Command Actions
Enter menu sequence:
Direct access sequence:
Command Result
System action taken:
System message display:
Optimization Metrics Table Parameters
Table 54 describes the parameters that may be displayed in the
optimization metrics table.
Table 54 Classes of Service
Parameter Description
CBR Constant Bit Rate
RT-VBR Real Time Variable Bit Rate
NRT-VBR Non-Real Time Variable Bit Rate
ABR Available Bit Rate
UBR Unspecified Bit Rate
Table 55 describes the values that may be assigned to the optimization
parameters. These parameters are used to determine the path in the
network for each Quality of Service.
Table 55 Optimization Values
Value
0 - opt_admin_weight
1 - opt_max_cr
2 - opt_av_cr
3 - opt_ctd
Setting Optimization Metrics
(1) SYS: Platform config
(1) SET: Switch setup
(10) PNI: PNNI Setup
(4) CFP: Configure PNNI
(3) NCF: Node Configuration
(5) OPT: Optimization Metrics
(1) GOP: Get Optimization
1 1 10 4 3 5 1
The PNNI optimization metrics table is displayed.
Information is displayed as shown in the example.
Description
Optimized Administrative Weight (assigned to each
path in the network)
Optimized Maximum Cell Rate
Optimized Average Cell Rate
Optimized Cell Transfer Delay
Metrics
