1 function Word Slave 2 function Word Slave 3 function 01100 During RUN 01200 During RUN 01300 During RUN 01101 Zero speed 01201 Zero speed...
Page 328 Status flags • Communications Port Enabled Flag Flag bit for communications port 7: A20207 Protocol Macro Execution Flag • The Protocol Macro Execution Flag is described below. Unit/Board Port 1 Port 2 CS1 Board CIO 190915 CIO 191915 Bit 15 of CIO n + CS1 Unit Bit 15 of CIO n + 9 n = CIO 1500 + (25 x number of units)
Page 329 Communications Functions Ladder Program Protocol Communications Macro Execution Port Enabled Flag * Flag Communications Port Abort Flag Fig 6.72 Ladder Program...
Page 330 The communications response times for communications with an Inverter via the RS-422/485 port of an Omron-made Communications Board are detailed below. Use this information as a reference when deciding the number of Slaves to be connected to one network, and when considering the timing of input and output signals.
Page 331 Communications Functions I/O Response Time The communications processing times for the Inverter are as follows. • Inverter communications input scan: 8 ms Inverter communications output scan: 8 ms • Internal processing time for the Inverter: Approx. 20 ms • The I/O response times for the Inverter are illustrated in the following diagram. Ladder program cycle time Communications time x 2 Inverter I/O scan...
Page 332: Individual Functions
Individual Functions This section explains the individual functions used in special applications. K K K K Using the Timer Function Multi-function contact input terminals S3 to S7 can be designated as timer function input terminals, and multi- function output terminals M1-M2, M3-M4, M5-M6, P1-PC, and P2-PC can be designated as timer function output terminals.
Page 333: Using Pid Control
Individual Functions K K K K Using PID Control PID control is a method of making the feedback value (detection value) match the set target value. By combin- ing proportional control (P), integral control (I), and derivative control (D), you can even control targets (machinery) with play time.
Page 334 nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion 0: Disabled PID control mode selection 1: Enabled (Deviation is D-controlled.) 2: Enabled (Feedback value is D-controlled.) b5-01 0 to 4 3: PID control enabled (frequency reference +...
Page 335 Individual Functions Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion PID sleep operation delay time Set the delay time until the PID sleep function 0.0 to b5-16 0.0 s starts in seconds.
Page 336 nPID Control Methods There are four PID control methods. Select the method by setting parameter b5-01. Set Value Control Method PID output becomes the Inverter output frequency, and D control is used in the difference between PID target value and feedback value. PID output becomes the Inverter output frequency, and D control is used in the PID feedback value.
Page 337 Individual Functions nPID Fine Adjustment Methods This section explains the fine adjustment of PID after setting the PID control constants. Suppressing Overshoot If overshoot occurs, reduce derivative time (D), and increase integral time (I). Response Before adjustment After adjustment Time Set a Rapidly Stabilizing Control Condition To rapidly stabilize the control even if overshoot occurs, reduce integral time (I), and lengthen derivative time (D).
Page 338 Suppressing Short Cycle Vibration If vibration occurs when the vibration cycle is short, and the cycle is almost identical to the derivative time (D) set value, the differential operation is too strong. Shorten the derivative time (D) to suppress the vibration. If vibration continues even when the derivative time (D) is set to 0.00 (D control disabled), reduce the propor- tional gain (P), or increase the PID primary delay time constant.
Page 339 Individual Functions nPID Control Block The following diagram shows the PID control block in the Inverter. Fig 6.76 PID Control Block...
Page 340 nPID Feedback Loss Detection When performing PID control, be sure to use the PID feedback loss detection function. If PID feedback is lost, the Inverter output frequency may accelerate to the maximum output frequency. When setting b5-12 to 1 and the status of the PID feedback value detection level in b5-13 is insufficient and continues for the time set in b5-14, an FbL (PID feedback reference lost) alarm will be displayed on the Digi- tal Operator and Inverter operation will continue.
Page 341: Energy-Saving
Individual Functions K K K K Energy-saving To perform energy saving, set b8-01 (Energy Saving Mode Selection) to 1. Energy-saving control can be per- formed using both V/f control and open loop vector control. The parameters to be adjusted are different for each.
Page 342 nAdjusting Energy-saving Control The method of adjustment during energy-saving control operations differs depending on the control method. Refer to the following when making adjustments. V/f Control In V/f control method, the voltage for optimum motor efficiency is calculated and becomes the output voltage reference.
Page 343: Setting Motor Constant Parameters
