3 . 1 0 . 4 E n a b l e W A N C
3 . 1 0 . 4 E n a b l e W A N C
1. Login the web user interface of the CPE.
2. Open WAN>>Internet Access. Use the drop down list of Access Mode on WAN1 to
select MPoA (RFC1483/2684). Then, click Details Page.
3. Click Specify an IP address. Type correct WAN IP address, subnet mask and gateway
IP address for your CPE. Then click OK.
Note: Reboot the CPE device and re-log into Vigor3900. CPE which has registered
to Vigor3900 will be captured and displayed on the page of Central VPN
Management>>CPE Management.
o n n e c t i o n o n C P E
o n n e c t i o n o n C P E
