Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
2. Click the Add button to open the following dialog. Different protocol type selected will
bring up different configuration web page.
Available parameters are listed as follows:
Item
Profile
(max length:7)
Enable
Description
VLAN ID
Priority(802.1q)
Default MAC
Address
MAC Address
Description
Type the name of the LAN profile.
Check this box to enable such profile.
Type the description for the new LAN profile.
Type a number as the VLAN ID to make the data be
identified while performing data transmission.
Type the packet priority number for such profile. The range is
from 0 to 7.
Enable – Click it to enable the default MAC address for such
profile.
Disable – Click it to type the MAC address manually for such
profile.
If Default MAC address is disabled, please specify a MAC
115