Individual Functions K K K K Setting Motor Constant Parameters In vector control method, the motor constant parameter are set automatically using autotuning. If autotuning does not complete normally, set them manually. nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory...
Page 344 nManual Motor Constant Parameter Setting Methods The motor constant parameters settings methods are given below. Make (enter) settings referring to the motor test report. Motor Rated Current Setting Set E2-01 to the rated current on the motor nameplate. Motor Rated Slip Setting Set E2-02 to the motor rated slip calculated from the number of rated rotations on the motor nameplate.
Page 345: Setting The V/F Pattern
Individual Functions K K K K Setting the V/f Pattern In V/f control method, you can set the Inverter input voltage and the V/f pattern as the need arises. nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop...
Page 346 nSetting Inverter Input Voltage Set the Inverter input voltage correctly in E1-01 to match the power supply voltage. This set value will be the standard value for the protection function and similar functions. nSetting V/f Pattern Set the V/f pattern in E1-03. There are two methods of setting the V/f pattern: Select one of the 15 pattern types (set value: 0 to E) that have been set beforehand, or set a user-defined V/f pattern (set value: F).
Page 347 Individual Functions 0.4 to 1.5 kW V/f Pattern The diagrams show characteristics for a 200-V class motor. For a 400-V class motor, multiply all voltages by Constant Torque Characteristics (Set Value: 0 to 3) • Set Value 0 50 Hz Set Value 1 60 Hz Set Value 2...
Page 348 2.2 to 45 kW V/f Pattern The diagrams show characteristics for a 200-V class motor. For a 400-V class motor, multiply all voltages by Constant Torque Characteristics (Set Value: 0 to 3) • Set Value 0 50 Hz Set Value 1 60 Hz Set Value 2 60 Hz...
Page 349 Individual Functions 55 to 300 kW V/f Pattern The diagrams show characteristics for a 200-V class motor. For a 400-V class motor, multiply all voltages by Constant Torque Characteristics (Set Value: 0 to 3) • Set Value 0 50 Hz Set Value 1 60 Hz Set Value 2...
Page 350 When E1-03 is set to F (User-defined V/f pattern), you can set parameters E1-04 to E1-10. If E1-03 is set to anything other than F, you can only refer to parameters E1-04 to E1-10. If the V/f characteristics are linear, set E1-07 and E1-09 to the same value.
Page 351: Digital Operator Functions
Digital Operator Functions Digital Operator Functions This section explains the Digital Operator functions. K K K K Setting Digital Operator Functions You can set Digital Operator-related parameters such as selecting the Digital Operator display, multi-function selections, and copy functions. nRelated Parameters Name Control Methods Param-...
Page 352 Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion Frequency reference set- Sets the operation when the Digital Operator is ting method selection disconnected. 0: Enter key needed o2-05 0 or 1 1: Enter key not needed...
Page 353: Copying Parameters
Digital Operator Functions nInitializing Changed Parameter Values You can save to the Inverter parameter set values that you have changed as parameter initial values. Change the set values from the Inverter factory settings, and then set o2-03 to 1. Set A1-03 (Initialize) to 1110 to initialize the Inverter parameters using the user-set initial values in memory. To clear the user-set initial values in memory, set o2-03 to 2.
Page 354 nStoring Inverter set values in the Digital Operator (READ) To store Inverter set values in the Digital Operator, make the settings using the following method. Set o3-02 (Read permitted selection) to 1 (read permitted). Table 6.6 READ Function Procedure Step Digital Operator Display Explanation Press the Menu Key, and select advanced pro-...
Page 355 Digital Operator Functions nWriting Parameter Set Values Stored in the Digital Operator to the Inverter (COPY) To write parameter set values stored in the Digital Operator to the Inverter, make the settings using the follow- ing method. Table 6.7 COPY Function Procedure Step Digital Operator Display Explanation...
Page 356 nComparing Inverter Parameters and Digital Operator Parameter Set Values (VERIFY) To compare Inverter parameters and Digital Operator parameter set values, make the settings using the follow- ing method. Table 6.8 VERIFY Function Procedure Step Digital Operator Display Explanation Press the MENU Key. and select advanced pro- gramming mode.
Page 357: Prohibiting Writing Parameters From The Digital Operator
Digital Operator Functions K K K K Prohibiting Writing Parameters from the Digital Operator If you set A1-01 to 0, you can refer to and set the A1 and A2 parameter groups, and refer to drive mode, using the Digital Operator. If you set one of the parameters H1-01 to H1-05 (multi-function contact input terminal S3 to S7 function selection) to 1B (write parameters permitted), you can write parameters from the digital operator when the ter- minal that has been set is ON.
Page 358: Displaying User-Set Parameters Only
Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion Used to set a four digit number as the password. Password setting This parameter is not usually displayed. When the 0 to A1-05 password (A1-04) is displayed, hold down the...
Page 359: Options
Options Options This section explains the Inverter option functions. K K K K Performing Speed Control with PG This section explains functions with V/f control with PG. nRelated Parameters Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range...
Page 360 Name Control Methods Param- Change Open eter Setting Factory during Description Loop Num- Range Setting Opera- LCD Display with Vec- tion Overspeed (OS) detection level F1-08 0 to 120 115% Sets the overspeed detection method. PG Overspd Level Frequencies above that set for F1-08 (set as a per- centage of the maximum output frequency) that Overspeed detection delay continue to exceed this frequency for the time set...
Page 361 Options Inverter Motor PG (encoder) Forward command Pulse output A-phase driven when set value = 0 B-phase driven when set value = 1 A-phase A-phase B-phase B-phase Example: Forward rotation of standard Yaskawa motor (PG used: E6B2-CWZ6C) Motor output axis rotates counter-clockwise during In- Forward verter forward command.
Page 362 nSetting PG Pulse Monitor Output Dividing Ratio This function is enabled only when using PG speed control card 3G3FV-PPGB2. Set the dividing ratio for the PG pulse monitor output. The set value is expressed as n for the higher place digit, and m for the lower place 2 digits.
Page 363: Troubleshooting
Chapter 7 Troubleshooting This chapter describes the fault displays and countermeasures for the Inverter, and motor prob- lems and countermeasures. Protective and Diagnostic Functions ......7-2 Troubleshooting ............7-15...
Page 364: Protective And Diagnostic Functions
Protective and Diagnostic Functions This section describes the alarm functions of the Inverter. The alarm functions include fault detection, alarm detection, operation error detection, and autotuning error detection. K K K K Fault Detection When the Inverter detects a fault, the fault contact output operates, and the Inverter output is shut OFF causing the motor to coast to a stop.
Page 365 Protective and Diagnostic Functions Table 7.1 Fault Displays and Processing (Continued) Display Meaning Probable Causes Corrective Actions Main Circuit Undervoltage The main circuit DC voltage is below • An open-phase occurred with the the Undervoltage Detection Level input power supply. (L2-05).
Page 366 Table 7.1 Fault Displays and Processing (Continued) Display Meaning Probable Causes Corrective Actions Check the size of the load and the length of the acceleration, deceler- Motor Overheating Alarm ation, and cycle times. The Inverter will stop or will continue The motor has overheated.
Page 367 Protective and Diagnostic Functions Table 7.1 Fault Displays and Processing (Continued) Display Meaning Probable Causes Corrective Actions • Make sure the load is an inertial High-slip Braking OL load. The inertia returned to the load is too The output frequency did not change •...
Page 368 Table 7.1 Fault Displays and Processing (Continued) Display Meaning Probable Causes Corrective Actions Check the Communications External fault input from Communi- Option Card and communications Opt Exter- cations Option Card signals. nal Flt External fault (Input terminal 3) Ext Fault External fault (Input terminal 4) Ext Fault •...
Page 369 Protective and Diagnostic Functions Table 7.1 Fault Displays and Processing (Continued) Display Meaning Probable Causes Corrective Actions Try turning the power supply off and on again. Baseblock circuit error BB Circuit The control circuit is damaged. Replace the Inverter. Try turning the power supply off and on again.
Page 370: Alarm Detection
K K K K Alarm Detection Alarms are detected as a type of Inverter protection function and do not operate the fault contact output. The system will automatically return to its original status once the cause of the alarm has been removed. The Digital Operator display flashes and the alarm is output from the multi-function outputs (H2-01 to H2- 03).
Page 371 Protective and Diagnostic Functions Table 7.2 Alarm Displays and Processing (Continued) Display Meaning Probable causes Corrective Actions Overtorque 1 • Make sure that the settings in L6-02 (blink- There has been a current greater than and L6-03 are appropriate. ing) the setting in L6-02 for longer than the •...
Page 372 Table 7.2 Alarm Displays and Processing (Continued) Display Meaning Probable causes Corrective Actions (blink- External fault (Input terminal S3) ing) Ext Fault (blink- External fault (Input terminal S4) ing) Ext Fault • Reset external fault inputs to the An external fault was input from a (blink- multi-function inputs.
Page 373: Operation Errors
Protective and Diagnostic Functions K K K K Operation Errors An operation error will occur if there is an invalid setting or a contradiction between two parameter settings. It won't be possible to start the Inverter until the parameters have been set correctly. (The alarm output and fault contact outputs will not operate either.) When an operation error has occurred, refer to the following table to identify and correct the cause of the errors.
