H H o o w w t t o o e e d d i i t t a a n n I I n n t t e e r r f f
1. Open LAN>>Switch and click the Interface tab.
2. Please select a profile and click the Edit button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Interface
Enable
Speed
Flow Control
802.3az
Apply
Cancel
4. Enter all the settings and click Apply. The profile has been edited.
a a c c e e p p r r o o f f i i l l e e
Description
Display the name of LAN interface profile.
Check the box to enable the Mirror function for the switch.
Use the drop down list to specify the transmission rate for
such profile.
Click Enable to enable such function. When the data cache
is approaching to full load, Vigor router will pause
transmitting the packets till the system is able to accept new
data again. It can avoid the network traffic congestion.
It is a function of energy-efficient Ethernet.
It can detect the network traffic automatically to adjust the
power output and let Vigor3900 save the energy during the
period of low traffic.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
136 Vigor3900 Series User's Guide
