Item
Refresh
Auto Refresh
BGP Neighbor
Neighbor IP
Neighbor AS
State
Description
Renew current web page.
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
Display the neighbor profile name configured successfully in
the Neighbor tab in Routing >>BGP configuration.
Display the neighbor IP address configured successfully in
the Neighbor tab in Routing >>BGP configuration.
Display the autonomous system number of the neighbor
configured successfully in the Neighbor tab in Routing
>>BGP configuration.
Display the status of neighbor profile. If it is established
successfully, "Established (time)" will be shown in this field.
176 Vigor3900 Series User's Guide
