Delete
Refresh
Profile
Mode
Interface
Primary Profile
Backup Profile
There are two modes, Load Balance and Failover, for you to choose as the Pool
configuration. If you choose Load Balance, the tab of Load Balance will be shown which
allows you to configure for different WAN interfaces. If you choose Failover, the tab of
Failover will be displayed which allows you to specify the primary profile and backup
profile for such Pool setting.
you to modify the corresponding settings for the selected
rule.
Remove the selected rule profile.
To delete a rule, simply select the one you want to delete
and click the Delete button.
Renew current web page.
Display the name of the load balance profile.
Display the mode (failover or load balance) used by the pool
profile.
Display the name of the WAN profiles for Load Balance
rule.
Display the primary profile configured in Failover page for
such profile.
Display the backup profile configured in Failover page for
such profile.
