Item
Profile
Status
Domain Name
Alias Domain Name
Type
IP Address
IPv6 Address
CNAME
DNS Server
Apply to
Apply
Cancel
4. Enter all of the settings and click Apply. The new profile will be added on the screen.
Description
Type a name for such profile.
Check the box to enable such profile.
Type the domain name for such profile.
Type several domain names in this field. LAN DNS will
redirect both Domain name and Alias Domain Name to an
assigned IP.
For example, Domain Name is set with "www.draytek.com",
and the Alias Domain Name is set as "www.dray.com". If
the IP address is set with "192.168.1.123", then both
"www.draytek.com" and "www.dray.com" will be directed
to "192.168.1.123".
When you choose IP, you need to type IP address and/or
IPv6 address as the mapping target.
When you choose CNAME, you need to type the content
(domain) of CNAME as the mapping target.
Please choose the suitable type to determine which IP
address or CNAME will be mapped by the above domain
name/alias domain name.
When you choose FORWARD, you need to type the IP
address of DNS server as the mapping target.
Type the IP address in this field. Then, the above domain
and/or alias domain name will be mapped to such IP address.
Type the IPv6 address in this field. Then, the above domain
and/or alias domain name will be mapped to such IPv6
address.
Type another domain name in this field. Then, the above
domain and/or alias domain name will be mapped to such
specified domain.
Type the IP address of the DNS server.
LAN DNS can be applied to specified LAN interfaces or all
of the LAN interfaces.
LAN Profile – When you choose Specified LANs, it is
necessary to specify at least one LAN profile in this field.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
142 Vigor3900 Series User's Guide
