Each item will be explained as follows:
Item
Packet count
Interface
Host / Port
Start
Download
Note
Description
Specify the threshold value of the packets to be captured by
Vigor router. If the packet captured reaches the threshold
value, Vigor router will cease the packet capturing.
Specify an interface which will be used to capture the
packets. The default setting is "All".
Type the IP address of the host or the post number that you
want to monitor.
Click it to capturing the packets and display the results on
this page.
The packets captured by Vigor router will be stored in router
as "packetmonitor.pcap". Download the file and store on
your host.
A pop up window appears to show special notices for such
function.
454 Vigor3900 Series User's Guide
