Draytek Vigor3900 User Manual page 105

Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
H o w t o e d i t a n e w U
H o w t o e d i t a n e w U
1. Choose one of the USB WAN profiles and click Edit.
2. The settings under Global tab are listed as below:
Available parameters are listed as follows:
Item
Profile
Enable
Description
Port
Protocol
Connection
Detection Host
S B W A N p r o f i l e
S B W A N p r o f i l e
Description
Display the name of the USB WAN profile.
Check it to enable the USB WAN profile.
Give the brief description for such profile.
Display the physical WAN interface for such profile.
Choose the connection mode for USB WAN.
If you choose PING/HTTP as Connection Detection Mode,
you have to specify the detection host address in this field.
97
