Draytek Vigor3900 User Manual page 93

Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Available parameters are listed as follows:
Item
IP Address
Subnet Mask
Gateway IP
Address
DNS Server IP
Address
IP Alias
Description
Type the IP address specified for such profile.
Use the drop down list to choose the subnet mask for such
profile.
Type the gateway address for such profile.
Type a public IP address as the primary DNS (Domain
Name Server). To add a new IP address, simply place the
mouse cursor on this filed. The following dialog will appear.
Add – click this button to have a field for adding a new IP
address.
Save – click this button to save the setting.
– click the icon to remove the selected entry.
Type other IP addresses to be bound to this interface. This
setting is optional. If you have typed addresses here, you
can see and choose it in later web page settings (e.g.,
NAT>>Port Redirection/DMZ Host).
Add – Click this button to display the IP address field for
adding a new IP address. Type the IP address on the tiny
boxes one by one.
85