Page 374: Errors During Autotuning
Table 7.3 Operation Error Displays and Incorrect Settings (Continued) Display Meaning Incorrect settings Parameters E1-04, E1-06, E1-07, and E1-09 do not satisfy the following conditions: • E1-04 (FMAX) ≥ E1-06 (FA) > E1-07 (FB) ≥ E1-09 (FMIN) V/f data setting error V/f Ptrn •...
Page 375: Errors When Using The Digital Operator Copy Function
Protective and Diagnostic Functions Table 7.4 Errors During Autotuning (Continued) Display Meaning Probable causes Corrective Actions • If the motor is connected to the Motor speed error machine, disconnect it. The torque reference was too high (detected only for • Increase C1-01 (Acceleration Time 1). (100%) during acceleration (for open rotational autotuning) •...
Page 376 Table 7.5 Errors during Copy Function Func- Display Meaning Probable causes Corrective Actions tion o3-01 was set to 1 to write a parameter Digital Operator Set o3-02 to 1 to enable writing when the Digital Operator was write- READ write-protected parameters with the Digital Operator.
Page 377: Troubleshooting
Troubleshooting Troubleshooting Due to parameter setting errors, faulty wiring, and so on, the Inverter and motor may not operate as expected when the system is started up. If that should occur, use this section as a reference and apply the appropriate measures.
Page 378: If The Motor Does Not Operate
K K K K If the Motor Does Not Operate Use the following information if the motor does not operate. nThe motor does not operate when the RUN Key on the Digital Operator is pressed. The following causes are possible. If the Inverter is not in drive mode, it will remain in ready status and will not start.
Page 379 Troubleshooting The operation method selection is wrong. If parameter b1-02 (reference selection) is set to 0 (Digital Operator), the motor will not operate when an external operation signal is input. Set b1-02 to 1 (control circuit terminal) and try again. Similarly, the motor will also not operate if the LOCAL/REMOTE Key has been pressed to switch to Digital Operator operation.
Page 380: If The Direction Of The Motor Rotation Is Reversed
K K K K If the Direction of the Motor Rotation is Reversed If the motor operates in the wrong direction, the motor output wiring is faulty. When the Inverter T1(U), T2(V), and T3(W) are properly connected to the motor T1(U), T2(V), and T3(W), the motor operates in a for- ward direction when a forward run command is executed.
Page 381: If The Slip Compensation Function Has Low Speed Precision
Troubleshooting nThe analog frequency reference bias setting is wrong (the gain setting is wrong). The frequency reference bias set in parameter H3-03 is added to the frequency reference. Check to be sure that the set value is suitable. nA signal is being input to the frequency reference (current) terminal A1. When 1F (frequency reference) is set for parameter H3-09 (Multi-function Analog Input Terminal A2 Func- tion Selection), a frequency corresponding to the terminal A2 input voltage (current) is added to the frequency reference.
Page 382: If The Motor Overheats
The torque limit has been reached. When a torque limit has been set in parameters L7-01 to L7-04, no torque will be output beyond that limit. This can cause the deceleration time to be too long. Check to be sure that the value set for the torque limit is suitable.
Page 383: If There Is Noise When The Inverter Is Started Or From An Am Radio
Troubleshooting (i.e., 1,200 V for 400 V class). Be sure to use a motor with a withstand voltage between the motor phases that is greater than the maximum surge voltage. In particular, when using a 400 V class Inverter, use a special motor for Inverters.
Page 384: If The Ground Fault Interrupter Operates When The Inverter Is Run
K K K K If the Ground Fault Interrupter Operates When the Inverter Is Run The Inverter performs internal switching, so there is a certain amount of leakage current. This may cause the ground fault interrupter to operate and cut off the power supply. Change to a ground fault interrupter with a high leakage detection level (i.e., a sensitivity current of 200 mA or greater per Unit, with an operating time of 0.1 s or more), or one that incorporates high frequency countermeasures (i.e., one designed for use with Invert- ers).
Page 385: If The Motor Rotates Even When Inverter Output Is Stopped
Troubleshooting nOscillation and hunting are occurring with V/f control. The gain adjustment may be insufficient. Reset the gain to a more effective level by adjusting parameters C4- 02 (Torque Compensation Primary Delay Time Constant), N1-02 (Hunting Prevention Gain), and C3-02 (Slip Compensation Primary Delay Time) in order.
Page 386: If 0 V Is Detected When The Fan Is Started, Or The Fan Stalls
