Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
DSCP It is available when DSCP is selected as the Match type.
TOS It is available when TOS is selected as the Match type.
Traffic Class Choose the traffic class to category the packets matching
with the condition configured as above. High is the highest;
Normal is the lowest.
Local Address
Click
IP Group profile. Check the object profile(s) as the source
target.
Local IP Object – Use the drop down list to choose one of
the IP objects for such rule profile.
Local IP Group – Use the drop down list to choose one of
the IP group for such rule profile.
If you want to create a new IP object, simply click
open the following dialog.
on the left side of the Source IP Object/Source
391
