Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Interface
Web Allow
Telnet Allow
SSH Allow
HTTPS Allow
SSL Proxy Allow
FTP Allow
SAMBA Allow
Server Certificate
Access List
IP List
Apply to LAN
Allow Ping from WAN
LAN Access Control
Allow management
from LAN
Apply to LAN Subnet
Web Allow
Telnet Allow
SSH Allow
Click Enable to allow system administrator to login from the
Internet and management the web page of the router.
Click Enable to allow system administrator to login from the
telnet and management the web page of the router.
Click Enable to allow system administrator to login from the
SSH server and management the web page of the router.
Click Enable to allow system administrator to login from the
HTTPS server and management the web page of the router.
Click Enable to allow SSL Proxy user to login SSL Proxy
Service.
Click Enable to allow system administrator to login from the
FTP server and management the web page of the router.
Click Enable to allow the users (with SAMBA function
enabled) login into the SAMBA server through Vigor
router.
Use the default setting.
Click Enable to allow system administrator to login from the
user defined IP address and management the web page of
the router. If you enable such function, the system can be
managed by these three IP addresses via WAN.
Type the first IP address for the system administrator to
login.
The former boxes indicate the IP address allowed to login to
the router, and the later box indicates a subnet mask allowed
to login to the router.
Choose the LAN profile(s) that the IPs controlled under
such profile are allowed to access into the web user
interface of Vigor3900.
Click Enable to allow system administrator to ping the
router from WAN interface.
WAN Profile – Specify the WAN interface to perform the
"Ping" job.
Click Enable to control such router from LAN.
Choose the LAN profile(s) that the IPs controlled under
such profile are allowed to access into the web user
interface of Vigor3900.
Click Enable to allow system administrator to login from the
Internet and management the web page of the router.
Click Enable to allow system administrator to login from the
telnet and management the web page of the router.
Click Enable to allow system administrator to login from the