executed, it means that the DC injection braking is not decelerating enough. Adjust the DC injection braking as follows: • Increase the parameter b2-02 (DC Injection Braking Current) setting. • Increase the parameter b2-04 (DC Injection Braking (initial excitation) Time at Stop) setting. K K K K If 0 V Is Detected When the Fan Is Started, or the Fan Stalls Generation of 0 V (main circuit voltage) and stalling can occur if the fan is turning when it is started.
Page 387 Troubleshooting nIncorrect operation due to sneak current. The Inverter input can become indefinitely ON due to an unwanted current path in the control section output. If, in the wiring diagram shown below, the output power supply for the control section is lower than 24 VDC or the power supply is OFF, current will flow as shown by the arrows and the Inverter input will operate.
Page 389: Maintenance And Inspection
Chapter 8 Maintenance and Inspection This chapter describes basic maintenance and inspection for the Inverter Maintenance and Inspection........8-2...
Page 390: Maintenance And Inspection
Maintenance and Inspection K K K K Daily Inspection Check the following items with the system in operation. • The motor should not be vibrating or making unusual noises. There should be no abnormal heat generation. • • The ambient temperature should not be too high. The output current value shown on the monitor displays should not be higher than normal.
Page 391 Maintenance and Inspection Periodic inspection standards vary depending on the Inverter's installation environment and usage conditions. The Inverter's maintenance periods are noted below. Keep them as reference. Fig 8.2 Part Replacement Guidelines Part Standard Replacement Period Replacement Method Cooling fan 2 to 3 years Replace with new part.
Page 392: Cooling Fan Replacement Outline
K K K K Cooling Fan Replacement Outline n200-V and 400-V Class Inverters of 18.5 kW or Less A cooling fan is attached to the bottom of the Inverter. If the Inverter is installed using the mounting holes on the back of the Inverter, the cooling fan can be replaced without removing the Inverter from the installation panel.
Page 393 Maintenance and Inspection n200-V and 400-V Class Inverters of 22 kW or More A cooling fan is attached to the top panel inside the Inverter. The cooling fan can be replaced without removing the Inverter from the installation panel. Removing the Cooling Fan 1.
Page 394: Removing And Mounting The Control Circuit Terminal Card
K K K K Removing and Mounting the Control Circuit Terminal Card The control circuit terminal card can be removed and mounted without disconnecting the cables. Always confirm that the charge indicator is not lit before removing or mounting the control circuit terminal card.
Page 395: Specifications
Chapter 9 Specifications This chapter describes the basic specifications of the Inverter and specifications for options and peripheral devices. Standard Inverter Specifications ........9-2 Specifications of Options and Peripheral Devices ..9-5 Options and Peripheral Devices ........9-6...
Page 396: Standard Inverter Specifications
Standard Inverter Specifications The standard Inverter specifications are listed by capacity in the following tables. K K K K Specifications by Model Specifications are given by model in the following tables. n200-V Class Inverters Table 9.1 Specifications for 200-V Class Inverters Model A2004 A2007...
Page 397 Standard Inverter Specifications n400-V Class Inverters Table 9.2 Specifications for 400-V Class Inverters Model A4004 A4007 A4015 A4022 A4037 A4040 A4055 A4075 A4110 A4150 A4185 3G3RV- Max. applicable motor output (kW) 0.75 18.5 Rated output capacity (kVA) Output specifi- Rated output current (A) 12.5 cations Max.
Page 398: Common Specifications
K K K K Common Specifications The following specifications apply to both 200 V and 400 V Class Inverters. Table 9.3 Common Specifications Model Number Specification 3G3RV-o o o o Sine wave PWM Control method Open loop vector control, V/f control, V/f with PG control (switched by parameter setting) Speed control range 1:100 (Open loop vector control) Speed control accuracy...
Page 399: Specifications Of Options And Peripheral Devices
Specifications of Options and Peripheral Devices Specifications of Options and Peripheral Devices The following options and peripheral devices can be used for the Inverter. Select them according to the application. Table 9.4 Options and Peripheral Devices Purpose Name Model (Code) Description Always connect a breaker to the power supply line to pro- MCCB or Ground...
Page 400: Options And Peripheral Devices
Options and Peripheral Devices There are several types of options and peripheral devices for Inverters: Separately installed options, spe- cial options, Option Cards, and recommended separately installed options. The specifications of these options are provided in this sections. Special Options Separately Installed Options BRAKING UNIT WARNING...
Page 401 Controls noise generated by the Inverter so it does not enter the power supply. Con- 3G3IV-PLF @ (Tokin) nected to the motor output side. * 1. Recommended Options can be ordered from OMRON using the above model numbers. * 2. Not applicable to (-E) models.
Page 402: Fan Unit
