3.
The QoS settings page appears.
Available parameters are listed as follows:
Item
WAN
Status
Bandwidth
High/Medium/
Normal/Low
Description
Use the drop down list to set WAN interface for QoS by
choosing one of the WAN interfaces.
Enable – Click it to enable such profile.
Disable – Click it to disable the QoS profile.
Type the number as the total transmission rate for the
outgoing /incoming data. The range can be set from 64000 to
10000000.
Click the unit (Kbps or Mbps) for such rate.
There are several available outgoing queues. All queues in
the data group to be initialized with weights of zero,
resulting in a strict service to completion (STC) mechanism