K K K K Special Mounted Options The special mounted options are described in this section. n Fan Unit Replacement fan for Inverters equipped with a cooling fan. Replace the Cooling Fan when the fan replacement time has come or a cooling fan fault (FAN) alarm has been displayed.
Page 403: Separately Installed Options
Options and Peripheral Devices A A A A Separately Installed Options The separately installed options include Scaling Meters and Analog Operators. n Scaling Meters A Scaling Meter is attached to a multi-function analog output from the Inverter and is used to display rota- tional speeds of motors, line speeds, etc., in physical units.
Page 404 Wiring Example A wiring example for a Scaling Meter is shown below. MCCB Inside Inverter 3-phase power Inverter supply Analog output Analog monitor Dimensions The dimensions of a Scaling Meter are given below. Recommended Panel Cutout Dimensions Display LED Size Weight: 200 g...
Page 405 Options and Peripheral Devices n Analog Operators: Standard with Steel Panels or Small in Plastic An Analog Operator allows frequency reference settings and ON/OFF operation control to be performed by analog references from a remote location (50 m max.) 3G3IV-PJV0P96 @ 3G3IV-PJV0P95 @ Analog Operator Analog Operator...
Page 406 n Braking Unit A Braking Unit is used with a Braking Resistor Unit to reduce the deceleration time of the motor. It is not required with Inverters of 18.5 kW or less. BRAKING UNIT May cause injury or electric shock. Please follow the instructions in operation.
Page 407 Options and Peripheral Devices Dimensions The dimensions of a Braking Unit are given below. Mounting direction Four, mounting holes Three, wire pullout holes (with 22-mm-dia. rubber bushings)
Page 408: Braking Resistor Unit
n Braking Resistor Unit A Braking Resistor Unit is used to absorb the regenerative motor energy with a resistor to reduce deceleration time (use rate: 10% ED). A 10% ED means that the 10% of the operating cycle time can be used to control braking (deceleration time).
Page 409 Options and Peripheral Devices Dimensions The dimensions of a Braking Resistor Unit are given below. Dimensions (mm) Model No. Voltage Weight Dimensions 3G3IV- Mounting Class Diagram (kg) PLKEB o o o o Screws M5 × 3 20P7 M5 × 4 21P5 M5 ×...
Page 410 n Braking Resistors A Braking Resistor consumes the regenerative motor energy with a resistor to reduce deceleration time (use rate: 3% ED). A 3% ED means that the 3% of the operating cycle time can be used to control braking (decel- eration time).
Page 411: Digital Operator Connection Cable
Options and Peripheral Devices n Digital Operator Connection Cable Connected the Inverter to a Digital Operator in a remote locations. Both 1-m and 2-m Cables are available. Models and Application Model No. Specifications 3G3IV-PCN126 Cable length: 1 m 3G3IV-PCN326 Cable length: 3 m...
Page 412 n DC Reactor A DC Reactor is used to control harmonics generated by the Inverter. It is more effective than and can be used in combination with an AC Reactor. It is also used to increase the power factor. Models and Application The standard models of DC Reactors are listed below.
Page 413 Options and Peripheral Devices Dimensions The dimensions of a DC Reactor are given below. Model Dimensions (mm) Weight Dimensions 3G3HV- Diagram (kg) PUZDABo o o o 5.4A8MH 18A3MH 36A1MH 72A0.5MH 90A0.4MH 3.2A28MH 5.7A11MH 12A6.3MH 23A3.6MH 33A1.9MH 47A1.3MH 2 mounting holes App.
Page 414 n AC Reactor An AC Reactor is used to control harmonics generated by the Inverter or when the power supply capacity is greatly larger than the Inverter’s capacity. It is also used to increase the power factor. Select the AC Reactor from the following table according to the motor capacity.
Page 415: Wiring Example
Options and Peripheral Devices Wiring Example A wiring example for an AC Reactor is shown below. AC reactor MCCB Motor Inverter Dimensions The dimensions of a DC Reactor are given below. Model Dimen- Dimensions (mm) Weight 3G3IV sions (kg) -PUZBABo o o o Diagram 2.5A4.2MH 10.5...
Page 416 n Input Noise Filters for EMC Directives (3G3RV-PFS @ @ @ @ , by Schaffner) When conformance to the EMC Directives in the EC Directives is required, always use one of these Filters. The Filter is connected between the Inverter’s power supply input terminals (R/L1, S/L2, T/L3) and the power supply.
Page 417 Options and Peripheral Devices Dimensions The dimensions of an Input Noise Filter for EMC Directives are given below. M5 (Inverter mounting holes x 4) M6 (Inverter mounting holes x 4) Dimensions Diagram 1 Dimensions Diagram 2 M5 (Inverter mounting holes x 4) Dimensions Diagram 3 Dimensions Diagram 4 Dimensions Diagram 6...
Page 418: Simple Input Noise Filter
n Simple Input Noise Filter A Simple Input Noise Filter reduces noise coming into the inverter from the power supply line and to reduce noise flowing from the inverter into the power supply line. Connected the Filter to the power supply input side.
Page 419 Options and Peripheral Devices Wiring Example A wiring example for a Simple Input Noise Filter is shown below. Inverter Input Noise Filter MCCB Dimensions The dimensions of a Simple Input Noise Filter are given below. Dimensions Model Weight Dimensions Mounting 3G3EV- Diagram (kg)
Page 420 n Input Noise Filter An Input Noise Filter reduces noise coming into the inverter from the power supply line and to reduce noise flowing from the inverter into the power supply line. Connected the Filter to the power supply input side. Models and Application The standard models of Input Noise Filters are listed in the following table.
Page 421 Options and Peripheral Devices Dimensions The dimensions of an Input Noise Filter are given below. Dimensions (mm) Weight Dimensions Model 3G3IV- Diagram (kg) PFN258L4207 4-M5 PFN258L5507 4-M5 PFN258L7534 4-M5 PFN258L10035 4-M5 PFN258L13035 4-M5 PFN258L18007 4-M5 PFN359L25099 PFN359L30099 J (mounting screw) J (mounting screw) Dimensions Diagram 1 Dimensions Diagram 2...
Page 422: Output Noise Filter
n Output Noise Filter An Output Noise Filter controls noise generated by the Inverter so it does not enter the power supply. It is con- nected to the motor output side. Models and Application The standard models of Output Noise Filters are listed in the following table. Inverter Output Noise Filter Max.
Page 423 Options and Peripheral Devices Wiring Example A wiring example for an Output Noise Filter is shown below. Output Noise Filter Inverter Dimensions The dimensions of an Output Noise Filter are given below. Model Weight Terminal 3G3IV- (Diameter) (Diameter) (kg) 7 × 4.5 PLF310KA TE-K5.5 M4 7 ×...
Page 424: Appendix
Appendix This chapter provides precautions for the Inverter, motor, and peripheral devices and also pro- vides lists of parameters. Inverter Application Precautions ........ 10-2 Motor Application Precautions ........10-5 Wiring Examples............10-7 Parameters ..............10-14...
Page 425: Inverter Application Precautions
Although the Inverter's protective functions will stop operation when a fault occurs, the motor will not stop immediately. Always provide mechanical stop and protection mechanisms on equipment requiring an emer- gency stop. nOptions Terminals B1, B2, 3 are for connecting only the options specifically provided by OMRON. Never connect any other devices to these terminals.
Page 426: Installation
Inverter Application Precautions K K K K Installation Observe the following precautions when installing an Inverter. nInstallation in Enclosures Either install the Inverter in a clean location not subject to oil mist, airborne matter, dust, and other contami- nants, or install the Inverter in a completely enclosed panel. Provide cooling measures and sufficient panel space so that the temperature surrounding the Inverter does not go beyond the allowable temperature.
Page 427: Handling
K K K K Handling Observe the following precautions when wiring or performing maintenance for an Inverter. nWiring Check The Inverter will be internally damaged if the power supply voltage is applied to output terminal U, V, or W. Check wiring for any mistakes before supplying power. Check all wiring and sequences carefully. nMagnetic Contactor Installation Do not start and stop operation frequently with a magnetic contactor installed on the power supply line.
Page 428: Motor Application Precautions
Cooling effects diminish in the low-speed range, resulting in an increase in the motor temperature. Therefore, the motor torque should be reduced in the low-speed range whenever using a motor not made by OMRON. If 100% torque is required continuously at low speed, consider using a special inverter or vector motor.
Page 429: Using The Inverter For Special Motors
K K K K Using the Inverter for Special Motors Observe the following precautions when using a special motor. nPole-changing Motor The rated input current of pole-changing motors differs from that of standard motors. Select, therefore, an appropriate Inverter according to the maximum input current of the motor to be used. Before changing the number of poles, always make sure that the motor has stopped.
Page 430: Wiring Examples
Wiring Examples Wiring Examples This section provides wiring examples to connect a Braking Unit and other peripheral devices to the main circuits, examples of wiring a transformer to Inverter I/O, and other aspects of Inverter wiring. K K K K Using a Braking Resistor Unit This example shows wiring for a Braking Resistor Unit.
Page 431: Using Braking Units In Parallel
K K K K Using Braking Units in Parallel This example shows wiring for using two Braking Units in parallel. A sequence is required to turn OFF the Thermal power supply for the thermal overload relay Thermal protector protector trip contacts of the Braking Resistor Unit. Brak- Brak- Resis-...
Page 432: Using A Braking Unit And Three Braking Resistor Units In Parallel
Wiring Examples K K K K Using a Braking Unit and Three Braking Resistor Units in Parallel This example shows wiring for using three Braking Resistor Units in parallel. Thermal Thermal Thermal protector protector protector Braking Braking Braking Resistor Resistor Resistor A sequence is required to turn OFF the Unit...
Page 433: Using An Analog Operator
K K K K Using an Analog Operator This example shows wiring for using an Analog Operator. The Analog Operator model number is 3G3IV- PJVOP95o or 3G3IV-PJVOP96o. This example shows wiring for the 3G3RV-A2075 (200-V class Inverters of 7.5 kW) Short-circuit bar (Standard) MCCB...
Page 434 Wiring Examples K K K K Using Transistors for Input Signals and a 0-V Common in Sinking Mode with an Internal Power Supply Set CN5 (shunt connector) on the control card to NPN as shown below for a sequence that uses an NPN tran- sistor for an input signal (0-V command and sinking mode) and an internal +24-V power supply.
Page 435 K K K K Using Transistors for Input Signals and a 0-V Common in Sinking Mode with an External Power Supply Set CN5 (shunt connector) on the control card to EXT as shown below for a sequence that uses an NPN tran- sistor for an input signal (0-V command and sinking mode) and an external +24-V power supply.
Page 436: Using Contact And Open Collector Outputs
Wiring Examples K K K K Using Contact and Open Collector Outputs This example shows wiring for contact outputs and open collector outputs. The following example is for the 3G3RV-A2075 (200-V class Inverter for 7.5 kW). MCCB Motor 3-phase power Inverter Ground Ammeter scale adjustment resistor...
Page 437 Parameters Factory settings are given in the following table. These settings are for a 200-V class Inverter of 0.4 kW set to factory set control method (open loop vector control). Table 10.1 Parameters Fac- Fac- Set- Set- Name tory Name tory ting ting...
Page 438 Parameters Table 10.1 Parameters (Continued) Fac- Fac- Set- Set- Name tory Name tory ting ting Setting Setting Torque compensation primary C4-02 d6-01 Field weakening level delay time constant C4-03 Starting torque value (forward) d6-02 Field frequency C4-04 Starting torque value (reverse) E1-01 Input voltage setting C4-05...
Page 439 Table 10.1 Parameters (Continued) Fac- Fac- Set- Set- Name tory Name tory ting ting Setting Setting Operation selection at PG open cir- F1-02 H1-04 Terminal S6 function selection 4 (3) cuit (PGO) Operation selection at overspeed F1-03 H1-05 Terminal S7 function selection 6 (4) (OS) F1-04...
Page 440 Parameters Table 10.1 Parameters (Continued) Fac- Fac- Set- Set- Name tory Name tory ting ting Setting Setting L1-01 Motor protection selection L7-03 Forward regenerative torque limit L1-02 Motor protection time constant L7-04 Reverse regenerative torque limit Alarm operation selection during Protect selection for internal DB L1-03 L8-01...
Page 441 Table 10.1 Parameters (Continued) Fac- Fac- Set- Set- Name tory Name tory ting ting Setting Setting o2-10 Fan operation time setting T1-02 Motor output power 0.40 Fault trace/fault history initializa- o2-12 T1-03 Motor rated voltage 200.0 tion o3-01 Copy function selection T1-04 Motor rated current 1.90...
Page 442 Index Symbols CPU internal A/D converter error (CPF04), 7-7 CPU internal A/D converter error (CPF05), 7-7 +/- speed, 6-68 CPU-ASIC mutual diagnosis fault (CPF09), 7-7 crimp terminal, 2-14, 2-54 Numerics 2-wire sequence, 6-12 3-wire sequence, 6-13 daily inspection, 8-2 DC reactor, 2-22 deceleration stop, 6-18 detecting motor overspeed, 6-146 AC reactor, 2-22...
Page 443 Index motor protection operation time, 6-49 motor rotation direction, 6-51 Ground Fault (GF), 7-2 motor torque detection, 6-43 ground wiring, 2-25 multi-function analog input, 6-40 grounding, 2-23 Multi-function analog input selection error (OPE07), 7-11 Multi-function input selection error (OPE03), 7-11 multi-step speed operation, 6-10 High-slip Braking OL (OL7), 7-5 hunting prevention function, 6-38...
Page 444 Index dwell functions (b6), 5-17 PG Disconnection Detected (PGO), 7-5 energy saving (b8), 5-18 PG is disconnected (PGO), 7-9 fault history (U3), 5-80 PG pulse setting, 6-144 fault restart (L5), 5-62 PG rotation direction, 6-144 fault trace (U2), 5-79 PG Speed Control Card, 2-48, 6-144 field weakening (d6), 5-31 PID control applications, 6-117 hardware protection (L8), 5-65...
Page 445 Index timer function, 6-116 torque compensation, 6-36 torque limit function, 6-40 trial operation, 4-1 Troubleshooting, 7-1, 7-15 Undertorque 1 (UL3), 7-9 Undertorque 2 (UL4), 7-9 Undertorque Detected 1 (UL3), 7-5 Undertorque Detected 2 (UL4), 7-5 V/f control with PG, 4-10 V/f control without PG, 4-10 V/f data setting error (OPE10), 7-12 V/f pattern setting, 6-129, 6-130...
Page 446: Revision History
Revision History Revision History A manual revision code appears as a suffix to the catalog number on the front cover of the manual. Cat. No. I532-E1-1 Revision Code The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.

This manual is also suitable for:

Sysdrive 3g3rv-a2004 Sysdrive 3g3rv-a2004-e Sysdrive 3g3rv-a2007 Sysdrive 3g3rv-a2007-e Sysdrive 3g3rv-a2015 Sysdrive 3g3rv-a2015-e ... Show all

Omron SYSDRIVE 3G3RV Series User Manual

Handling Inverters

Chapter 1

Wiring

Chapter 2

Digital Operator and Modes

Trial Operation

Parameters

Parameter Settings by Function

Chapter 6

Troubleshooting

Maintenance and Inspection

Specifications

Appendix

Quick Links

Troubleshooting

Related Manuals for Omron SYSDRIVE 3G3RV Series

Summary of Contents for Omron SYSDRIVE 3G3RV Series
